Eaton Crouse-Hinds 2472B-125 Receptacle - IP66
Part Number: 2472B-125
Manufacturer
Eaton Crouse-Hinds
Part number
2472B-125
Quick Summary
2472B-125 receptacle provides internal-breaker protection for 125 VAC equipment in rugged industrial settings. Engineers often battle nuisance trips, corrosion, and space constraints in control panels. With IP66 ingress protection and an ordinary/non-hazardous area rating, this Pauluhn receptacle is built for tough environments. Its brass construction and four-wire, three-pole configuration support robust, code-compliant installations across marine, outdoor, water-treatment, and manufacturing applications. The internal breaker reduces external components and simplifies wiring, while the heavy-duty enclosure withstands washdown and vibration. In practice, this design translates to faster installation, lower maintenance costs, and improved safety margins in harsh locations.
Product Information
Extended Description
2472B-125 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker, 20A, Four-wire, three-pole, Brass, 125 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker
Catalog Number
2472B-125
Product Length/Depth
7.81 in
Product Height
13.44 in
Product Width
6 in
Product Weight
31.5 lb
UPC
662276378636
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Configuration
Four-wire, three-pole
Amperage Rating
20A
Material
Brass
Voltage rating
125 Vac
Pauluhn Marine Interlock Receptacles with Internal Breaker catalog page
IF LBL 1552 - 246, 247 Watertight Receptacle and Breaker
Eaton Specification Sheet - 2472B-125
Feature IP66 protection delivers reliable performance in wet, dusty, and high-pressure washdown environments. Business Impact Seals against dust and water intrusion, reducing downtime and arcing risk; Application outdoor enclosures, docks, and offshore equipment where uptime matters. Feature Internal breaker reduces panel footprint and wiring complexity. Business Impact Simplifies protection schemes and minimizes nuisance trips, lowering maintenance time and spare parts needs; Application remote pumps, lighting, and process equipment. Feature Four-wire, three-pole configuration provides dedicated grounding and neutral paths. Business Impact Improves fault tolerance and code compliance for clean motor-control circuits; Application marine and industrial control panels. Feature Brass construction offers corrosion resistance and long life in humid or washdown environments. Business Impact Extends service intervals and lowers maintenance costs in salt-rich or harsh environments; Application coastal facilities and washdown-rated equipment. Feature Robust enclosure with substantial weight supports vibration resistance and secure mounting. Business Impact Reduces wear on mating connectors and improves overall installation reliability; Application heavy-duty industrial panels and shipboard applications.
Get a Quick Quote for a Eaton Crouse-Hinds 2472B-125
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2472B-125?
Enquire Now
FAQs
Plan panel cutouts to accommodate the 7.81 in depth, 13.44 in height, and 6 in width while supporting the brass body. Use proper sourcing per Pauluhn catalogs, ensure IP66 seals are intact, and connect four wires for four-wire, three-pole operation. Follow the LBL1552 instructions for watertight installation.
The internal breaker provides immediate overcurrent protection at the receptacle, reducing the need for external fuses or breakers. This simplifies wiring diagrams and reduces panel complexity while maintaining 20 A at 125 VAC. It improves nuisance-trip resistance and enables faster, safer isolation during maintenance or fault conditions in rugged industrial environments.
Yes, its IP66 rating and brass construction are designed for harsh environments, including marine and outdoor facilities. The ordinary/non-hazardous area classification supports safe installation in non-hazardous locations, while the watertight features reduce ingress during washdowns. Ensure proper mounting and sealing per LBL1552 instructions.
This receptacle carries IP66 ingress protection and falls under Ordinary/Non-Hazardous Locations, aligning with general industrial compliance. These certifications ensure reliable performance against dust and water for non-hazardous facilities, enabling safe operation in typical plants, outdoor sites, or shipboard environments. The Pauluhn lineage also supports compatibility with existing 246/247 series installations.
By consolidating protection and wiring into a single unit, maintenance time is reduced and spare parts inventory simplified. The robust brass body, IP66 sealing, and built-in breaker diminish failure rates in demanding locations, lowering downtime costs and extending service intervals in industrial or marine applications.
