Eaton Crouse-Hinds 834F Snap Switch - IP66
Part Number: 834F
Quick Summary
The Eaton Crouse-Hinds 834F snap switch is a two-pole, single-throw device designed for flush-mount installation in industrial panels and marine enclosures. In tight spaces, engineers struggle with compact, reliable switching that can withstand harsh conditions and moisture exposure. This model delivers IP66 ingress protection and is suited for ordinary/non-hazardous locations, enabling clean panel integration with minimal enclosure alteration. With a 20 A, 600 Vac rating and brass construction, it provides robust electrical protection while simplifying servicing for distributed control systems. For buyers, the 834F translates to shorter install times, reduced downtime, and better parts availability within the Pauluhn 833/834 family ecosystem.
Product Information
Extended Description
834F Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 833/834 snap switch, 20A, Brass, Flush mount, Two-pole, Single throw, 600 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 833/834 snap switch
Catalog Number
834F
Product Length/Depth
5.69 in
Product Height
5.69 in
Product Width
4.66 in
Product Weight
6 lb
UPC
662276387423
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Type
Single throw
Mounting style
Flush
Amperage Rating
20A
Voltage rating
600 Vac
Number Of Poles
Two-pole
Material
Brass
Pauluhn Marine Snap Switch catalog page
IF LBL 1502 - 833/834 General Alarm Contact Marker
Eaton Specification Sheet - 834F
Feature: Two-pole, single-throw design provides straightforward actuation and wiring simplification. Benefit: Reduces potential contact points and failure modes, improving reliability in control circuits. Application: Ideal for panel mounting in industrial automation and marine equipment where quick, dependable switching is required. Feature: 20 A at 600 Vac rating. Benefit: Supports common loads directly without the need for supplemental relays or contactors, cutting component count and installation time. Application: Control and power circuits in motors, lighting, and auxiliary systems in harsh environments. Feature: Brass construction. Benefit: Enhances durability and corrosion resistance in challenging environments, extending lifecycle and reducing maintenance. Application: Environments with exposure to moisture or salt spray in marine and outdoor panel assemblies. Feature: IP66 ingress protection. Benefit: Enables reliable operation during washdowns and in dusty environments, lowering failure risks from moisture ingress. Application: Ordinary location installations in industrial plants and maritime applications where protection from water and dust is essential. Feature: Flush mounting style with compact footprint (5.69 in L, 5.69 in H, 4.66 in W). Benefit: Saves panel space and simplifies enclosure design, enabling cleaner, tighter installations. Application: Control panels and instrument enclosures with limited depth and streamlined aesthetics. Feature: Compatibility with Pauluhn 833/834 series documentation and catalogs. Benefit: Streamlines parts sourcing and maintenance planning, reducing downtime and stocking complexity. Application: Replacement or upgrade projects in existing Pauluhn series deployments.
Get a Quick Quote for a Eaton Crouse-Hinds 834F
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 834F?
Enquire Now
FAQs
The 834F is flush-mount and fits standard panel cutouts; ensure the panel opening matches the 5.69 in length/depth and 4.66 in width. Use appropriate sealing and mounting hardware to maintain IP66 protection, and wire per the two-pole, single-throw configuration for 20A at 600 Vac. Verify enclosure location is suitable for ordinary/non-hazardous areas and follow Pauluhn installation guidance for consistent results.
834F is rated for 20A at 600 Vac with a two-pole, single-throw configuration. It is suitable for control circuits, lighting, and moderate-magnitude loads within these limits, enabling direct switching without additional relays in many standard industrial applications while maintaining IP66 protection and flush-mount installation.
Yes. The 834F is intended for ordinary/non-hazardous locations and provides IP66 ingress protection, making it appropriate for marine and washdown environments when properly installed and sealed in a controller or panel enclosure.
834F supports ordinary/non-hazardous locations with IP66 ingress protection. This combination ensures suitability for general industrial and marine settings where harsh washdowns or dust are present, aligning with Pauluhn series documentation for compliant installations.
The brass construction provides corrosion resistance, reducing replacement frequency in challenging environments. The compact flush-mount design simplifies installation and improves enclosure reliability, while compatibility with Pauluhn 833/834 documentation streamlines spare parts and maintenance planning, delivering lower total cost of ownership over the product lifecycle.
