Eaton Crouse-Hinds CEX133-B12-327SN Roughneck Plug - Zone 1
Part Number: CEX133-B12-327SN
Quick Summary
Eaton Crouse-Hinds CEX133-B12-327SN cable mounted plug is a rugged solution for hazardous-location power connections in demanding industrial environments. It reliably seals and terminates #12 AWG conductors with a crimped socket contact, even where exposure to dust, moisture, or chemicals is high. This assembly carries IECEx/ATEX, NEC/CEC, and Zone 1 ratings along with IP68 and IP66 protection, delivering regulatory compliance and safer operation in the field. For procurement teams and engineers, the combination of a compact shell size and a robust Eex d gland reduces part numbers and simplifies spares when stocking Roughneck connectors. In practice, you gain safer installations, faster commissioning, and sustained performance across oil, gas, and chemical processing facilities.
Product Information
Extended Description
CEX133-B12-327SN Eaton Crouse-Hinds: Eaton Crouse-Hinds series Roughneck CEX cable mounted plug with cable gland, 30A, Eex d gland, Unarmoured, Female, Silver plated copper contacts, #12 AWG, Crimp, Socket, 13.5 - 20.5 inner sheath, 18.0 - 27.5 outer sheath, 12 shell
Product Name
Eaton Crouse-Hinds series Roughneck CEX cable mounted plug with cable gland
Catalog Number
CEX133-B12-327SN
Product Length/Depth
6.57 in
Product Height
1.75 in
Product Width
1.75 in
Product Weight
1.5 lb
UPC
662276622470
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC IECEx/ATEX
IECEx/ATEX hazardous rating
Zone 1
NEMA Rating
6P 4X
Ingress protection (IP) ratings
IP68 IP66
Shell size
12
Cable hardware
Eex d Gland
Cable type
Unarmoured
Inner sheath (min/max)
13.5 - 20.5
Outer sheath (min/max)
18.0 - 27.5
Contact size
#12 AWG
Amperage Rating
30A
Connector gender
Female
Contact type
Socket
Contact termination
Crimp
Contact material
Silver plated copper
Roughneck Multi-pin and Single Pole Connectors brochure
Roughneck Hazardous Area Multi-pin and Single Pole Connectors catalog page
IF 1683 - Roughneck Hazardous Multi-pin Connector
Eaton Specification Sheet - CEX133-B12-327SN
Feature: Rugged Roughneck construction with an EEx d gland and unarmoured cable compatibility. Business Impact: Improves reliability in harsh environments and reduces field failure rates, lowering maintenance costs. Application: Ideal for wiring power distribution in hazardous locations with rugged outdoor or wet processing conditions. Feature: 30A amperage rating with #12 AWG silver-plated copper contacts and a crimp termination. Business Impact: Enables robust current transfer for moderate motor loads while maintaining low contact resistance and long-term durability. Application: Suitable for compact motor starters and control circuits in hazardous areas. Feature: IP68 and IP66 sealing alongside NEMA 6P 4X protection. Business Impact: Delivers dust-tight and water ingress resistance plus extended equipment life, minimizing downtime during washdowns or washdowns and tough climates. Application: Offshore platforms, refineries, and chemical plants requiring rugged protection. Feature: Shell size 12 and specified inner/outer sheath ranges (13.5–20.5 mm; 18.0–27.5 mm). Business Impact: Supports flexible cable sizing with reliable strain relief, reducing the need for adapters. Application: Field installations where cable lengths and sheath sizes vary. Feature: Contact material of silver-plated copper with socket, crimp termination. Business Impact: Enhances conductivity and corrosion resistance, delivering stable performance in corrosive atmospheres. Application: Harsh environments where long-term electrical integrity is critical. Feature: IECEx/ATEX Zone 1, NEC/CEC compliance, and hazardous-location suitability. Business Impact: Streamlines procurement, regulatory compliance, and installation approvals. Application: Projects in oil, gas, mining, and chemical-processing facilities where safety certification is essential.
Get a Quick Quote for a Eaton Crouse-Hinds CEX133-B12-327SN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds CEX133-B12-327SN?
Enquire Now
FAQs
The CEX133-B12-327SN accepts unarmoured conductors up to #12 AWG with crimp termination and uses an EEx d gland. It supports inner sheath sizing of 13.5–20.5 mm and outer sheath of 18.0–27.5 mm, enabling secure strain relief for field wiring and ensuring a proper seal in hazardous environments when paired with the correct mating Roughneck connector.
With a 30A amperage rating and #12 AWG silver-plated copper contacts, the plug handles standard motor control and smaller electrical loads reliably. The socket/crimp configuration reduces contact resistance and wear, delivering consistent performance over time while the EEx d gland maintains a gas-tight seal in hazardous locations.
Yes. The CEX133-B12-327SN carries IECEx/ATEX Zone 1 ratings, NEC/CEC compliance, and IP68/IP66 protection, making it suitable for hazardous-area installations in oil, gas, chemical, and mining environments where flammable atmospheres may be present.
Key certifications include IECEx/ATEX for Zone 1 hazardous areas, NEC/CEC for North American compliance, IP68/IP66 for ingress protection, and NEMA 6P 4X for rugged enclosure compatibility. These credentials help ensure regulatory acceptance, safety, and long-term reliability in demanding industrial settings.
The Roughneck CEX133 enables quick field wiring with crimp termination and a robust EEx d gland, reducing commissioning time and spare-part diversity. Its durable build and hazard-location certifications translate into lower maintenance costs and less downtime, delivering faster return on investment in continuous-operation facilities.
