Eaton CPMV3L-UNV1-S891 LED Wall Pack Light Fixture - IP66

The CPMV3L-UNV1-S891 uses a 30W LED engine to deliver 3000 lumens at 111 lm/W, which translates into significant energy savings while maintaining robust wall-pack coverage for perimeter lighting. This efficiency directly lowers operating costs in continuous-duty applications and supports compliant, bright illumination in high-traffic zones. The dimmable driver combined with a wide voltage range (120-277 Vac, 50/60 Hz) enables seamless integration with existing plant electrical systems, reducing wiring changes and enabling zone-by-zone lighting control for safer operations. The die-cast aluminum housing is designed for durability in harsh environments, offering IP66 ingress protection and a NEMA 4X enclosure to resist dust, water, and corrosive exposure, thereby reducing maintenance cycles and extending service life. A diffused glass lens and 7x6 optical distribution provide uniform coverage with minimal glare, enhancing worker safety and reducing hot spots in outdoor walls. Finally, the fixture is approved for hazardous/classified locations (NEC/CEC) and features a 3/4" entry with yoke mounting for straightforward installation and compatibility with retrofit projects, supporting fast deployment across critical infrastructure.
