Eaton PXLED Floodlight 13042311005 - Zone 1/2 IP66/IP67
Part Number: 13042311005
Quick Summary
Eaton PXLED floodlight provides high-output illumination for hazardous-location industrial facilities. Operators often contend with maintenance downtime and safety risk in challenging environments; this fixture reduces both with rugged ingress protection and IECEx/ATEX compliance. Key certifications include IECEx/ATEX, IP66/IP67, and Zone approvals for hazardous areas, supporting reliable operation in Zone 1, Zone 2, Zone 21 and Zone 22. With long life LED performance and energy-efficient operation, it offers a lower total cost of ownership. The modular design and swivel bracket also streamline installation and ongoing maintenance for project teams.
Product Information
Extended Description
13042311005 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED floodlight, 0.72A, 5700K color temp, 2 x M25 plastic plugs, Glass cover, 15000 lm, 106 lm/W, Anodized copper-free aluminum, Wide beam, >0.95, Swivel bracket, 3 LED systems, 110-277 Vac, 127-270 Vdc, 147W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042311005
Product Length/Depth
465 mm
Product Height
607 mm
Product Width
325 mm
Product Weight
24.3 kg
EAN
4250959981738
Area classification
Hazardous/Classified Locations
Standards type
IEC IECEx/ATEX
IECEx/ATEX hazardous rating
Zone 22 Zone 1 Zone 2 Zone 21
Ingress protection (IP) ratings
IP66 IP67
Lamp type
LED
Lumens
15000
Lumens per watt
106
Optical distribution
Wide beam
Color temperature
5700 K
Lens material
Toughened glass
Entry size
2 x M25 plastic threaded plugs
Wattage
147W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
0.72A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, three LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED IECEx Certificate of Conformity
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED LED LDT photometric files
Crouse-Hinds CEAG PXLED LED LDT photometric files
The PXLED floodlight delivers high lumen output with 15000 lumens at 5700 K and 106 lm/W efficiency, using 147 W of power. This results in enhanced visibility for critical processes while minimizing energy consumption and heat generation. The three LED systems provide redundancy, improving reliability in demanding environments and reducing maintenance calls in hazardous locations. Applications include chemical plants, oil & gas facilities, and mining operations where consistent illumination, dimming resilience, and safe operation are essential. The wide voltage range (110-277 VAC, 127-270 VDC) simplifies stock and installation across global sites, while the IP66/IP67 enclosure and toughened glass lens protect against dust, water ingress, and impact in outdoor or harsh indoor spaces. The anodized copper-free aluminum housing delivers corrosion resistance, extending service life in aggressive atmospheres and reducing replacement costs. The swivel bracket enables precise aiming and quick reorientation without additional hardware, lowering commissioning time and labor costs. Entry is via 2 x M25 plastic threaded plugs, ensuring robust, sealed connections that maintain reliability in explosive zones. Overall, the PXLED is designed to meet stringent standards without compromising on energy efficiency or light quality, supporting safer operations and compliant asset performance.
Get a Quick Quote for a Eaton Crouse-Hinds 13042311005
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042311005?
Enquire Now
FAQs
The PXLED floodlight features a swivel bracket that allows precise aiming and easy orientation after installation, reducing commissioning time. It is designed for robust mounting in Zone 1/2/21/22 environments and supports secure connection via 2 x M25 plastic threaded plugs. This combination simplifies alignment, minimizes downtime, and facilitates serviceability without compromising safety.
Catalog 13042311005 delivers 15000 lumens at 5700 K with a 106 lm/W efficiency, drawing 147 W at 0.72 A. It operates on 110-277 VAC or 127-270 VDC with a 50-60 Hz frequency rating and a power factor above 0.95. The fixture uses toughened glass and aluminum housing, making it suitable for harsh industrial environments.
Yes. The luminaire carries IECEx/ATEX certifications and is rated for hazardous locations across Zones 1, 2, 21, and 22. With IP66/IP67 protection and a rugged construction, it remains compliant and safe for use in chemical plants, oil & gas facilities, mining sites, and other demanding environments.
The PXLED employs long-life LED technology with 15000 lumens and a 57xx K color temperature, delivering lower energy costs and reduced maintenance cycles. Its corrosion-resistant anodized aluminum housing and sealed IP66/IP67 enclosure minimize moisture and dust ingress, extending service life and lowering total cost of ownership over time in harsh locations.
Official installation instructions, IECEx certifications, and product datasheets are available through Eaton’s Crouse-Hinds PXLED resources. Access operating instructions, LDT photometrics, and EU/Russian certificates to ensure proper installation, compliance, and ongoing performance in hazardous environments.
