Eaton 2705PL-125 Receptacle - NEMA 5-15/20R, 125V
Part Number: 2705PL-125
Quick Summary
2705PL-125 is a surface-mounted, double receptacle delivering 15A/20A at 125 Vac for industrial control panels. Installing in rugged environments often demands quick, corrosion-resistant and space-efficient solutions. This unit supports ordinary/non-hazardous area classifications and standard NEMA 5-15/20R outlets, helping you stay compliant while simplifying procurement. Its non-metallic construction and surface-mount design translate to faster installations, lower maintenance, and reliable performance in everyday panel applications across manufacturing, processing, and automation environments. Engineers appreciate the compact footprint and predictable polarity, which reduces wiring errors and streamlines spare-part inventories. This combination translates to reduced downtime and faster project timelines in critical plant upgrades.
Product Information
Extended Description
2705PL-125 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 27R receptacle, 15A/20A, Non-metallic, Surface, 5-15/20R, One rectangular face double receptacle, 125 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 27R receptacle
Catalog Number
2705PL-125
Product Length/Depth
2.75 in
Product Height
4.5 in
Product Width
1.75 in
Product Weight
0.7 lb
UPC
662276381438
Area classification
Ordinary/Non-Hazardous Locations
Material
Non-metallic
Type
One rectangular face double receptacle
Amperage Rating
15A/20A
Voltage rating
125 Vac
NEMA configuration
5-15/20R
Mounting method
Surface
Pauluhn Marine Interior ANSI NEMA Receptacles catalog page
IF LBL 1557 - 27 and 27B Receptacles and Switches
Eaton Specification Sheet - 2705PL-125
Versatile electrical rating and configuration provide 15A/20A at 125 Vac with a NEMA 5-15/20R footprint, enabling plug-and-play compatibility with common industry devices and reducing the need for adapters in control panels. This directly improves procurement efficiency and minimizes field rework during panel builds. Surface mounting and the Pauluhn 27R design offer fast retrofits in existing enclosures, shortening installation time and lowering labor costs while preserving enclosure aesthetics and integrity. The non-metallic housing delivers corrosion resistance and electrical insulation in non-hazardous environments, boosting safety margins and reducing maintenance cycles. With a compact footprint (2.75 in L x 4.5 in H x 1.75 in W) and light 0.7 lb weight, this receptacle fits crowded panels and simplifies shipment and stocking. Its ordinary-location suitability aligns with standard panel practices, supporting streamlined sourcing and consistent part numbers across projects. Comprehensive documentation supports installation, compliance, and future upgrades, reducing risk during deployment.
Get a Quick Quote for a Eaton Crouse-Hinds 2705PL-125
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2705PL-125?
Enquire Now
FAQs
The 2705PL-125 uses surface mounting and is designed for Pauluhn 27R style enclosures in ordinary, non-hazardous locations. This configuration enables rapid retrofits in control panels and other industrial housings, while maintaining a clean, unobtrusive profile inside compact enclosures.
The receptacle provides 15A/20A at 125 Vac and employs the standard NEMA 5-15/20R configuration. This ensures compatibility with common plug types used in factory automation, machinery, and panel installations, reducing the need for adapters or additional hardware.
The product is specified for Ordinary/Non-Hazardous Locations, making it appropriate for typical factory floors, offices, and non-hazardous enclosures. While the Pauluhn catalog page references marine interior applications, this specific model targets ordinary-location environments and standard electrical distribution within industrial panels.
The non-metallic construction provides corrosion resistance and improved insulation in humid or wet environments, while surface mounting simplifies installation, reduces panel prep, and speeds up maintenance; technicians can replace or upgrade units with minimal downtime and little special hardware, supporting higher overall equipment efficiency.
Official resources include the Pauluhn catalog page for 27R receptacles, installation sheets such as IF LBL 1557 for 27/27B models, and the Eaton specification sheet for 2705PL-125. These documents guide correct mounting, wiring, and compliance with non-hazardous location requirements, improving installation accuracy and traceability.
