Eaton CEAG PXLED Floodlight 13042416005 - IECEx/ATEX Zone 1
Part Number: 13042416005
Quick Summary
PXLED floodlight is a high-output illumination solution for hazardous locations in industrial facilities. A common challenge for engineers is delivering reliable, bright lighting while meeting strict safety and compliance requirements in explosive environments. This luminaire carries IECEx/ATEX certification and Zone 1/21/22 ratings, plus IP66/IP67 ingress protection, enabling safe operation in demanding areas. With 110-277 VAC or 127-270 VDC operation, 20000 lumens and 5700 K color temperature, it delivers consistent performance with energy efficiency. For procurement and maintenance teams, the PXLED supports easy integration with existing controls and scalable lighting strategies that reduce lifecycle costs.
Product Information
Extended Description
13042416005 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED flood, 0.96A, 5700K color temp, 2xM25 plastic plugs, Glass cover, 20000 lm, 102 lm/W, Alum, Asymmetric 2, >0.95, Swivel, 4 LED systems, Type 2410 - max. 6 mm² terminals, 110-277 Vac, 127-270 Vdc, 196W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042416005
Product Length/Depth
465 mm
Product Height
607 mm
Product Width
325 mm
Product Weight
28.7 kg
EAN
4251510758899
Area classification
Hazardous/Classified Locations
Standards type
IECEx/ATEX IEC
IECEx/ATEX hazardous rating
Zone 1 Zone 22 Zone 21 Zone 2
Ingress protection (IP) ratings
IP66 IP67
Lamp type
LED
Lumens
20000
Lumens per watt
102
Optical distribution
Asymmetric 2
Color temperature
5700 K
Lens material
Toughened glass
Type
Type 2410 - max. 6 mm² terminals
Entry size
2 x M25 plastic threaded plugs
Wattage
196W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
0.96A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, four LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED LED LDT photometric files
Crouse-Hinds CEAG PXLED LED LDT photometric files
High lumen output and efficiency drive broader coverage and lower energy costs, delivering up to 20000 lumens at 102 lm/W while maintaining a compact 196 W input. This translates to fewer fixtures to meet area lighting requirements and reduced total cost of ownership in large hazardous zones. The IECEx/ATEX certification and Zone 1/21/22 ratings, combined with IP66/IP67 protection, provide compliance assurance and safer operations in chemical plants, oil & gas facilities, and mining sites, lowering risk and enabling faster project approvals. Durable anodized copper-free aluminum and toughened glass lens withstand harsh industrial environments, extending service life and reducing maintenance cycles. The unit accepts 110-277 VAC or 127-270 VDC and 50-60 Hz, simplifying stock and installation while enabling seamless integration with existing electrical infrastructure. The 2x M25 plastic plugs and Type 2410 terminal block (max 6 mm²) streamline termination and permit straightforward field wiring, while the asymmetric 2 optical distribution and swivel bracket offer precise targeting and easy angle adjustments during commissioning. Four LED systems and 5700 K color temperature ensure consistent, high-contrast illumination essential for precise inspections, critical path work, and safety monitoring in hazardous locations.
Get a Quick Quote for a Eaton Crouse-Hinds 13042416005
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042416005?
Enquire Now
FAQs
This unit is designed for Hazardous/Classified Locations with IECEx/ATEX certification and Zone 1 compatibility. It features IP66/IP67 protection, a robust aluminum housing, toughened glass lens, and a Type 2410 terminal block for up to 6 mm² conductors. For wiring, use the 2 x M25 plastic threaded plugs, and orient the Swivel bracket to ensure optimal light distribution while maintaining safe clearances per local codes.
The PXLED Floodlight delivers 20000 lumens at a color temperature of 5700 K with an efficiency of 102 lm/W. It operates at 196 W, draws 0.96 A, and supports 50-60 Hz. Voltage options are 110-277 VAC or 127-270 VDC, making it compatible with a wide range of industrial power systems and control architectures without compromising performance.
Yes. It supports both AC mains 110-277 VAC and DC 127-270 VDC, across 50-60 Hz. The design includes a 2x M25 plug entry and a Type 2410 terminal block allowing straightforward field wiring. This compatibility simplifies procurement, reduces stocking of multiple variants, and facilitates integration with existing control systems and emergency lighting schemes.
This luminaire is intended for Zone 1 and other hazardous/classified locations, such as oil and gas facilities, chemical plants, and mining operations. Its IP66/IP67 protection and rugged construction enable reliable outdoor and indoor illumination in harsh conditions. The asymmetric 2 optical distribution supports targeted lighting for safe site monitoring, asset protection, and crane or dock areas where precise visibility is critical.
Eaton provides comprehensive documentation, including the CEAG PXLED brochure, UK/Russia/EU declarations of conformity, operating instructions, and photometric files. Access to IECEx/ATEX certificates and installation guides helps with regulatory compliance and safe commissioning. PDF resources support design reviews, installation planning, and ongoing maintenance planning for lifecycle cost reduction.
