Eaton Crouse-Hinds 842B-250 Receptacle - IP66
Part Number: 842B-250
Quick Summary
The Eaton Crouse-Hinds 842B-250 receptacle is a rugged 20 A, 250 V four-wire, three-pole metal connector designed for industrial enclosures. Maintenance teams struggle with weatherproofing and safe interlock options in harsh environments. Its IP66 rating protects against water and dust in ordinary/non-hazardous locations, and it supports Pauluhn 800 interlock assemblies. Together with robust brass construction and a compact footprint, this receptacle enables faster installations and lower maintenance costs. Engineers appreciate standardization with the Pauluhn 800 family, reducing spares and stocking complexity. Manufacturers benefit from a proven, weatherproof solution that supports compliant, safe low-voltage distribution in control panels. This combination delivers long-term total cost of ownership improvements for industrial wiring and connectivity projects.
Product Information
Extended Description
842B-250 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 800 receptacle, 20A, Four-wire, three-pole, Brass, 250 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 800 receptacle
Catalog Number
842B-250
Product Length/Depth
5.19 in
Product Height
7.5 in
Product Width
4.5 in
Product Weight
9.5 lb
UPC
662276387546
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Amperage Rating
20A
Voltage rating
250 V AC
Material
Brass
Pauluhn Marine Interlock Receptacles catalog page
IF LBL 1545 - 841B, 842B, 843B, 844B Interlocking Switches and Receptacles
Eaton Specification Sheet - 842B-250
Feature: Brass construction provides excellent durability and corrosion resistance. Business Impact: Longer service life in harsh environments reduces replacement cycles and maintenance spend. Application: Suitable for outdoor and moisture-prone industrial enclosures and damp locations. Feature: IP66 ingress protection delivers reliable weatherproofing. Business Impact: Protects critical connections from water and dust ingress, improving uptime and safety. Application: Outdoor equipment, outdoor-rated control panels, and marine or wet-area installations. Feature: 20A, 250 V AC four-wire three-pole design. Business Impact: Supports common industrial loads with robust electrical separation, enabling safer control circuits and easier wiring. Application: Control panels and process equipment in mid-size industrial facilities. Feature: Pauluhn 800 interlock compatibility. Business Impact: Simplifies integration with modular interlock systems, reducing install time and risk. Application: Pauluhn 800 interlock switches and receptacles in standardized automation layouts. Feature: Brass material and 9.5 lb weight. Business Impact: High torque resistance and rugged handling during installation, lowering rework. Application: Heavy-duty electrical connections in demanding environments. Feature: Compact dimensions (5.19 in L x 7.5 in H x 4.5 in W). Business Impact: Easier mounting in tight spaces, reducing enclosure footprint and install time. Application: Pauluhn 800 interlock assemblies and compact control enclosures in new builds or retrofits.
Get a Quick Quote for a Eaton Crouse-Hinds 842B-250
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 842B-250?
Enquire Now
FAQs
The 842B-250 should be mounted in a compatible Pauluhn 800 interlock system, using the provided mounting dimensions (5.19 in L, 7.5 in H, 4.5 in W). Weighing about 9.5 lb, it benefits from secure enclosure mounting, appropriate torque on brass terminals, and alignment with four-wire, three-pole wiring for reliable interlock operation.
It is rated for 20A and 250 V AC, configured as a four-wire, three-pole receptacle with brass construction, suitable for industrial control circuits and interlock assemblies within Pauluhn 800 systems.
Yes. The IP66 ingress protection rating provides strong water and dust resistance, and the Ordinary/Non-Hazardous Location classification supports use in standard industrial outdoor or damp environments with appropriate enclosures.
Indeed. The 842B-250 is designed for Pauluhn 800 interlock switches and receptacles, streamlining kit compatibility and installation, with installation sheets and catalog pages available for reference.
Durable brass construction and IP66 protection reduce corrosion-related maintenance and downtime, delivering longer service intervals, faster installation, and lower total cost of ownership in industrial wiring and connectivity projects.
