Eaton Crouse-Hinds 556B Junction Box - IP66 Surface
Part Number: 556B
Quick Summary
556B junction box by Eaton Crouse-Hinds is a brass, surface-mounted enclosure that protects electrical connections in industrial control panels and equipment. Installers often grapple with corrosion resistance, dust ingress, and sealing reliability in harsh environments; this Pauluhn box delivers rugged protection and dependable service life. It meets key standards for North American installs, including NEC/CEC compliance and IP66 ingress protection, and is appropriate for Ordinary/Non-Hazardous Locations. The combination of material, protective rating, and compliant design helps streamline approvals and reduce rework. By prioritizing durability, ease of installation, and long-term maintenance economics, this enclosure supports safer, more efficient wiring chores and minimizes downtime in production environments.
Product Information
Extended Description
556B Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 556 junction box, 2" depth, Brass, Surface mount
Product Name
Eaton Crouse-Hinds series Pauluhn 556 junction box
Catalog Number
556B
Product Length/Depth
4.17 in
Product Height
6.75 in
Product Width
2.47 in
Product Weight
5.5 lb
UPC
662276383258
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
Ingress protection (IP) ratings
IP66
Material
Brass
Depth
2 in
Mounting style
Surface
Crouse-Hinds series Pauluhn 500 Series Rectangular Marine Junction Boxes catalog page
Eaton Specification Sheet - 556B
Brass construction provides excellent corrosion resistance and mechanical robustness, reducing maintenance needs and extending service life in challenging environments. This translates to lower lifecycle costs and fewer field replacements for coastal or wash-down applications, where reliability is critical. IP66 ingress protection guards against dust and high-pressure water exposure, ensuring continuous operation in harsh factories or outdoor installations and improving uptime for critical equipment. The enclosure dimensions—4.17 in length, 6.75 in height, and 2.47 in width with a 2 in depth—offer ample space for conductors and accessory fitments, supporting cleaner terminations and faster wiring in busy control panels. NEC/CEC compliance and Ordinary/Non-Hazardous Location classification simplify project approvals and reduce scope for special permits. Surface mounting and Pauluhn 500-series compatibility enable quick, secure installations with minimal supporting structures, boosting site productivity and reducing installation costs.
Get a Quick Quote for a Eaton Crouse-Hinds 556B
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 556B?
Enquire Now
FAQs
The 556B is designed for surface mounting, enabling direct attachment to walls or equipment surfaces without complex framing. Its Pauluhn 500-series compatibility ensures easy integration with existing enclosure systems, while brass construction provides long-term durability in non-hazardous environments. This combination reduces installation time and minimizes hardware requirements, improving field efficiency.
Yes. The 556B carries NEC/CEC standards compliance and is rated for Ordinary/Non-Hazardous Locations. Its IP66 ingress protection helps meet stringent environmental requirements, while the brass construction supports durable enclosures in standard industrial settings. This makes it a reliable choice for code-compliant control panels operating in non-hazardous areas.
The 556B measures about 4.17 inches in length, 6.75 inches in height, and 2.47 inches in width, with a 2-inch external depth. It weighs approximately 5.5 pounds. These dimensions offer ample internal room for conductors and terminations while remaining manageable for wall or equipment mounting.
Yes, thanks to its IP66 rating, the 556B provides robust protection against dust and high-pressure water jets, making it suitable for certain outdoor or wash-down settings where non-hazardous locations are applicable. Brass construction adds corrosion resistance, helping maintain enclosure integrity over long service life in challenging environments.
Official resources include the Eaton Crouse-Hinds Pauluhn 556B specification sheet and the Crouse-Hinds catalog page for the 500 Series Rectangular Marine Junction Boxes. These documents provide detailed dimensions, ratings, and installation guidance to support selection, quoting, and field deployment.
