Eaton Crouse-Hinds PXLED Floodlight 13042301005 - IECEx/ATEX
Part Number: 13042301005
Quick Summary
Introducing Eaton Crouse-Hinds PXLED floodlight, a high-efficiency LED luminaire designed for hazardous locations in industrial facilities. This fixture delivers robust illumination while reducing maintenance downtime in challenging environments. Operators often struggle with lens degradation, corrosion, and unreliable performance in areas with dust, moisture, and vibration; PXLED addresses these through a rugged copper-free aluminum housing, toughened glass, and precise optics. The unit carries IECEx/ATEX certification for Zone 1/2 and Zone 21/22, along with IP66/IP67 protection, ensuring safe operation in demanding settings. With a 147 W rating, 15,000 lumen output, and 4000 K color temperature, it provides consistent brightness and color rendering. Its wide beam and swivel mounting support versatile placement for oil and gas, chemical processing, mining, and other asset-intensive operations.
Product Information
Extended Description
13042301005 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED flood, 0.72A, 4000K color temp, 2xM25 plastic plugs, Glass cover, 15000 lm, 102 lm/W, Anod copper-free alum, Wide, >0.95, Swivel, 3 LED systems, Type 2410-max. 6 mm² term, 110-277 Vac, 127-270 Vdc, 147W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042301005
Product Length/Depth
465 mm
Product Height
607 mm
Product Width
325 mm
Product Weight
24.3 kg
EAN
4251510719227
Area classification
Hazardous/Classified Locations
Standards type
IECEx/ATEX IEC
IECEx/ATEX hazardous rating
Zone 22 Zone 2 Zone 1 Zone 21
Ingress protection (IP) ratings
IP66 IP67
Lamp type
LED
Lumens
15000
Lumens per watt
102
Optical distribution
Wide beam
Color temperature
4000 K
Lens material
Toughened glass
Type
Type 2410 - max. 6 mm² terminals
Entry size
2 x M25 plastic threaded plugs
Wattage
147W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
0.72A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, three LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED IES photometric files
Crouse-Hinds CEAG PXLED IES photometric files
Feature LED illumination delivering 15000 lumens at 4000 K with a wide beam. Business impact reduces energy usage and operational costs versus legacy lighting while maintaining excellent visibility in outdoor process areas. Application ideal for large-area coverage in hazardous locations such as refinery yards and tank farms. Feature 147 W input with 110-277 Vac and 127-270 Vdc capability and PF > 0.95. Business impact provides flexible power sourcing to simplify procurement and minimize spare part needs; Application supports migration from legacy HID systems without compromising compliance. Feature IP66/IP67 ingress protection combined with toughened glass lens. Business impact improves reliability in wet, dusty environments, reducing maintenance cycles and downtime; Application fits offshore platforms and chemical plants. Feature copper-free aluminum housing plus anodized finish. Business impact delivers corrosion resistance and long life in aggressive atmospheres; Application suits outdoor and exposed installations. Feature 2 x M25 plastic entry plugs and Type 2410 terminals up to 6 mm². Business impact enables straightforward wiring and installation; Application supports easy retrofit and serviceability. Feature Swivel bracket and three LED systems. Business impact offers flexible aiming angles and redundancy; Application aids precise mounting in constrained spaces while maintaining uptime.
Get a Quick Quote for a Eaton Crouse-Hinds 13042301005
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042301005?
Enquire Now
FAQs
The PXLED floodlight supports a swivel bracket for adjustable aiming and uses 2 x M25 plastic entry plugs with Type 2410 terminals (max 6 mm²). Installers should observe clearance for heat dissipation, follow hazardous-location wiring practices, and ensure terminals are tight to maintain the PF > 0.95 specification. The unit weighs 24.3 kg and requires robust mounting to withstand vibrations in industrial settings.
The fixture operates at 110-277 Vac and 127-270 Vdc with a frequency of 50-60 Hz, drawing 0.72 A and consuming 147 W. It delivers 15000 lumens at 102 lm/W with a power factor greater than 0.95. Its wide voltage range simplifies power-sourcing from mixed sites, while the high lumen output supports large-area coverage without excessive fixtures.
Yes. The PXLED is certified under IECEx/ATEX for hazardous locations, covering Zones 1 and 2 (gas) and Zones 21 and 22 (dust). This enables safe operation in oil and gas facilities, chemical plants, and mining environments where classification and compliance are critical. Always verify local panel and enclosure ratings to maintain compliance during installation.
IP66/IP67 protection guards against dust ingress and powerful water jets, while toughened glass and an anodized copper-free aluminum housing resist corrosion and impact. These features reduce preventive maintenance needs and extend service life in wet, dusty, and rugged sites such as offshore rigs, refineries, and processing plants.
With a long LED lifespan, high lumen maintenance, and energy efficiency, the PXLED lowers replacement intervals and energy costs compared to legacy solutions. Its robust housing and sealing minimize downtime, while 147 W consumption provides strong illumination with a wide beam, reducing the number of fixtures required for large areas and lowering total cost of ownership.
