Eaton Crouse-Hinds 842B-480 Receptacle - IP66/480V
Part Number: 842B-480
Quick Summary
842B-480 receptacle from Eaton Crouse-Hinds is a rugged four-wire, three-pole connector for harsh industrial environments. Engineers often struggle with weatherproofing and reliable interlock operation in outdoor washdown areas. It carries IP66 protection and is suitable for ordinary/non-hazardous locations, enabling durable, code-compliant performance. This model also integrates with Pauluhn 800 interlock configurations, simplifying panel wiring and maintenance for contractors. By combining standard 480 Vac operation with brass construction, it supports reliable connections in corrosive or washdown environments. For panel builders and maintenance teams, SKU 842B-480 offers predictable fit, faster assembly, and easier stocking. This helps shorten project timelines and lowers total cost of ownership.
Product Information
Extended Description
842B-480 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Pauluhn 800 receptacle, 20A, Four-wire, three-pole, Brass, 480 Vac
Product Name
Eaton Crouse-Hinds series Pauluhn 800 receptacle
Catalog Number
842B-480
Product Length/Depth
5.19 in
Product Height
7.5 in
Product Width
4.5 in
Product Weight
9.5 lb
UPC
662276387553
Area classification
Ordinary/Non-Hazardous Locations
Ingress protection (IP) ratings
IP66
Amperage Rating
20A
Voltage rating
480 Vac
Material
Brass
Pauluhn Marine Interlock Receptacles catalog page
IF LBL 1545 - 841B, 842B, 843B, 844B Interlocking Switches and Receptacles
Eaton Specification Sheet - 842B-480
IP66 protection delivers dust-tight and water ingress resistance, reducing contamination and unplanned downtime in washdown or outdoor locations, which translates to lower maintenance costs and longer service life in harsh environments. The 20A, 480 Vac four-wire three-pole design aligns with mainstream industrial equipment, enabling quick, plug-and-play wiring and consistent performance across control panels and field connections. Brass construction provides inherent corrosion resistance, extending component life in humid or chemical exposure areas and improving reliability in marine or coastal facilities. Compatibility with Pauluhn 800 interlock switches and receptacles streamlines system integration, lowering installation time and reducing spare-parts inventory for maintenance teams. Clear dimensions and standard hardware footprint facilitate straightforward panel layout planning and faster procurement for project teams. Documentation such as IF LBL 1545 supports compliant interlock installation and reduces risk during commissioning.
Get a Quick Quote for a Eaton Crouse-Hinds 842B-480
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 842B-480?
Enquire Now
FAQs
The 842B-480 is suited for industrial environments requiring reliable interlock operation in washdown and outdoor locations. With IP66 protection and a four-wire, three-pole configuration, it supports 20A at 480 Vac and is compatible with Pauluhn 800 interlock systems, making it ideal for control panels in manufacturing and processing facilities where moisture and dust are concerns.
Yes. The 842B-480 is designed to integrate with Pauluhn 800 interlock configurations. Installation guidance is available in the IF LBL 1545 instruction sheet, facilitating proper interlock alignment, safe operation, and streamlined maintenance for Pauluhn interlock receptacle setups.
Key specs include a 20A amperage rating, 480 Vac voltage, brass construction, and four-wire, three-pole configuration. The receptacle carries IP66 ingress protection and is intended for ordinary/non-hazardous locations, ensuring robust performance in challenging environments.
The 842B-480 features IP66 ingress protection for strong protection against dust and water. It is classified for Ordinary/Non-Hazardous Locations, aligning with standard industrial wiring expectations. This combination supports reliable operation in outdoor and washdown environments, though exact regulatory markings other than IP66 and area classification are not specified in the provided data.
The receptacle measures 5.19 inches in depth, 7.5 inches in height, and 4.5 inches in width, with a weight of 9.5 pounds. Catalog number is 842B-480, UPC 662276387553, and the unit uses brass as the housing material, which supports corrosion resistance in harsh environments.
