Eaton Crouse-Hinds CGD292 Cable Gland - NEMA 4
Part Number: CGD292
Quick Summary
CGD292 cable gland by Eaton Crouse-Hinds provides a rugged seal for non-armoured tray cables in industrial enclosures. The challenge of sealing multiple cable types while maintaining IP and fire safety can slow installation and drive cost. This gland meets NEC/CEC standards, carries a NEMA 4 rating, and is designed for ordinary/non-hazardous locations—reducing risk and rework. For panel builders and integrators, the CGD292 simplifies entry points for tray cables and complements existing Crouse-Hinds gland families, delivering reliable, long-term performance in harsh environments while keeping installation straightforward for technicians.
Product Information
Extended Description
CGD292 Eaton Crouse-Hinds: Eaton Crouse-Hinds series CGD cable gland, Cable range min/max: 0.125-0.250", Non-armoured and tray cable, 45° angle, Non-armoured gland, Feraloy iron alloy, General purpose, 3/4" NPT
Product Name
Eaton Crouse-Hinds series CGD cable gland
Catalog Number
CGD292
Product Length/Depth
2.57 in
Product Height
1.14 in
Product Width
1.14 in
Product Weight
0.3 lb
UPC
782274143651
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
4
Protection type
General purpose
Cable type
Non-armoured Tray cable
Gland type
Non-armoured
Connector type
45° angle
Thread Size
3/4"
Thread type
NPT
Cable range (min/max)
0.125-0.250"
Material
Feraloy iron alloy
Crouse-Hinds series Tray Cable Glands brochure
Crouse-Hinds series CGB, CGD, CGE and CGFP Non-armoured Glands catalog page
CGB, CGD, CGE and CGFP Non-armoured Glands UL certification (Cover)
CGB, CGD, CGE and CGFP Non-armoured Glands UL certification (Cover)
IF 1826 - CGB, CGD and CGE Connectors
IF 1826 - CGB, CGD and CGE Connectors
Eaton Specification Sheet - CGD292
Feature → Business Impact → Application: The CGD292 uses a non-armoured gland construction with a 3/4" NPT thread size and a 45° angle connector, enabling quick, precise entry into enclosures while minimizing bending stresses on non-armoured tray cables. This translates to faster installation, reduced downtime, and improved reliability in control panels and junction boxes across manufacturing lines. The Feraloy iron alloy body provides robust mechanical strength and corrosion resistance, extending service life in harsh environments and lowering maintenance costs for facility managers. With a cable range of 0.125–0.250 inches and a general-purpose protection type, it supports a wide variety of tray cable assemblies without sacrificing seal integrity or plug performance. The gland is aligned with NEC/CEC standards, UL-certified configurations, and ordinary/non-hazardous location classifications, ensuring compliance during audits and helping procurement maintain consistent spec adherence. Installation advantages include compatibility with existing Crouse-Hinds tray cable gland ecosystems, reducing the need for adapters and simplifying stocking. In practice, engineers can achieve secure gland terminations with predictable torque and fit, mitigating leaks and ingress paths in critical enclosures.
Get a Quick Quote for a Eaton Crouse-Hinds CGD292
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds CGD292?
Enquire Now
FAQs
CGD292 uses a 3/4" NPT gland and a 45° angle entry, allowing straightforward routing of non-armoured tray cables into electrical enclosures. The gland’s non-armoured design reduces footprint and simplifies seal seating, which shortens installation time and minimizes vibration-induced leakage in panels operating in ordinary locations.
Key specs include a cable range of 0.125–0.250 inches, 3/4" NPT thread size, a 45° angle connector, and a body made from Feraloy iron alloy. These factors contribute to reliable sealing, resistance to corrosion, and compatibility with tray cables used in non-armoured installations under NEC/CEC guidelines.
CGD292 is designed for ordinary/non-hazardous locations with a NEMA 4 rating, satisfying general-purpose protection needs. It is not intended for hazardous area classifications, where additional explosion-proof or higher IP-rated gland solutions would be required.
Ensure the entered cable diameter stays within 0.125–0.250 inches and tighten to the manufacturer’s torque specification to maintain the seal. Use compatible non-armoured tray cables and align the gland angle to minimize bending. The Feraloy alloy provides corrosion resistance, beneficial for damp or mildly corrosive environments.
CGD292 aligns with NEC/CEC standards and carries a NEMA 4 rating for general enclosure protection. It is supported by UL certification materials within Eaton’s Crouse-Hinds catalog and datasheets, ensuring traceability for compliance audits and safe integration into existing control systems.
