Eaton Crouse-Hinds CZP-12-314-SN Roughneck CZ insert kit - Ordinary/Non-Hazardous Locations
Part Number: CZP-12-314-SN
Quick Summary
CZP-12-314-SN is an Eaton Crouse-Hinds Roughneck CZ insert kit that delivers a reliable, high-current connection for heavy industrial wiring with #10 AWG conductors. For engineers, the challenge is finding a connector that is rugged yet easy to assemble and service in the field; this kit balances durability with practical installation. The unit is suitable for ordinary or non-hazardous locations and carries UL-based Canadian certification for CZ Series components, offering regulatory assurance across North American plants. It also aligns with the Roughneck family’s rugged performance in harsh environments. By standardizing on this insert kit, procurement and maintenance teams can reduce spares variety while improving uptime and safety.
Product Information
Extended Description
CZP-12-314-SN Eaton Crouse-Hinds: Eaton Crouse-Hinds series Roughneck CZ insert kit, 40A, Female, #10 AWG, Crimp, Socket, 12 shell
Product Name
Eaton Crouse-Hinds series Roughneck CZ insert kit
Catalog Number
CZP-12-314-SN
Product Length/Depth
2.06 in
Product Height
1.41 in
Product Width
1.41 in
Product Weight
0.25 lb
UPC
662276428843
Area classification
Ordinary/Non-Hazardous Locations
Shell size
12
Contact size
#10 AWG
Amperage Rating
40A
Connector gender
Female
Contact type
Socket
Contact termination
Crimp
Roughneck Multi-pin and Single Pole Connectors brochure
Roughneck Heavy Industrial Multi-pin and Single Pole Connectors catalog page
Roughneck Heavy Industrial Multi-pin Connectors Canadian certification (CZ Series)
Roughneck Heavy Industrial Multi-pin Connectors Canadian certification (CZ Series)
IF 1688 - Roughneck Non-hazardous Multi-pin Connector
Eaton Specification Sheet - CZP-12-314-SN
Eaton Specification Sheet - CZP-12-314-SN
Feature: High current capability and conductor compatibility. Business Impact: Supports essential power and signal loads in dense harnesses, reducing voltage drop and overheating risks in motor and control circuits. Application: Heavy equipment panels, machine control enclosures, and high-density wiring in industrial facilities. This helps customers meet performance targets without overhauling existing harnesses. Feature: Socket contact with crimp termination. Business Impact: Delivers a robust, field-serviceable connection that stands up to vibration and repeated mating cycles, lowering maintenance costs. Application: Field installations where quick, reliable terminations are critical, such as service cabinets and remote equipment bays. Feature: 12-shell shell size and #10 AWG contact size. Business Impact: Enables modular, scalable connectors with standardized spares, improving inventory management and reducing downtime during changes or expansions. Application: Multi-pin data, control, and power assemblies in rugged environments. Feature: Rugged Roughneck lineage with documented installation resources. Business Impact: Streamlines procurement and onboarding with familiar tooling and installation practices, reducing training time and error rates. Application: New builds and retrofits in process plants and manufacturing lines. Feature: Compliance and documentation support. Business Impact: Provides easy access to brochures, datasheets, and installation instructions to ensure proper selection, installation, and ongoing maintenance. Application: Engineering BOMs, procurement briefs, and QC workflows.
Get a Quick Quote for a Eaton Crouse-Hinds CZP-12-314-SN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds CZP-12-314-SN?
Enquire Now
FAQs
CZP-12-314-SN is a Roughneck CZ insert kit designed for Eaton Crouse-Hinds CZ Series multi-pin connectors. It uses a 12-shell configuration with a #10 AWG contact size and a crimped socket, suitable for 40A applications.
Install using proper crimp tooling and the specified 12-shell CZ insert kit, following the manufacturer’s guidance (IF 1688 instructions are referenced in Eaton literature). Ensure correct mating with CZ Series connectors and verify the #10 AWG crimp termination for a secure, low-resistance connection.
No. The product is rated for Ordinary/Non-Hazardous Locations, so for hazardous area applications you should verify local codes and consider alternative ratings or configurations from the CZ Roughneck family.
Key specs include 40A amperage rating, shell size 12, contact size #10 AWG, female socket, crimp termination, length 2.06 in, width 1.41 in, height 1.41 in, weight 0.25 lb, and UPC 662276428843.
Access Eaton’s Roughneck literature and spec sheets, including the CZP-12-314-SN datasheet and catalog pages, plus Canadian UL CZ Series certification references. Useful resources include brochure, catalog pages, and installation sheets linked in the product downloads.
