Eaton Crouse-Hinds PXLED Floodlight 13042216005 - IP66/IP67
Part Number: 13042216005
Quick Summary
Eaton's PXLED floodlight provides high-output LED illumination for hazardous-area industrial facilities. In demanding environments, operators need reliable lighting that withstands dust, moisture, and explosive atmospheres while meeting stringent safety standards. The unit carries IECEx/ATEX certifications and IP66/IP67 ingress protection, with Zone 1, Zone 2, Zone 21, and Zone 22 classifications for versatile hazardous-location use. With a toughened-glass lens and anodized aluminum housing, it combines rugged durability with precise optical performance. Compatible with 110–277 VAC or 127–270 VDC and drawing 98 W, the PXLED reduces energy costs and maintenance while offering easy installation via 2 x M25 plugs and a swivel bracket.
Product Information
Extended Description
13042216005 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED flood, 0.48A, 5700 K color temp, 2 x M25 plastic plugs, Glass cover, 10000 lm, 102 lm/W, Aluminum, Asymmetric 2, >0.95, Swivel, 2 LED systems, Type 2410-max. 6 mm² term, 110-277 Vac, 127-270 Vdc, 98W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042216005
Product Length/Depth
502 mm
Product Height
303 mm
Product Width
259 mm
Product Weight
14.4 kg
EAN
4251510758882
Area classification
Hazardous/Classified Locations
Standards type
IEC IECEx/ATEX
IECEx/ATEX hazardous rating
Zone 22 Zone 21 Zone 1 Zone 2
Ingress protection (IP) ratings
IP66 IP67
Lamp type
LED
Lumens
10000
Lumens per watt
102
Optical distribution
Asymmetric 2
Color temperature
5700 K
Lens material
Toughened glass
Type
Type 2410 - max. 6 mm² terminals
Entry size
2 x M25 plastic threaded plugs
Wattage
98W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
0.48A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, two LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED IES photometric files
Crouse-Hinds CEAG PXLED IES photometric files
Feature: The PXLED floodlight delivers 10000 lumens and 5700 K color temperature from a single LED platform, drawing 98 W. Business Impact: Provides bright, uniform illumination with energy efficiency (102 lm/W) and reduced operating costs due to long LED life. Application: ideal for hazardous locations like loading bays, aisles, and outdoor work areas in chemical plants or refineries. Feature: IP66/IP67 ingress protection with IECEx/ATEX certification and Zone 1/2, Zone 21/22 ratings. Business Impact: ensures regulatory compliance and safe operation in harsh environments, reducing risk and downtime. Application: suitable for oil & gas facilities, mining sites, and offshore platforms. Feature: Asymmetric 2 optical distribution plus a toughened-glass lens and anodized aluminum housing. Business Impact: targeted illumination with reduced glare and durable performance under demanding conditions. Application: walkways, equipment bays, and vehicle routes where precise lighting control matters. Feature: Two LED systems, 2 x M25 plugs, and termination up to 6 mm². Business Impact: Flexible wiring and fast field installation, lowering commissioning time and sparing labor costs. Application: retrofit projects and new builds with tight installation constraints. Feature: Wide voltage range (110–277 VAC, 127–270 VDC) and PF > 0.95. Business Impact: resilient operation across regions and grids, simplifying spare part inventory. Application: global deployments across multi-site facilities needing consistent performance.
Get a Quick Quote for a Eaton Crouse-Hinds 13042216005
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042216005?
Enquire Now
FAQs
Plan for IP66/IP67 rated enclosure and Zone 1/ Zone 2/ Zone 21/22 suitability. Use the 2 x M25 plugs and 6 mm² terminal limits, connect to 110–277 VAC or 127–270 VDC, and mount with the swivel bracket to achieve the required light distribution.
It provides 10000 lumens at 5700 K, draws 98 W, and has a power factor > 0.95. Input voltage ranges 110–277 VAC or 127–270 VDC with a frequency rating of 50–60 Hz and current around 0.48 A.
Yes. With IP66/IP67 protection and IECEx/ATEX certifications covering Zone 1/2 and Zone 21/22, it is engineered for harsh environments typical of oil, gas, mining, and maritime facilities.
The product carries IECEx/ATEX certification, IP66/IP67 ratings, and Zone classifications. Documentation includes EU DoC and related compliance certificates available from the manufacturer’s certification library.
High lumen output with 102 lm/W efficiency reduces number of fixtures and energy use. Rugged housing and glass lens improve durability, lowering maintenance cycles and extending service life in hazardous locations, delivering faster ROI on capital projects.
