Eaton 13042510005 PXLED floodlight - IP66/IP67

High lumen output and efficient optics drive tangible site productivity by reducing the number of fixtures required. The PXLED floodlight delivers 25,000 lumens with a narrow beam, enabling effective area illumination from a minimal footprint and simplifying layout planning. This improved visibility supports safer, faster operations at loading docks and outdoor yards while minimizing hotspots and glare. Power input flexibility supports 110-277 Vac or 127-270 Vdc, delivering plug-and-play compatibility with established plant electrics and reducing wiring complexities. The 1.20 A current draw and 110 lm/W efficiency translate into predictable energy consumption and lower operating costs over the lifecycle. The 5700 K daylight color enhances color rendering for inspections and maintenance tasks across shifts. Industrial-grade housing uses anodized copper-free aluminum and toughened glass, delivering robust corrosion resistance and long-term durability in harsh environments. IP66 and IP67 protection guard against dust ingress, water jets, and immersion scenarios during washdowns or severe weather, minimizing downtime. IECEx/ATEX certification and Zone 1/2/21/22 ratings provide confidence for global installations and compliance audits. Swivel bracket and two M25 plugs enable flexible mounting on walls, poles, or gantries with precise aiming for critical areas. The footprint (465 mm L × 866 mm H × 328 mm W) and weight of 38.5 kg inform installation planning, anchoring methods, and crane-lift considerations on larger projects. Rugged construction reduces service calls and extends productive life in demanding sites. Five LED systems deliver redundancy and uniform distribution across the beam, helping to limit lumen drop and ensure consistent illumination even if one LED array requires servicing. The toughened glass lens minimizes glare while preserving sharp cut-off, and the thermal design maintains performance across outdoor temperature swings. The combination of energy efficiency, long service life, and minimal maintenance lowers total cost of ownership for hazardous-location lighting. From procurement through operation, the PXLED solution aligns with safety, regulatory compliance, and lifecycle cost objectives. Its hazardous-location approvals, robust IP protection, high lumen output, and compatible voltage ranges make it suitable for oil and gas, chemical processing, mining, and heavy manufacturing facilities seeking reliable, regulatory-compliant lighting.
