Eaton 13042211011 PXLED Floodlight - IECEx/ATEX Zone 1
Part Number: 13042211011
Quick Summary
Eaton Crouse-Hinds PXLED floodlight is a rugged LED luminaire designed for hazardous locations and challenging industrial environments. It delivers 10000 lumens at 5700 K in a compact, corrosion-resistant housing. Engineers often struggle with reliable, explosion-protected lighting that withstands dust, moisture, and vibration while meeting strict certifications. The PXLED meets IECEx/ATEX requirements and Zone 1, Zone 21, Zone 22 classifications, backed by IP67 and IP66 protection. With a wide beam, toughened glass lens, and a swivel bracket, it simplifies installation and maintenance. Its 110-277 Vac and 127-270 Vdc voltage range supports diverse power designs, reducing stocking complexity. Overall, this luminiare couples high output with robust safety features to improve uptime, worker safety, and lifecycle cost for hazardous-area facilities.
Product Information
Extended Description
13042211011 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED flood, 0.48A, 5700 K color temp, 1xM25 metal gland, 1xM25 plastic plug, Glass cover, 10000 lm, 102 lm/W, Alum, Wide, >0.95, Swivel, 2 LED systems, Type 2410-max. 6mm² term, 110-277 Vac, 127-270 Vdc, 98W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042211011
Product Length/Depth
502 mm
Product Height
303 mm
Product Width
259 mm
Product Weight
14.4 kg
EAN
4251510777739
Area classification
Hazardous/Classified Locations
Standards type
IEC IECEx/ATEX
IECEx/ATEX hazardous rating
Zone 1 Zone 21 Zone 22 Zone 2
Ingress protection (IP) ratings
IP67 IP66
Lamp type
LED
Lumens
10000
Lumens per watt
102
Optical distribution
Wide beam
Color temperature
5700 K
Lens material
Toughened glass
Type
Type 2410 - max. 6 mm² terminals
Entry size
1 x M25 ADE-1F2 metal gland, 1 x M25 plastic threaded plug
Wattage
98W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
0.48A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, two LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED IES photometric files
Crouse-Hinds CEAG PXLED IES photometric files
The PXLED floodlight delivers high-output illumination with 10000 lumens at a 5700 K color temperature, providing immediate visibility improvements and reducing the number of fixtures required to cover a given area, which lowers capital expenditure and energy use. In hazardous locations, this translates to safer work environments and faster inspections on production lines, chemical plants, and offshore facilities. With two LED systems, the unit offers redundancy and improved MTBF, minimizing downtime and maintenance costs while supporting continuous operation in demanding environments. The toughened glass lens and anodized aluminum enclosure resist corrosive atmospheres and physical impacts, extending service life and reducing replacement cycles in aggressive plant settings. A swivel bracket enables precise aiming and quick re-aiming during shifts or after layout changes, simplifying installation and retrofit projects. Compatibility with 110-277 Vac and 127-270 Vdc reduces inventory variety and supports flexible power design across global sites.
Get a Quick Quote for a Eaton Crouse-Hinds 13042211011
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042211011?
Enquire Now
FAQs
Plan for IECEx/ATEX Zone 1, Zone 21, Zone 22 compliance and install with 1 x M25 ADE-1F2 metal gland plus 1 x M25 plastic threaded plug. Use the swivel bracket for flexible mounting angles and ensure the enclosure is properly grounded. The unit supports Type 2410 terminals up to 6 mm² and operates within 110-277 VAC or 127-270 VDC to suit site power systems.
Voltage rating covers 110-277 Vac and 127-270 Vdc, frequency 50-60 Hz, and current 0.48 A with a wattage of 98 W. The luminaire provides a high power factor (>0.95) and broad compatibility with common industrial supply designs. Termination is via Type 2410 max 6 mm² terminals, and the fixture uses an M25 gland/plugs for secure, sealed entry in hazardous areas.
Yes. The PXLED is IECEx/ATEX certified for hazardous locations and explicitly rated for Zone 1 (gas) and Zone 21/22 (dust) classifications. This makes it appropriate for refineries, chemical plants, and offshore facilities where explosive atmospheres exist, while maintaining strict IP protection (IP67/IP66).
With 10000 lumens at 5700 K and 102 lm/W efficiency, fewer fixtures deliver the same illumination, reducing install and lifecycle costs. The two LED systems provide redundancy, lowering MTTR during maintenance. High IP ratings and a toughened glass lens minimize unscheduled downtime, while the long service life of LED technology reduces replacement cycles in harsh environments.
Comprehensive resources include the PXLED brochure, UK and EU DoC certificates, operating instructions, and IES photometric files. Additional certifications cover IECEx/ATEX conformity, Russian, UK, and EU certificates, plus installation and maintenance guidance to support commissioning, regulatory audits, and ongoing support.
