CPMV5L-UNV34-S903 LED Wall Pack - IP66/NEMA 4X
Part Number: CPMV5L-UNV34-S903
Quick Summary
CPMV5L-UNV34-S903 LED wall pack is a high-efficiency lighting fixture designed for hazardous-area facilities. In practice, engineers face reliability gaps and costly maintenance when lighting must perform in Class I/Division 2 zones. This model delivers IP66 protection, NEMA 4X enclosure, and NEC/CEC alignment for Hazardous/Classified Locations, helping meet strict industry standards. With dimmable drivers and a 347-480 VAC rating, it supports flexible retrofits and new-build installations while reducing energy use. The 5000-lumen output at 116 lm/W paired with a rugged die-cast aluminum housing ensures long life in demanding environments, providing safer, more efficient illumination for both indoor and outdoor applications. Coupled with a yoke mount, 3/4" entry, and polycarbonate lens, it simplifies mounting and maintenance in tight spaces while offering reliable performance in challenging weather.
Product Information
Extended Description
CPMV5L-UNV34-S903 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Champ CPMV LED wall pack, 0.15A, Cool white, Dimmable driver, 3/4" entry, 100W equiv, 60 Hz, Polycarbonate lens, 5000 lumens, 116 lm/W, Die cast aluminum, Yoke mount, 7x6 distribution, 347-480 Vac, 45W
Product Name
Eaton Crouse-Hinds series Champ CPMV LED wall pack light fixture
Catalog Number
CPMV5L-UNV34-S903
Product Length/Depth
9.16 in
Product Height
12.76 in
Product Width
12.6 in
Product Weight
14 lb
UPC
662276892088
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class III Class I, Division 2 Class II, Division 1
NEMA Rating
4X
Ingress protection (IP) ratings
IP66
Lamp type
LED
Lumens
5000
Lumens per watt
26W
Color temperature
Cool white
Optical distribution
7x6
Mounting Method
Yoke
Voltage rating
347-480 Vac
Frequency rating
60 Hz
Lens material
Polycarbonate
Wattage
45W
Amperage Rating
0.088A
Power factor
> 0.90
Dimming
Dimmable driver
Entry size
3/4"
Material
Die cast aluminum
Equivalent luminaire
100W
SP3D Design Package - Champ CPMV LED Hazardous Area Wallpack Light Fixtures
Crouse-Hinds series CPMV LED brochure
Crouse-Hinds series CPMV LED brochure
Crouse-Hinds series Champ CPMV LED catalog page
Champ CPMV LED Hazardous Area Wallpack Light Fixtures UL certification
Champ CPMV LED Hazardous Area Wallpack Light Fixtures UL certification
IF 1892 - Champ-Pak CPMVL LED Wall Pack
Eaton Specification Sheet - CPMV5L-UNV34-S903
Feature: 5000 lumens at 116 lm/W with a 45W driver. Business Impact: high-efficiency output lowers energy costs and reduces cooling load, extending maintenance intervals. Application: ideal for hazardous-area wallpacks in outdoor and indoor industrial spaces. Feature: 347-480 VAC operation with 60 Hz and dimmable driver. Business Impact: enables flexible retrofits and reduces wiring substitutions, improving project timelines. Application: suited for facilities with varied power architectures and need for adjustable brightness. Feature: rugged housing using die-cast aluminum and polycarbonate lens. Business Impact: enhanced durability against corrosion and impact, leading to longer service life and lower replacement costs. Application: chemical plants, refineries, offshore installations. Feature: IP66 and NEMA 4X protection. Business Impact: resilient performance in dusty, wet, and hazardous environments, ensuring compliance and uptime. Application: hazardous-location lighting across harsh industrial settings. Feature: Yoke mounting with 3/4" entry, 9.16 in length, 12.76 in height, 12.6 in width, and 14 lb weight. Business Impact: straightforward installation and retrofit compatibility with limited access spaces, reducing labor time. Application: retrofit projects and new-builds requiring robust wall-pack solutions.
Get a Quick Quote for a Eaton Crouse-Hinds CPMV5L-UNV34-S903
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds CPMV5L-UNV34-S903?
Enquire Now
FAQs
The CPMV5L-UNV34-S903 is designed for 347-480 VAC operation at 60 Hz and features a dimmable driver. It draws approximately 0.088 A at 45 W, delivering 5000 lumens. This makes it suitable for retrofit projects and new builds where voltage flexibility and dimming control improve energy management and lighting quality in hazardous locations.
This wall pack carries NEC/CEC alignment for Hazardous/Classified Locations and an IP66 rating with a NEMA 4X enclosure. It is designed for Class I, Division 2 (and related classifications) and Class II, Division 1 environments, ensuring code compliance and enhanced protection against dust, water, and corrosion in harsh facilities.
The fixture uses a 3/4" entry with a convenient yoke mounting setup, compact dimensions (9.16 in L, 12.76 in H, 12.6 in W) and a weight of 14 lb. These characteristics simplify mounting in tight spaces, support straightforward wiring during retrofits, and enable reliable operation in both indoor and outdoor hazardous-area walls.
This LED wall pack excels in hazardous locations such as chemical plants, refineries, and offshore facilities. Its rugged housing, polycarbonate lens, and wide 7x6 optical distribution provide uniform coverage for exterior facades and protected indoor areas, reducing the number of fixtures required and improving safety and visibility in critical workflows.
With 5000 lumens at 116 lm/W and a durable die-cast aluminum housing, the CPMV5L-UNV34-S903 reduces energy consumption and maintenance cycles compared to legacy fixtures. The dimmable driver supports demand-based lighting control, while the robust enclosure lowers replacement frequency in harsh environments, delivering lower total cost of ownership over the system life.
