Eaton 2753BF-125 Receptacle - 15A 125V Flush Mount
Part Number: 2753BF-125
Quick Summary
2753BF-125 Receptacle by Eaton provides a rugged 15A, 125V flush-mount power outlet for industrial control panels. Engineers often struggle with moisture, corrosion, and non-standard mounting in harsh environments, which can lead to costly downtime. This Pauluhn 27R receptacle is suitable for Ordinary/Non-Hazardous Locations and uses brass construction for durability, while the flush-mount design minimizes interference and installation complexity. The compact form factor, 2.75 in depth, and single round-face receptacle design support efficient enclosure layouts, reducing field wiring errors and accelerating panel builds. By combining reliability with straightforward installation, it delivers measurable business value through reduced maintenance and improved uptime in standard industrial facilities.
Product Information
Extended Description
2753BF-125 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 27R receptacle, 15A, Single, Brass, Flush mount unit, One round face single receptacle, 125 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 27R receptacle
Catalog Number
2753BF-125
Product Length/Depth
2.75 in
Product Height
4.5 in
Product Width
1.75 in
Product Weight
2 lb
UPC
662276382213
Area classification
Ordinary/Non-Hazardous Locations
Material
Brass
Type
One round face single receptacle
Amperage Rating
15A
Voltage rating
125 Vac
Cover type
Single
Special features
Flush mount unit
Pauluhn Marine Interior ANSI NEMA Receptacles catalog page
IF LBL 1557 - 27 and 27B Receptacles and Switches
Eaton Specification Sheet - 2753BF-125
Feature: 15A, 125V electrical rating; Business Impact: supports standard equipment loads with proven reliability, reducing circuit overloading risks and costly downtime; Application: control panels and enclosures in non-hazardous environments. Feature: Brass material; Business Impact: offers corrosion resistance and long-term durability, lowering replacement and maintenance costs; Application: damp or humid plant areas and marine interiors where durability matters. Feature: Flush-mount design; Business Impact: minimizes protrusions for safer, easier assembly and reduced enclosure footprint; Application: tight control panels and equipment cabinets with restricted clearance. Feature: One round face single receptacle; Business Impact: simplifies wiring and maintenance, lowering labor time and error potential; Application: compact electrical outlets inside industrial enclosures. Feature: Ordinary/Non-Hazardous Locations classification; Business Impact: simplifies compliance and procurement for typical factory floors, improving project timelines; Application: standard facility installations without hazardous environments. The combination of these features supports faster installation, predictable performance, and a lower total cost of ownership for electrical distribution in industrial settings.
Get a Quick Quote for a Eaton Crouse-Hinds 2753BF-125
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 2753BF-125?
Enquire Now
FAQs
The 2753BF-125 is designed as a single-face, round-receptacle Pauluhn 27R unit intended for flush-mount installation in standard industrial enclosures. It aligns with conventional 27R face dimensions and panel cutouts, enabling straightforward retrofits or new builds in ordinary, non-hazardous locations. When selecting enclosures, ensure door clearance and mounting hardware accommodate the 2.75 in depth and 4.5 in height for proper serviceability and wiring access.
This receptacle is rated for 15A at 125V, with brass construction and a single round-face receptacle. It supports standard 125Vac circuits and is intended for flush-mount installations inside electrical panels or control enclosures. The configuration simplifies wiring and keeps contact interfaces consistent with other Pauluhn 27R receptacles, aiding in predictable performance across installed bases.
The product is classified for Ordinary/Non-Hazardous Locations, indicating suitability for typical factory floors and non-hazardous zones. It is not specified for marine-specified or hazardous-area environments. For marine interiors or higher-risk settings, consult Eaton’s marine interior or hazardous-location variants and the associated installation guidelines to ensure proper protection and compliance.
Flush-mount design minimizes protrusions, reducing snag risk and allowing denser enclosure layouts. It also simplifies interior wiring routes and improves enclosure aesthetics, which can speed up commissioning and maintenance. In addition, brass construction enhances durability in humid or damp environments, contributing to longer service life and lower replacement costs in routine maintenance cycles.
Brass construction provides corrosion resistance, reducing wear in steady-state operation and extending mean time between maintenance. The standard 125V/15A rating supports common automation loads, enabling predictable performance with minimal rewiring. The flush-mount configuration reduces maintenance access time and potential damage during servicing, contributing to lower lifecycle costs and quicker return on investment for panel hardening projects.
