Eaton Crouse-Hinds 1869B Rotary Switch - IP66
Part Number: 1869B
Quick Summary
The 1869B rotary switch from Eaton Crouse-Hinds is a rugged surface-mounted control for two-gang applications in 120/240 VAC equipment. When panel space is tight and reliability matters, this compact switch lowers maintenance and downtime through durable brass construction and simple wiring. It is rated for ordinary/non-hazardous locations and carries IP66 protection, while supporting 20 A and up to 2 HP at 240 V for flexible motor and accessory control. With Pauluhn heritage and compatibility with the 862/1869/1871 family, it offers dependable installation in industrial automation and marine environments.
Product Information
Extended Description
1869B Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 862/1869/1871 rotary switch, 20A, 1 HP at 120 Vac/2 HP at 240 Vac, Brass, Surface mount, Two-gang, 120/240 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 862/1869/1871 rotary switch
Catalog Number
1869B
Product Length/Depth
5.5 in
Product Height
4.06 in
Product Width
3.13 in
Product Weight
4.5 lb
UPC
662276377738
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Material
Brass
Mounting style
Surface
Voltage rating
120/240 Vac
Amperage Rating
20A
Horsepower
1 hp at 120 V, 2 hp at 240 V
Number of gangs
Two-gang
Pauluhn Marine Rotary Switch catalog page
IF LBL 1511 - 862/1869/1871 Rotary Switch Boxes
Eaton Specification Sheet - 1869B
Brass construction provides corrosion resistance and long service life in wet, dusty, or humid environments, reducing ongoing maintenance costs and downtime. This translates to lower total cost of ownership for remote or harsh panels and improved reliability in conveyor, pump, or equipment controls. The IP66 ingress protection protects critical switch contacts from water and dust ingress, enabling safe operation in washdown zones or outdoor enclosures, while maintaining consistent performance. The surface-mount two-gang form factor saves panel space and simplifies wiring, enabling faster installation and easier future expansion in control cabinets and machinery housings. With a 20 A rating and 1 HP at 120 V / 2 HP at 240 V, the 1869B handles common motor and accessory loads without overspec, improving energy efficiency and reducing switch wear. Compatibility with the Pauluhn 862/1869/1871 family allows straightforward retrofits and replacements, minimizing downtime during upgrades or service. Comprehensive installation resources, including LBL1511 instructions and Eaton data sheets, streamline commissioning and ensure compliance in industrial environments.
Get a Quick Quote for a Eaton Crouse-Hinds 1869B
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 1869B?
Enquire Now
FAQs
Yes. The 1869B is designed for use with the Pauluhn 862/1869/1871 rotary switch family and comes in a surface-mounted, two-gang form factor. Installation can follow the LBL1511 installation sheet, and it fits within standard Pauluhn enclosures. This enables straightforward retrofits and minimizes panel modifications while preserving existing wiring layouts.
The 1869B is rated for 20 A, with a horsepower rating of 1 hp at 120 V and 2 hp at 240 V. This makes it suitable for switching medium-load motors and accessories in general purpose equipment, conveyors, pumps, and localized control circuits without oversizing the switch.
Yes. The unit is certified for Ordinary/Non-Hazardous Locations and carries IP66 ingress protection, offering robust water and dust resistance. This combination supports dependable operation in standard industrial settings, washdown zones, and outdoor panels where moisture or particulate exposure is a concern.
The 1869B features a brass body for durability and corrosion resistance, with a weight of 4.5 lb. Its dimensions are 5.5 in in length, 4.06 in in height, and 3.13 in in width. It is designed as a surface-mount, two-gang rotary switch, balancing robustness with a compact footprint suitable for tight control panels.
Documentation is available through Eaton’s Pauluhn resources: the Pauluhn Marine Rotary Switch catalog page, the LBL1511 installation sheet for 862/1869/1871 boxes, and the Eaton 1869B specification sheet. These documents provide wiring diagrams, mounting details, and compliance information to accelerate commissioning and audits.
