Eaton PXLED Floodlight 13042210001 - IECEx/ATEX Zone 1/2
Part Number: 13042210001
Quick Summary
Eaton PXLED floodlight delivers high-output illumination for hazardous-location industrial facilities. In harsh environments, unreliable lighting and frequent replacements drive maintenance costs and safety risk. This fixture carries IECEx/ATEX certification for Zone 1/2 and Zone 21/22 with IP66/IP67 protection, backed by toughened glass lens and rugged aluminum housing. Its energy-efficient LED design reduces operating expenses while delivering consistent performance across a wide input range. For project engineers and procurement teams, the PXLED integrates seamlessly with existing electrical infrastructure and simplifies inventory management, delivering long-term reliability and predictable lifecycle costs in demanding applications.
Product Information
Extended Description
13042210001 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED floodlight, 0.48A, 5700 K color temp, 2 x M25 metal cable glands, Glass cover, 10000 lm, 110 lm/W, Anodized copper-free aluminum, Narrow beam, > 0.95, Swivel, 2 LED systems, 110-277 Vac, 127-270 Vdc, 98W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042210001
Product Length/Depth
502 mm
Product Height
303 mm
Product Width
259 mm
Product Weight
14.4 kg
EAN
4250959974273
Area classification
Hazardous/Classified Locations
Standards type
IEC IECEx/ATEX
IECEx/ATEX hazardous rating
Zone 21 Zone 22 Zone 1 Zone 2
Ingress protection (IP) ratings
IP66 IP67
Lamp type
LED
Lumens
10000
Lumens per watt
110
Optical distribution
Narrow beam
Color temperature
5700 K
Lens material
Toughened glass
Entry size
2 x M25 ADE-1F2 metal cable glands
Wattage
98W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
0.48A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, two LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED EU-Type Examination Certificate
Crouse-Hinds CEAG PXLED EU-Type Examination Certificate
Crouse-Hinds CEAG PXLED EU-Type Examination Certificate
Crouse-Hinds CEAG PXLED EU-Type Examination Certificate
Crouse-Hinds CEAG PXLED EU-Type Examination Certificate
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED LED LDT photometric files
Crouse-Hinds CEAG PXLED LED LDT photometric files
Feature: High-output LED performance delivering 10,000 lumens at 5700 K with 98 W input and a power factor greater than 0.95. Business Impact: Superior illumination with energy efficiency, facilitating safer operations while reducing energy spend. Application: Outdoor hazardous-location areas such as plant exteriors, loading bays, and perimeters where precise, bright lighting is essential. Feature: Narrow beam optical distribution with toughened glass lens. Business Impact: Targeted light where it's needed, minimizing glare and waste, improving inspection accuracy and reducing maintenance visits. Application: Zone 1/2 and Zone 21/22 work zones in chemical plants and refineries. Feature: Robust housing of anodized copper-free aluminum and 2 x M25 cable glands. Business Impact: Long-term durability in corrosive environments and flexible, clean installation. Application: Harsh outdoor or indoor hazardous locations with challenging ingress conditions. Feature: Dual LED systems with a swivel bracket. Business Impact: Redundancy and adjustable aiming reduce downtime, support easy retrofit, and speed commissioning. Application: Perimeter lighting and workstation illumination with adaptable aiming angles. Feature: Wide voltage compatibility 110-277 Vac and 127-270 Vdc with 50-60 Hz. Business Impact: One part fits multiple supply scenarios, lowering spare-part complexity and stocking costs. Application: Mixed-voltage facilities and projects with evolving power systems. Feature: Compliance and safety certifications including IECEx/ATEX and Hazardous Locations rating. Business Impact: Regulatory peace of mind and faster permit processes, improving project timelines. Application: Manufacturing, mining, and chemical processing environments requiring zone classification. Feature: IP66/IP67 protection and toughened lens for reliability in wet and dusty environments. Business Impact: Minimal maintenance cycles and extended service life, reducing total cost of ownership. Application: Outdoor floodlighting around tanks, racks, and outdoor equipment in hazardous zones.
Get a Quick Quote for a Eaton Crouse-Hinds 13042210001
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042210001?
Enquire Now
FAQs
Installation should follow the manufacturer guidelines for hazardous locations, using the 2 x M25 gland entries provided. Ensure the unit is mounted within its swivel bracket to adjust aiming, and verify voltage compatibility (110-277 Vac or 127-270 Vdc) before energizing. Support from qualified electrical personnel is recommended to maintain compliance with IECEx/ATEX standards.
The PXLED floodlight delivers up to 10,000 lumens with a color temperature of 5700 K and a high luminous efficacy of 110 lm/W. It operates at 0.48 A with a power draw of 98 W, maintaining a power factor > 0.95 across the specified voltage range, ensuring efficient, steady illumination in demanding environments.
Yes. The unit is IECEx/ATEX certified for Zone 1/2 and Zone 21/22 and is rated for Hazardous/Classified Locations, guaranteeing compliance with global explosion-protection requirements while delivering robust, reliable performance in harsh conditions.
It carries IECEx/ATEX certification for hazardous locations, Zone 1/2 and Zone 21/22, plus IP66/IP67 ingress protection. Its toughened glass lens and anodized copper-free aluminum housing resist environmental ingress, aiding long service life in outdoor and indoor hazardous environments.
With 10,000 lumens per 98 W and a PF > 0.95, the PXLED reduces energy use while delivering durable performance in demanding zones. Its rugged housing, sealed optics, and dual LED system minimize maintenance cycles and downtime, delivering long-term ownership savings in hazardous-location facilities.
