Eaton 2464B-277 Receptacle with Internal Breaker - IP66
Part Number: 2464B-277
Manufacturer
Eaton Crouse-Hinds
Part number
2464B-277
Quick Summary
2464B-277 receptacle with internal breaker delivers reliable power distribution for marine and industrial enclosures. A common pain point is moisture ingress and downtime caused by insufficient protection in harsh environments. This model is IP66-rated and intended for Ordinary/Non-Hazardous Locations, supporting dependable operation in wet or dusty settings. With 30A at 277 Vac, brass construction, and Pauluhn compatibility, it delivers robust performance while reducing maintenance and parts cost. End users gain improved uptime and longer service life for critical power circuits in industrial plants and marine applications.
Product Information
Extended Description
2464B-277 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker, 30A, Three-wire, two-pole, Brass, 277 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker
Catalog Number
2464B-277
Product Length/Depth
7.81 in
Product Height
13.44 in
Product Width
6 in
Product Weight
31.5 lb
UPC
662276378520
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Configuration
Three-wire, two-pole
Amperage Rating
30A
Material
Brass
Voltage rating
277 Vac
Pauluhn Marine Interlock Receptacles with Internal Breaker catalog page
IF LBL 1552 - 246, 247 Watertight Receptacle and Breaker
Eaton Specification Sheet - 2464B-277
Feature: Internal breaker built into the receptacle. Business Impact: Simplifies wiring, reduces external components, and enhances safety—leading to faster maintenance and clearer fault isolation in control panel assemblies. Application: Pauluhn 246/247 series installations in rugged environments where space and reliability matter. Feature: 30A amperage rating at 277 Vac. Business Impact: Supports typical commercial/industrial loads while enabling compact, cost-effective distribution solutions. Application: Enclosures and equipment racks requiring dependable mid-range power delivery. Feature: Three-wire, two-pole configuration. Business Impact: Clear neutrals/grounds separation improves fault detection and compliance; reduces miswiring risk during field installations. Application: Standard power distribution in dry and wet locations. Feature: IP66 ingress protection. Business Impact: High resistance to water and dust ingress minimizes unscheduled downtime and warranty claims. Application: Marine, outdoor, and harsh-processing environments. Feature: Brass material and weight of 31.5 lb. Business Impact: Corrosion resistance and mechanical durability extend service life in corrosive or humid settings; lowers replacement frequency. Application: Long-life receptacles for demanding industrial enclosures. Feature: 277 Vac voltage rating. Business Impact: Aligns with common facility power distribution, enabling safe integration with existing electrical infrastructure. Application: Lighting, motors, and control circuits in commercial and industrial installations.
Get a Quick Quote for a Eaton Crouse-Hinds 2464B-277
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2464B-277?
Enquire Now
FAQs
The 2464B-277 is designed for Pauluhn-series receptacle installations with an internal breaker. It uses a three-wire, two-pole configuration and a brass housing, delivering a robust solution for standard Pauluhn enclosures. While exact mounting patterns vary by enclosure, the unit maintains intended alignment with typical Pauluhn footprints and supports reliable, field-friendly interconnection in industrial and marine applications.
Key specifications include a 30A amperage rating at 277 Vac and a three-wire, two-pole configuration. The brass construction provides durability, while IP66 protection ensures strong ingress protection. Wiring implications focus on proper three-wire connections with neutral and ground paths clearly separated, which supports safe fault isolation and reliable operation in wet or dusty environments.
Yes, the 2464B-277 is rated for Ordinary/Non-Hazardous Locations and features IP66 ingress protection, making it well-suited for marine and other harsh environments where water and dust exposure are concerns. While not intended for hazardous locations, it delivers dependable performance in non-hazardous industrial and marine power-distribution applications.
The model carries IP66 ingress protection and is classified for Ordinary/Non-Hazardous Locations, aligning with common electrical protection and safety requirements for non-hazardous industrial settings. These features support compliance with general electrical protection standards and help minimize downtime due to environmental exposure.
The internal breaker simplifies wiring and fault isolation, reducing maintenance complexity and field wiring errors. By providing built-in safety interlock capabilities, it lowers the risk of downstream equipment damage and downtime, contributing to lower total cost of ownership and a quicker return on investment in continuous-operation environments.
