Eaton Crouse-Hinds 2472B-250 Receptacle - IP66 250V
Part Number: 2472B-250
Manufacturer
Eaton Crouse-Hinds
Part number
2472B-250
Quick Summary
The Eaton Crouse-Hinds 2472B-250 receptacle delivers rugged, weatherproof power delivery for industrial and marine applications. In harsh environments, installation reliability and protection against water ingress are common pain points that can drive downtime and maintenance costs. This model leverages IP66 protection and a four-wire, three-pole configuration to meet demanding safety and performance requirements in ordinary or non-hazardous locations. By combining a brass/brass-alloy body with an internal breaker, it simplifies wiring, reduces panel space, and supports safer, code-compliant connectivity. For engineers and procurement professionals, this receptacle offers a dependable, long-term solution that aligns with maintenance schedules and uptime targets while supporting 250 V AC circuits and heavy-duty usage scenarios.
Product Information
Extended Description
2472B-250 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker, 20A, Four-wire, three-pole, Brass, 250 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker
Catalog Number
2472B-250
Product Length/Depth
7.81 in
Product Height
13.44 in
Product Width
6 in
Product Weight
31.5 lb
UPC
662276378643
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Configuration
Four-wire, three-pole
Amperage Rating
20A
Material
Brass
Voltage rating
250 V AC
Pauluhn Marine Interlock Receptacles with Internal Breaker catalog page
IF LBL 1552 - 246, 247 Watertight Receptacle and Breaker
Eaton Specification Sheet - 2472B-250
Feature: Four-wire, three-pole configuration enables correct grounding and phasing for safer, more reliable power distribution. Business Impact: Reduces miswiring risk and improves personnel safety during panel assembly and maintenance. Application: Ideal for Pauluhn 246/247 receptacle installations in industrial control panels and marine environments.Feature: Internal breaker provides localized protection without extra external devices. Business Impact: Cuts installation time and lowers total cost of ownership by simplifying wiring and fault isolation. Application: Suitable for 20A circuits in harsh locations where quick fault response is essential.Feature: IP66 ingress protection and brass construction offer superior water and dust resistance. Business Impact: Extends equipment life in wet, dusty environments and minimizes corrosion-related failures. Application: Marine interlock receptacles and other exterior or wet-area installations.Feature: 250 V AC rating supports standard industrial power distribution while maintaining compact form. Business Impact: Enables compatibility with a wide range of equipment and controls, improving compatibility and inventory management. Application: Used in industrial automation, machinery, and field power distribution where robust voltage support is required.Feature: Heavy-duty Pauluhn design delivers durability in ordinary/non-hazardous locations with reliable performance. Business Impact: Improves uptime, reduces maintenance cycles, and supports long service intervals. Application: Suitable for control panels, weather-exposed installations, and demanding industrial settings where reliability matters.
Get a Quick Quote for a Eaton Crouse-Hinds 2472B-250
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2472B-250?
Enquire Now
FAQs
Installation requires a four-wire, three-pole connection to ensure proper grounding and phasing. Use the internal breaker to provide localized protection and connect the brass body to a secure panel mounting location rated for IP66 environments. Verify seal integrity and conduct periodic inspections to maintain water ingress protection in marine settings.
The 2472B-250 is rated for 20A at 250V AC and configured as four-wire, three-pole with brass construction. These specifications support safe operation of typical industrial loads, enable robust grounding and fault isolation, and ensure compatibility with standard 250V equipment. The IP66 rating provides protection against dust and powerful water jets, enhancing reliability in harsh environments.
Yes. The four-wire, three-pole configuration is designed to deliver safe, isolated power with proper grounding for industrial and marine environments. Coupled with IP66 protection and an internal breaker, it maintains performance in wet, dusty, or exterior installations while simplifying wiring and maintenance tasks.
This receptacle is rated for Ordinary/Non-Hazardous Locations, aligning with common facility safety standards. The IP66 ingress protection rating helps ensure dust and water resistance in non-hazardous settings, while the four-wire, three-pole arrangement supports compliant, safe wiring practices in standard industrial environments.
An internal breaker reduces the need for external protection and simplifies wiring, cutting installation time and panel space. This can lower maintenance costs by reducing fault-finding complexity and improving uptime, particularly in demanding marine or industrial environments where reliable, quick fault isolation is critical.
