Eaton Crouse-Hinds 2716B Toggle Switch - 120 Vac
Part Number: 2716B
Quick Summary
The 2716B toggle switch from Eaton Crouse-Hinds is a pilot-light control device designed for surface mounting in industrial control panels. Engineers often face space constraints and demand clear signaling without complicating panel wiring. This model is rated for Ordinary/Non-Hazardous Locations, aligning with common plant environments and safety practices. With a compact brass construction and a single-pole design, it delivers reliable operation while minimizing installation time. Designed for 120 V systems and 15 A circuits, it helps keep maintenance schedules predictable and downtime low. This combination of signaling reliability and straightforward installation supports faster project rollout and reduced field errors.
Product Information
Extended Description
2716B Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 27S toggle switch, 15A, Brass, Surface mount, Single-pole, Pilot light, One single-pole switch and pilot light, 120 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 27S toggle switch
Catalog Number
2716B
Product Length/Depth
2.75 in
Product Height
4.5 in
Product Width
1.75 in
Product Weight
2 lb
UPC
662276381582
Area classification
Ordinary/Non-Hazardous Locations
Material
Brass
Number Of Poles
Single-pole
Type
One single-pole switch and pilot light
Amperage Rating
15A
Voltage rating
120 Vac
Mounting style
Surface
Special features
Pilot light
Pauluhn Interior Toggle Switch catalog page
IF LBL 1557 - 27/27B Receptacles and Switches
Eaton Specification Sheet - 2716B
Brass construction provides durability in demanding panels, resisting wear from frequent operation and rough handling. That rugged build translates to longer life in high-use control stations and reduces maintenance costs over time. Surface mounting simplifies installation by eliminating additional chassis cutouts and brackets. This approach speeds up commissioning and minimizes field errors when wiring pilot light circuits. The integrated pilot light delivers immediate status indication, improving operator awareness and troubleshooting. With a single-pole configuration, it clearly signals one control channel without complicating wiring. Rated for 15A at 120V, it supports common lighting and control loads without overloading the circuit. That electrical margin helps maintain performance in standard plant applications. Compact dimensions—2.75 in length, 4.5 in height, 1.75 in width—fit standard Pauluhn interior cutouts and panel depths. Proportional weight of about 2 lb provides sturdy actuation while keeping panel mass balanced. Compatibility with the Pauluhn 27S family means installers can reuse existing mounting footprints and harnesses. That reduces part proliferation and streamlines procurement.
Get a Quick Quote for a Eaton Crouse-Hinds 2716B
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2716B?
Enquire Now
FAQs
The 2716B is engineered for surface mounting with standard Pauluhn interior footprints and a compact 2.75 in L x 4.5 in H x 1.75 in W profile. This simplifies retrofit projects and minimizes required chassis modifications, making it ideal for existing control cabinets and new panel builds alike.
This model provides a 15A amperage rating at 120 Vac, suitable for typical lighting and control loads in industrial panels. Its single-pole design keeps switching simple and predictable, reducing the risk of overloads on shared circuits.
Yes. The 2716B is specified for Ordinary/Non-Hazardous Locations, aligning with standard plant environments and safety practices. This makes it a reliable choice for general-purpose signaling and control in non-hazardous industrial settings.
You can access the Pauluhn Interior Toggle Switch catalog page, LBL1557 installation sheets, and the Eaton specification sheet for 2716B through Eaton’s official resources. These documents provide wiring diagrams, mechanical dimensions, and mounting instructions to support compliant installation.
The 2716B combines durable brass construction with a pilot-light indicator and surface-mount convenience, delivering reliable signaling and faster commissioning. This reduces maintenance downtime, minimizes field wiring errors, and supports repeatable procurement within Pauluhn 27S-compatible panels, contributing to lower total cost of ownership.
