Eaton 13042611001 PXLED Floodlight - IECEx/ATEX Zone 1/2
Part Number: 13042611001
Quick Summary
Eaton PXLED Floodlight 13042611001 delivers high-output illumination for hazardous locations in industrial plants. Engineers face harsh environments, corrosion, and maintenance downtime that erode productivity; this luminaire addresses those challenges with rugged construction and long life. It carries IECEx/ATEX certification for Zone 1/2 and Zone 21/22, plus IP66/IP67 protection, ensuring safe operation in demanding locations. With a wide voltage range and 30,000 lumens at 5700 K, it enables global deployment while reducing lifecycle costs and maintenance cycles. The design supports flexible installation and energy-efficiency targets, delivering reliable performance in challenging industrial settings.
Product Information
Extended Description
13042611001 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CEAG PXLED floodlight, 1.44A, 5700 K color temp, 2 x M25 metal cable glands, Glass cover, 30000 lm, 106 lm/W, Anodized copper-free alum, Wide, > 0.95, Swivel bracket, 6 LED systems, 110-277 Vac, 127-270 Vdc, 294W
Product Name
Eaton's Crouse-Hinds series CEAG PXLED floodlight
Catalog Number
13042611001
Product Length/Depth
465 mm
Product Height
866 mm
Product Width
328 mm
Product Weight
41.1 kg
EAN
4250959974259
Area classification
Hazardous/Classified Locations
Standards type
IEC IECEx/ATEX
IECEx/ATEX hazardous rating
Zone 1 Zone 2 Zone 22 Zone 21
Ingress protection (IP) ratings
IP67 IP66
Lamp type
LED
Lumens
30000
Lumens per watt
106
Optical distribution
Wide beam
Color temperature
5700 K
Lens material
Toughened glass
Entry size
2 x M25 ADE-1F2 metal cable glands
Wattage
294W
Voltage rating
110-277 Vac, 127-270 Vdc
Frequency rating
50-60 Hz
Amperage Rating
1.44A
Power factor
> 0.95
Material
Anodized copper-free aluminum
Special features
Swivel bracket, six LED systems
Crouse-Hinds series CEAG PXLED Floodlight brochure
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED UK-Declaration of Conformity Certificate
Crouse-Hinds CEAG PXLED operating instructions
Crouse-Hinds CEAG PXLED IES photometric files
Crouse-Hinds CEAG PXLED IES photometric files
LED luminaire delivers 30,000 lm at 5700 K with 106 lm/W efficiency, improving site visibility and safety while reducing energy use and cooling load. This translates to measurable business benefits, including lower energy costs and enhanced compliance with lighting standards in hazardous areas. The PXLED floodlight uses six independent LED systems for redundancy, which means reduced outage risk and easier maintenance planning for critical operations such as refineries and chemical plants. Its rugged anodized copper-free aluminum housing and toughened glass lens withstand harsh environments, extending service life and lowering total cost of ownership. With IP66/IP67 protection and IECEx/ATEX Zone 1/2/21/22 ratings, installation across global facilities is compliant and streamlined. The inclusive 2 x M25 glands and a swivel bracket enable flexible mounting and faster commissioning, even in tight or elevated locations. A wide voltage window supports international projects and simplifies spare-parts inventories for procurement teams, while the high PF (>0.95) and low total harmonic distortion improve power quality for nearby equipment.
Get a Quick Quote for a Eaton Crouse-Hinds 13042611001
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 13042611001?
Enquire Now
FAQs
The PXLED floodlight supports flexible mounting via a swivel bracket and 2 x M25 glands for secure, weathersealed entry. It is certified for Zone 1/2 and Zone 21/22 with IP66/IP67 protection, so installation should ensure enclosure integrity and correct gland sealing to maintain explosion-protection ratings. Use appropriate anti-seize and torque per instructions to avoid compromising ingress protection.
Operating from 110-277 Vac or 127-270 Vdc with a 294 W draw, it delivers about 30,000 lm at 5700 K and a power factor > 0.95. This combination reduces energy use compared with traditional luminaires, lowers cooling loads, and supports tighter energy-performance targets in hazardous-area facilities.
Yes. The luminaire features IP66/IP67 protection and toughened glass, which resist dust intrusion and water ingress in outdoor environments. Zone- and location-classified approvals ensure safe operation in high-risk areas such as manufacturing yards, outdoor staging, and loading zones.
It carries IECEx/ATEX certification with Zone 1/2 and Zone 21/22 ratings, plus IP66/IP67 ingress protection. These certifications support compliance in chemical plants, offshore facilities, and other hazardous locations, enabling global deployment with reduced compliance risk.
Six LED modules provide redundancy, reducing unplanned outages, while the long-life LEDs and copper-free aluminum housing minimize replacement and corrosion costs. The combination of energy efficiency, compliant certifications, and straightforward maintenance lowers total cost of ownership in demanding facilities.
