Eaton Crouse-Hinds 2470B-125 Receptacle - IP66
Part Number: 2470B-125
Manufacturer
Eaton Crouse-Hinds
Part number
2470B-125
Quick Summary
2470B-125 receptacle is a rugged, watertight four-wire, three-pole connector for industrial and marine power applications. In harsh environments, moisture intrusion and unreliable connections drive costly downtime. Key protections include IP66 ingress protection and suitability for Ordinary/Non-Hazardous Locations, with an internal breaker for overload protection. The brass construction and Pauluhn compatibility support long service life while delivering safe, code-compliant power distribution. This makes it a practical choice for manufacturers and maintenance teams seeking reliability and cost efficiency in demanding facilities.
Product Information
Extended Description
2470B-125 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker, 15A, Four-wire, three-pole, Brass, 125 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker
Catalog Number
2470B-125
Product Length/Depth
7.81 in
Product Height
13.44 in
Product Width
6 in
Product Weight
31.5 lb
UPC
662276378605
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Configuration
Four-wire, three-pole
Amperage Rating
15A
Material
Brass
Voltage rating
125 Vac
Pauluhn Marine Interlock Receptacles with Internal Breaker catalog page
IF LBL 1552 - 246, 247 Watertight Receptacle and Breaker
Eaton Specification Sheet - 2470B-125
Feature → IP66 ingress protection and brass construction deliver rugged, corrosion-resistant performance in washdown and outdoor locations. Business impact → Reduces maintenance cycles and downtime, protecting downstream equipment and lowering total cost of ownership. Application → Suitable for marine interlock receptacles and industrial power drops where water, dust, and vibration are concerns. Feature → Internal breaker provides local overload protection integrated into the receptacle. Business impact → Shrinks panel space and simplifies wiring, improving safety and response times. Application → Fits Pauluhn 246/247 configurations in compact power distribution setups. Feature → 15A, 125 Vac four-wire, three-pole configuration ensures compatibility with common industrial equipment. Business impact → Reduces need for adapters and helps standardize installations across facilities. Application → Ideal for Pauluhn 246/247 series deployments in ordinary locations with reliability requirements. Feature → Pauluhn compatibility and brass construction extend service life in harsh environments. Business impact → Delivers predictable performance with reduced maintenance costs over the equipment lifecycle. Application → Particularly beneficial for marine/interlock receptacle applications and outdoor industrial areas in non-hazardous locations.
Get a Quick Quote for a Eaton Crouse-Hinds 2470B-125
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2470B-125?
Enquire Now
FAQs
Installation requires using the four-wire, three-pole configuration with the internal breaker specified for Pauluhn 246/247 receptacles. Follow Eaton’s LBL1552 guidance for watertight assembly and ensure proper sealing to achieve IP66 performance. The Pauluhn catalog page provides compatibility context, and the installation sheet offers step-by-step instructions to minimize leakage paths and maximize safety.
The unit is rated for 15A at 125 Vac with a four-wire, three-pole configuration. Its internal breaker provides local overload protection, reducing external protection requirements. This combination supports dependable power distribution for standard industrial loads while maintaining compliance in ordinary/non-hazardous locations.
Yes. The receptacle carries IP66 ingress protection, making it well-suited for washdown, outdoor, and marine interlock applications. Its brass construction adds corrosion resistance, and the internal breaker helps safeguard equipment in challenging environments, supporting reliable performance in shipboard and other wet locations.
The product is specified for Ordinary/Non-Hazardous Locations and features IP66 ingress protection. These designations indicate suitability for general industrial environments without hazardous ratings, ensuring safe operation in typical factory, outdoor, or marine-adjacent spaces.
The internal breaker offers localized overload protection, reducing the need for external fusing or breakers and simplifying wiring. This can shorten maintenance cycles, lower wiring complexity, improve response times to electrical faults, and extend equipment uptime by preventing nuisance trips in critical Pauluhn applications.
