Eaton Crouse-Hinds 426PC-480 Plug & Connector - IP66
Part Number: 426PC-480
Quick Summary
426PC-480 is a rugged plug and connector for 480 Vac power in industrial deployments. Mismatched parts and harsh washdowns often cause downtime and safety risk on busy production floors. This unit features IP66 ingress protection and is suited for Ordinary/Non-Hazardous locations, aligning with the Pauluhn series expectations for reliable field connections. In addition to its robust build, it integrates easily with 420FC/PP/PC mating plugs, enabling faster installation and standardized spare parts. These benefits translate to lower maintenance costs and higher system uptime, making it a strong choice for engineers and procurement teams seeking dependable power distribution in manufacturing and processing facilities.
Product Information
Extended Description
426PC-480 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 420FC/PP/PC plug and connector, 20A, 3-wire, 2-pole, ABS/Polycarbonate, 480 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 420FC/PP/PC plug and connector
Catalog Number
426PC-480
Product Length/Depth
8.25 in
Product Height
2 in
Product Width
2 in
Product Weight
0.6 lb
UPC
662276382886
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Voltage rating
480 Vac
Amperage Rating
20A
Material
Acrylonitrite butadiene styrene/polycarbonate blend (ABS+PC)
Pauluhn Marine Nonmetallic Pin and Sleeve Plugs and Connectors catalog page
Eaton Specification Sheet - 426PC-480
Feature ABS/PC housing provides a tough, chemical-tolerant shell that resists impact and corrosion in dirty or oily environments. Business impact: longer service life and reduced replacement costs. Application: factory floors and washdown zones where equipment endures frequent exposure to liquids and particulates. Feature IP66 ingress protection delivers dust-tight and high-pressure washdown resistance, allowing compliant operation in harsh environments. Business impact: minimal downtime during cleaning cycles and improved equipment reliability. Application: continuous production lines and outdoor installations. Feature 480 Vac and 20A rating with a 3-wire, 2-pole configuration supports standard industrial loads, enabling straightforward integration with common motors and control gear. Application: motor starters, feeders, and power distribution within automation cabinets. Feature compact 8.25 inch length and 2 inch width/height with a 0.6 lb weight optimize enclosure routing and panel space utilization. Business impact: easier retrofits and faster field installation. Application: panel upgrades and new equipment rollouts. Feature compatibility with Pauluhn 420FC/PP/PC plugs and connectors simplifies procurement and spares management. Business impact: reduced SKU variety and faster maintenance response. Application: retrofits and OEM replacements. Feature Ordinary/Non-Hazardous location rating aligns with standard industrial environments, simplifying compliance and installation planning. Business impact: lowers approval times and reduces safety certifications overhead. Application: general manufacturing and processing facilities.
Get a Quick Quote for a Eaton Crouse-Hinds 426PC-480
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 426PC-480?
Enquire Now
FAQs
For installation, ensure mating with Pauluhn 420FC/PP/PC plugs and accessories, verify the receiving receptacle is rated for 480 Vac, and use proper locking or securing methods. Confirm IP66 seals are intact for washdown environments and ensure the connection remains within Ordinary/Non-Hazardous locations per the catalog. Use appropriate wiring practices for 20A, 3-wire, 2-pole configurations to maintain safe, compliant power distribution.
Key specs are 480 Vac voltage, 20A current rating, and a 3-wire, 2-pole configuration. These specs define suitable load types (typically motors and control gear) and ensure compatibility with standard industrial equipment. The ABS/PC housing supports durability in industrial settings, while IP66 protection delivers reliable performance in dusty or washdown environments, contributing to consistent uptime.
Yes. The 426PC-480 is part of the Pauluhn 420FC/PP/PC plug and connector family, designed for mating with those plug types and accessories. This compatibility simplifies procurement, spares management, and retrofit projects, ensuring consistent performance across product lines and reducing the risk of mismatched components.
The unit carries an IP66 ingress protection rating and is specified for Ordinary/Non-Hazardous Locations. IP66 ensures dust-tight and high-pressure washdown resistance, which is critical in manufacturing and processing environments. Ordinary/Non-Hazardous location classification simplifies compliance and installation planning, helping ensure safe operation in typical factory settings without special hazardous-area requirements.
Expected benefits include reduced downtime due to rugged, corrosion-resistant ABS/PC housing and IP66 protection, and fewer spare parts because of standardized Pauluhn components. The 426PC-480 enables faster field replacements and reliable power connections for 480 Vac loads, contributing to higher line uptime, lower maintenance costs, and a favorable return on investment over time.
