Eaton 13042411005 PXLED Floodlight - IECEx/ATEX Zone 21/22 Hazardous Locations
Part Number: 13042411005
Quick Summary
Eaton's Crouse-Hinds CEAG PXLED floodlight is a high-output LED fixture designed for hazardous locations and demanding industrial environments. Operators face downtime and safety concerns when lighting fails in explosive atmospheres, impacting production schedules and compliance. It carries IECEx/ATEX certifications for Zone 21/22 and Zone 1/2, plus IP66/IP67 protection, ensuring safe operation across harsh ambient conditions. The design combines wide-beam optics, four LED systems, and a copper-free aluminum housing with robust voltage tolerance, delivering energy-efficient illumination and predictable lifecycle costs for 110-277 Vac and 127-270 Vdc deployments in global installations.
Product Information
Extended Description
13042411005 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED floodlight, 0.96A, 5700 K color temp, 2 x M25 plastic plugs, Glass cover, 20000 lm, 106 lm/W, Anodized copper-free aluminum, Wide, >0.95, Swivel, 4 LED systems, 110-277 Vac, 127-270 Vdc, 196W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042411005
Product Length/Depth
465 mm
Product Height
607 mm
Product Width
325 mm
Product Weight
28.7 kg
EAN
4250959981752
Area classification
Hazardous/Classified Locations
Standards type
IECEx/ATEX IEC
IECEx/ATEX hazardous rating
Zone 21 Zone 22 Zone 1 Zone 2
Ingress protection (IP) ratings
IP66 IP67
Lamp type
LED
Lumens
20000
Lumens per watt
106
Optical distribution
Wide beam
Color temperature
5700 K
Lens material
Toughened glass
Entry size
2 x M25 plastic threaded plugs
Wattage
196W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
0.96A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, four LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED EU-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED IES photometric files
Crouse-Hinds CEAG PXLED IES photometric files
Feature → Business Impact → Application: The PXLED floodlight delivers 20000 lumens at 5700 K with a 106 lm/W efficiency, enabling high-visibility work areas while reducing energy consumption; Ideal for plant-wide floodlighting in chemical, oil, and mining facilities. Feature → Business Impact → Application: Wide beam optics and toughened glass lens minimize glare and shadowed zones, improving safety and productivity in large outdoor yards and indoor processing zones. Feature → Business Impact → Application: IP66/IP67 protection combined with IECEx/ATEX Zone 21/22 and Zone 1/2 ratings ensures compliance in hazardous environments, lowering regulatory risk and accelerating project approvals. Feature → Business Impact → Application: Broad voltage support 110-277 Vac and 127-270 Vdc simplifies sourcing and installation, reducing spare part diversity and enabling faster commissioning across multinational sites. Feature → Business Impact → Application: Two M25 plugs and a swiveling bracket facilitate flexible mounting and maintenance access, shortening installation time and enabling retrofits with minimal downtime.
Get a Quick Quote for a Eaton Crouse-Hinds 13042411005
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042411005?
Enquire Now
FAQs
Plan for mounting with the swivel bracket and ensure 2 x M25 plastic plugs are unobstructed for entry. Verify IP66/IP67 protection against dust and water, and confirm Zone 21/22 or Zone 1/2 compliance. Use appropriate cable glands and strain relief to maintain enclosure integrity and permit serviceability without compromising safety.
The fixture accepts 110-277 Vac and 127-270 Vdc at 50-60 Hz, drawing 0.96 A and consuming 196 W. This broad voltage range enables global deployment with fewer transformers or drivers, reduces inventory for spare parts, and supports consistent performance across fluctuating supply conditions.
Yes. It carries IECEx/ATEX certifications for hazardous locations and is rated for Zone 21/22 and Zone 1/2. This broad certification set supports safe operation in explosive atmospheres, enabling installation in chemical plants, oil & gas facilities, and other hazardous environments.
The PXLED provides 20,000 lumens with a color temperature of 5700 K. This combination delivers bright, neutral white light for accurate color rendering and improved task visibility, which is essential for safety-critical industrial processes.
With an LED design, high luminous efficacy (106 lm/W) and a long service life, the PXLED lowers energy consumption and reduces re-lamping cycles. The four LED systems and robust housing minimize downtime, while its wide voltage range and durable aluminum construction simplify ongoing maintenance and retrofit projects.
