Eaton Crouse-Hinds PXLED Floodlight 13042611005 - IECEx/ATEX

LED performance starts with a 30,000-lumen LED array at 5700 K, driven by a 294 W module. With a PF greater than 0.95, this design delivers bright, consistent illumination with minimal reactive losses, translating to lower energy costs and less heat in critical spaces. Optical distribution is wide, providing a broad, uniform footprint that reduces the number of fixtures required to cover large outdoor or production areas. This simplifies lighting design, lowers installation time, and minimizes ongoing maintenance needs in harsh environments. Housing uses anodized copper-free aluminum with a toughened-glass lens and IP66/IP67 protection, guarding against dust, water jets, and immersion in challenging conditions. The integrated swivel bracket supports flexible mounting angles, enabling quick alignment during commissioning even in tight spaces. Electrical flexibility is built in with 110-277 VAC and 127-270 VDC operation across 50-60 Hz, accommodating mixed power rails on site. The 1.44 A current draw and robust electrical design support stable operation, even under voltage fluctuations, while 30,000 lumens are delivered at the specified efficiency. Installation advantages include 2 x M25 plastic threaded plugs for clean conduit entries and six LED systems that offer redundancy and easy maintenance. Access to Crouse-Hinds LDT photometric files and IES data lets engineers accurately model performance in daylight calculations. Documentation and compliance are straightforward with IECEx/ATEX certifications, UK DoC, EU certificates, operating instructions, and brochures available for download. This combination of robust safety credentials and practical design improves uptime, simplifies audits, and supports long-term total cost of ownership reductions.
