Eaton Crouse-Hinds PXLED Floodlight - IECEx/ATEX Hazardous Locations
Part Number: 13042410005
Quick Summary
The Eaton Crouse-Hinds PXLED floodlight is a high-performance LED fixture designed for hazardous locations and demanding industrial sites. It solves the challenge of reliable, low-maintenance illumination where downtime costs money. With IECEx/ATEX certification and IP67/IP66 protection, it thrives in dust, water, and harsh atmospheres while maintaining stable brightness. The luminaire delivers up to 20,000 lumens at 5700 K and a PF > 0.95, enabling precise visibility for safety-critical tasks. Its rugged copper-free aluminum housing and swivel bracket streamline installation and service, minimizing maintenance cycles. For engineers and procurement teams, this PXLED floodlight blends energy efficiency with robust compliance, delivering predictable performance and reduced total cost of ownership in hazardous-location projects.
Product Information
Extended Description
13042410005 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED flood, 0.96A, 5700 K color temp, 2xM25 plastic plugs, Glass cover, 20000 lm, 110 lm/W, Anod copper-free alum, Narrow, >0.95, Swivel, 4 LED systems, Type 2410-max. 6mm² term, 110-277Vac, 127-270Vdc, 196W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042410005
Product Length/Depth
465 mm
Product Height
607 mm
Product Width
325 mm
Product Weight
28.7 kg
EAN
4250959981745
Area classification
Hazardous/Classified Locations
Standards type
IECEx/ATEX IEC
IECEx/ATEX hazardous rating
Zone 2 Zone 1 Zone 21 Zone 22
Ingress protection (IP) ratings
IP67 IP66
Lamp type
LED
Lumens
20000
Lumens per watt
110
Optical distribution
Narrow beam
Color temperature
5700 K
Lens material
Toughened glass
Type
Type 2410 - max. 6 mm² terminals
Entry size
2 x M25 plastic threaded plugs
Wattage
196W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
0.96A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, four LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED LED LDT photometric files
Crouse-Hinds CEAG PXLED LED LDT photometric files
LED performance and energy efficiency translate directly into lower operating costs and longer intervals between replacements, while maintaining high-contrast visibility in challenging environments. The PXLED delivers 20,000 lumens at 5700 K with a PF greater than 0.95, enabling reliable area and task lighting in petrochemical plants, refineries, and mining operations, reducing fatigue and improving safety outcomes. The narrow beam distribution concentrates light on critical work zones, minimizing glare and wasted light while supporting compliant illumination levels in confined areas. The IP67/IP66 ingress protection and hazardous-location ratings (Zone 1/2, Zone 21/22) ensure reliable operation under dust, moisture, and corrosive exposure, reducing maintenance calls and extending service life. A rugged copper-free aluminum enclosure, toughened glass lens, and a 465 mm by 607 mm by 325 mm footprint pair with a swivel bracket to simplify mounting and alignment in constrained spaces. Electrical versatility is baked in with 110–277 Vac and 127–270 Vdc operation, 50–60 Hz compatibility, 0.96 A current, and a 196 W power draw, supporting flexible site power architectures and fast commissioning. The 2 x M25 entry plugs and max 6 mm² terminals (Type 2410) enable straightforward field wiring, while four LED systems provide redundancy and fault tolerance in mission-critical lighting scenarios. Overall, the PXLED floodlight lowers total cost of ownership through extended life, robust certifications, and simple maintenance in hazardous environments.
Get a Quick Quote for a Eaton Crouse-Hinds 13042410005
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042410005?
Enquire Now
FAQs
PXLED installation leverages a swivel bracket for flexible aiming and two M25 entry plugs for secure, IP-rated cable entry. Terminations accept up to 6 mm² per connector (Type 2410), and the assembly measures 465 mm long, 607 mm high, and 325 mm wide, with a weight of 28.7 kg. Ensure power wiring matches the 110–277 Vac / 127–270 Vdc range and use appropriate enclosure protection to maintain IECEx/ATEX compliance.
Key performance drivers include 20000 lumens at 5700 K, a high power factor (>0.95), and an energy draw of 196 W at 0.96 A. The LED design offers four LED systems for redundancy, a toughened glass lens, and a copper-free aluminum housing, delivering reliable illumination with long life in Zone 1/2 and Zone 21/22 applications while minimizing maintenance.
Yes. The PXLED is certified under IECEx/ATEX for hazardous locations and provides Zone 1/2 and Zone 21/22 approvals. Its IP67/IP66 ratings protect against dust and immersion, making it suitable for industrial floors, offshore platforms, chemical plants, and other environments where explosion protection and reliability are critical.
Operate within 110–277 Vac or 127–270 Vdc at 50–60 Hz. The unit draws 0.96 A and uses a 196 W power draw. Field wiring uses 2 x M25 plugs with max 6 mm² terminals (Type 2410), supporting straightforward integration with common electrical distribution systems in hazardous locations.
PXLED offers long LED life, high reliability, and rugged construction that reduce replacement cycles and maintenance calls. The combination of high lumens per watt (110 lm/W), robust protection (IP67/IP66), and hazardous-location certifications translates to lower lifecycle costs, improved safety uptime, and predictable budgeting for hazardous-area lighting projects.
