Eaton Crouse-Hinds 2474B-125 Receptacle - IP66
Part Number: 2474B-125
Manufacturer
Eaton Crouse-Hinds
Part number
2474B-125
Quick Summary
Eaton Crouse-Hinds 2474B-125 receptacle is a four-wire, three-pole power outlet designed for 30A, 125V service in industrial environments. Engineers often struggle to source a rugged, enclosure-rated device that combines reliable internal protection with straightforward installation in damp or outdoor locations. This model carries IP66 ingress protection and is approved for Ordinary/Non-Hazardous Locations, ensuring safe operation where exposure to dust and moisture is a concern. By integrating a compact, brass-bodied design with an internal breaker, it helps reduce wiring complexity and maintenance costs, supporting scalable, compliant installations for process, marine, and outdoor power distribution.
Product Information
Extended Description
2474B-125 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker, 30A, Four-wire, three-pole, Brass, 125 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 246/247 receptacle with internal breaker
Catalog Number
2474B-125
Product Length/Depth
7.81 in
Product Height
13.44 in
Product Width
6 in
Product Weight
31.5 lb
UPC
662276378667
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Configuration
Four-wire, three-pole
Amperage Rating
30A
Material
Brass
Voltage rating
125 Vac
Pauluhn Marine Interlock Receptacles with Internal Breaker catalog page
IF LBL 1552 - 246, 247 Watertight Receptacle and Breaker
Eaton Specification Sheet - 2474B-125
IP66 protection and internal breaker deliver tangible business value; this combination keeps dust and moisture out of critical connections, reducing field failures and service interruptions in outdoor and harsh environments. Four-wire, three-pole configuration simplifies grounding and neutral wiring, enabling faster installations and more consistent electrical layouts across distributed equipment and remote skids. Brass construction provides durability and corrosion resistance, extending service life in marine, chemical, or high-humidity facilities while lowering replacement costs. The 30A, 125V rating aligns with common industrial loads, reducing panel space requirements and the need for multiple devices in power distribution panels. Pauluhn interlock compatibility with internal breaker supports modular installations, enabling scalable safety upgrades and easier retrofit in existing Pauluhn-based systems. The Ordinary/Non-Hazardous location classification lowers compliance and installation risk, helping teams meet plant standards without unnecessary overdesign.
Get a Quick Quote for a Eaton Crouse-Hinds 2474B-125
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2474B-125?
Enquire Now
FAQs
The 2474B-125 is designed for seamless pairing with Pauluhn Marine Interlock Receptacles that share the same four-wire, three-pole configuration. Its internal breaker simplifies wiring by providing branch protection within the receptacle itself, reducing panel space and neutral/ground routing complexity. For retrofit projects, verify enclosure dimensions (7.81 in depth, 13.44 in height) and confirm interlock compatibility with existing Pauluhn modules before installation.
Key specs include a 30A amperage rating at 125Vac, a four-wire, three-pole configuration, brass construction, and IP66 ingress protection. The Ordinary/Non-Hazardous Location classification indicates suitability for standard industrial environments without hazardous-area credentials. In outdoor or damp locations, rely on the IP66 rating and enclosure integrity to minimize moisture ingress and maintain reliable operation.
Yes. The product designation under Pauluhn Marine Interlock Receptacles with Internal Breaker signals intended use in marine and rugged industrial settings. Its brass body and IP66 rating provide corrosion resistance and weatherproofing essential for vessels or offshore installations, while the internal breaker supports integrated protection within existing interlock schemes.
The model features IP66 ingress protection and an Ordinary/Non-Hazardous Location classification, aligning with common industrial safety and environmental requirements. While exact third-party listings like UL/CE aren’t listed in the provided data, these designations indicate suitability for standard industrial and marine environments. Always verify with your facility’s compliance team and local electrical codes for site-specific approvals.
The internal breaker provides overcurrent protection at the receptacle level, reducing wiring complexity, panel space, and field wiring time. This can translate to lower labor costs during installation and fewer components to stock and maintain. In high-vibration or damp environments, built-in protection also lowers nuisance trips and unplanned downtime, contributing to improved uptime and total cost of ownership.
