Eaton Crouse-Hinds 841B-125 Receptacle - IP66 Rated
Part Number: 841B-125
Quick Summary
841B-125 receptacle by Eaton Crouse-Hinds provides reliable 125 Vac power in demanding industrial environments. Maintenance downtime and harsh conditions often threaten connection integrity and safety in control panels. This model features IP66 ingress protection and is intended for Ordinary/Non-Hazardous locations, supporting rugged operation in wet or dusty sites. Its brass construction with a 20A rating ensures durable, code-compliant wiring within wiring & connectivity and Pauluhn interlock applications, delivering long-term cost savings and uptime. For procurement teams, the 841B-125 aligns with Eaton’s installation sheets and datasheets, streamlining field retrofits and reducing vendor touchpoints while maintaining safety and regulatory compliance.
Product Information
Extended Description
841B-125 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 800 receptacle, 20A, Three-wire, two-pole, Brass, 125 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 800 receptacle
Catalog Number
841B-125
Product Length/Depth
5.19 in
Product Height
7.5 in
Product Width
4.5 in
Product Weight
7.5 lb
UPC
662276387492
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Amperage Rating
20A
Voltage rating
125 Vac
Material
Brass
Pauluhn Marine Interlock Receptacles catalog page
IF LBL 1545 - 841B, 842B, 843B, 844B Interlocking Switches and Receptacles
Eaton Specification Sheet - 841B-125
Feature: 20A, 125 Vac with a three-wire, two-pole configuration. Business Impact: Supports typical automation loads with safe, predictable current, reducing nuisance trips and improving panel reliability. Application: Ideal for control cabinets and industrial enclosures. Feature: IP66 ingress protection. Business Impact: Shields against dust and water ingress, lowering maintenance and replacement costs. Application: Suitable for washdown, outdoor, marine, and harsh industrial settings. Feature: Brass construction. Business Impact: Enhances durability and corrosion resistance for longer service life and stable contact performance. Application: Used in rugged environments with frequent mating cycles. Feature: Dimensions 5.19 in depth, 7.5 in height, 4.5 in width. Business Impact: Provides a compact footprint for flexible panel layouts, speeding installation. Application: Fits Pauluhn 800 interlock systems and standard mounting patterns. Feature: Interlock compatibility with Pauluhn 800 series and reference to IF LBL 1545. Business Impact: Streamlines installation and changeovers, reducing commissioning time. Application: Supports interlocking switches and receptacles in automation setups.
Get a Quick Quote for a Eaton Crouse-Hinds 841B-125
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 841B-125?
Enquire Now
FAQs
Yes. The 841B-125 is a Pauluhn 800 series receptacle designed for interlock configurations and is referenced in Eaton's IF LBL 1545 installation guidance, simplifying integration with interlock switches and receptacles.
It is rated for 20A at 125 Vac, using a three-wire, two-pole configuration, which supports standard automation loads in control panels and enclosures.
IP66 protection makes it suitable for washdown, dusty, outdoor, marine, and harsh industrial locations, ensuring reliable operation in non-hazardous environments.
Key compliance includes IP66 ingress protection and an Ordinary/Non-Hazardous locations classification, aligning with typical industrial safety and environmental requirements.
Refer to the Pauluhn Marine Interlock Receptacles catalog page, IF LBL 1545 installation sheet, and the Eaton Specification Sheet for 841B-125 to support safe installation and retrofits.
