Eaton Crouse-Hinds 2636B-250 Receptacle - 20A, 250V
Part Number: 2636B-250
Quick Summary
The Eaton Crouse-Hinds 2636B-250 receptacle is a rugged surface-mounted three-receptacle unit designed for 20A at 250V AC in industrial panels and general electrical installations. For engineers and procurement teams, the challenge is delivering reliable, easy-to-wire power distribution that survives daily use without complicating installation. It carries Ordinary/Non-Hazardous Locations area classification, aligning with common non-hazardous environments while supporting durable Brass construction and Pauluhn compatibility. This combination reduces downtime and maintenance cost, improves stock efficiency, and enables faster field service. In addition to core three-receptacle functionality, the design supports seamless integration with Pauluhn series components for scalable, modular wiring solutions in industrial facilities.
Product Information
Extended Description
2636B-250 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 263/264 receptacle, 20A, Three-wire, two-pole, Brass, Surface,Three receptacles, 250 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 263/264 receptacle
Catalog Number
2636B-250
Product Length/Depth
4.75 in
Product Height
3.75 in
Product Width
8.5 in
Product Weight
7.4 lb
UPC
662276380929
Area classification
Ordinary/Non-Hazardous Locations
Material
Brass
Configuration
Three-wire, two-pole
Mounting method
Surface
Type
Three receptacles
Amperage Rating
20A
Voltage rating
250 V AC
Pauluhn Marine Pin and Sleeve Receptacles and Plugs catalog page
IF LBL 1506 - 263 Marine Pin and Sleeve Plugs and Connectors
Eaton Specification Sheet - 2636B-250
Feature: Brass construction provides superior corrosion resistance and durability in harsh industrial environments → Business Impact: Longer service life reduces replacement costs and maintenance intervals → Application: Ideal for Pauluhn 263/264 receptacle installations in control panels and equipment enclosures. Feature: Surface mounting simplifies retrofits and new builds → Business Impact: Cuts installation time and labor costs while preserving existing footprints → Application: Quickly deploy in electrical rooms and non-hazardous locations. Feature: Three-wire, two-pole configuration ensures reliable, code-compliant power distribution → Business Impact: Improves electrical safety and reduces wiring complexity → Application: Suitable for standard 20A circuits in industrial facilities. Feature: 250 V AC, 20A rating meets typical US industrial power systems → Business Impact: Minimizes need for part substitutions during upgrades → Application: Compatible with common 250V systems in service panels. Feature: Pauluhn series compatibility with surface-mount brass receptacles → Business Impact: Streamlines procurement and maintenance across marine and non-marine environments → Application: Supports scalable power distribution in equipment housings and control stations. Additional notes: The unit’s weight and dimensions (4.75 in L, 3.75 in H, 8.5 in W; 7.4 lb) inform enclosure sizing and mounting clearances, aiding accurate BOM planning and installation scheduling. Long-tail keywords integrated: Pauluhn 263/264 receptacle, surface-mounted receptacle, brass receptacle, 20A 250V AC receptacle, ordinary locations electronics, three-receptacles configuration, three-wire two-pole electrical outlet.
Get a Quick Quote for a Eaton Crouse-Hinds 2636B-250
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2636B-250?
Enquire Now
FAQs
To install the 2636B-250, verify the circuit is rated for 20A at 250V and the location is Ordinary/Non-Hazardous. Mount the brass receptacle on a suitable surface, align with the panel cutout, and secure with the provided mounting hardware. Connect the three-wire, two-pole wiring per standard electrical diagrams, then test continuity and insulation before energizing the circuit. This approach minimizes rework and ensures reliable operation in non-hazardous environments.
The 2636B-250 is a 20A, 250V AC receptacle configured as three-wire, two-pole with brass construction. It is designed for surface mounting and supports three receptacles in a Pauluhn-compatible format. Dimensions include approximately 4.75 in in length, 3.75 in in height, and 8.5 in in width with a weight around 7.4 lb, suitable for ordinary locations.
This model is part of the Pauluhn series and is specified for Ordinary/Non-Hazardous Locations, making it well-suited for standard industrial or commercial panels in non-hazardous environments. For marine or outdoor use, verify additional environmental ratings or enclosures. If corrosion resistance and rugged moisture sealing are critical, consult Pauluhn product literature for compatible options with enhanced sealing or IP ratings.
The 2636B-250 lists Area classification as Ordinary/Non-Hazardous Locations, indicating suitability for standard commercial and industrial environments. This aligns with Pauluhn series design intent for reliable, non-hazardous operation. When selecting for a project, confirm any site-specific electrical code requirements and ensure the installation follows applicable local regulations and safety standards.
The brass construction offers durable corrosion resistance, extending service life and reducing maintenance frequency in industrial settings. Its surface-mount design simplifies retrofits and replacements, lowering downtime during upgrades. By adopting Pauluhn 2636B-250, facilities benefit from standardized parts, faster procurement, and predictable performance across panels, control stations, and equipment housings, improving overall return on investment through reduced maintenance and stock complexity.
