Eaton CZP-20-350-SN Roughneck CZ Insert Kit - 30A
Part Number: CZP-20-350-SN
Quick Summary
CZP-20-350-SN Roughneck CZ insert kit provides a 30A multi-pin power connector for harsh industrial environments. Engineers and technicians often contend with bulky inserts that slow assembly, complicate splices, and drive downtime. UL certification coverage for the CZ Series and area classifications of Ordinary/Non-Hazardous Locations provide regulatory assurance and safer operation. The kit’s compatibility with Roughneck connectors, field-crimp readiness, and a compact footprint help speed installs while preserving reliability and scalability in the field. For procurement teams, the standardized CZP-20-350-SN part number reduces sourcing ambiguity across facilities. Distributors and service partners benefit from documented data sheets and UL certifications referenced in the included literature.
Product Information
Extended Description
CZP-20-350-SN Eaton Crouse-Hinds: Eaton Crouse-Hinds series Roughneck CZ insert kit, 30A, Female, #12 AWG, Crimp, Socket, 20 shell, 37 contacts
Product Name
Eaton Crouse-Hinds series Roughneck CZ insert kit
Catalog Number
CZP-20-350-SN
Product Length/Depth
2.42 in
Product Height
2.5 in
Product Width
2.5 in
Product Weight
1 lb
UPC
662276429161
Area classification
Ordinary/Non-Hazardous Locations
Shell size
20
Contact size
#12 AWG
Amperage Rating
30A
Connector gender
Female
Contact type
Socket
Contact termination
Crimp
Roughneck Multi-pin and Single Pole Connectors brochure
Roughneck Heavy Industrial Multi-pin and Single Pole Connectors catalog page
Roughneck Heavy Industrial Multi-pin Connectors UL certification (CZ Series)
Roughneck Heavy Industrial Multi-pin Connectors UL certification (CZ Series)
IF 1688 - Roughneck Non-hazardous Multi-pin Connector
Multi-pin Connectors
Multi-pin Connectors
Feature: 30A amperage rating and socket contacts sized for #12 AWG. Business Impact: Enables clean, low-resistance power paths for reliable operation in heavy power distribution and motor control. Application: Ideal for Roughneck CZ insert assemblies in industrial control panels. Feature: Crimp termination for field installation. Business Impact: Reduces installation time and minimizes field wiring errors, lowering downtime and labor costs. Application: Quick turn-around in on-site wiring without sacrificing reliability. Feature: Shell size 20 with 37 contacts. Business Impact: Supports flexible, multi-pin configurations for complex data, signal, and power needs. Application: Multi-pin connector assemblies in data and control networks within rugged environments. Feature: Area classification Ordinary/Non-Hazardous Locations with UL certification. Business Impact: Compliance assurance and safer operation in non-hazardous facilities. Application: Suitable for non‑hazardous plants and process environments requiring recognized safety standards. Feature: Compact footprint and documented accessories. Business Impact: Easier panel integration and streamlined procurement with available brochures and datasheets. Application: Retrofit or new-build applications where space and documentation ease are critical.
Get a Quick Quote for a Eaton Crouse-Hinds CZP-20-350-SN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds CZP-20-350-SN?
Enquire Now
FAQs
To install, verify shell size 20 and socket contacts sized for #12 AWG. Prepare crimp terminations per IF 1688 instructions, insert contacts into the CZ shell, and secure per manufacturer guidelines. Ensure the assembly remains within ordinary/non-hazardous locations and perform a final continuity check to confirm solid, low-resistance connections.
The CZP-20-350-SN uses the Roughneck CZ insert format with a 20-shell, socket contact configuration designed for #12 AWG conductors and crimp terminations. It is specified as a female, 30A, multi-pin solution compatible with CZ series housings, supporting up to 37 contacts for flexible, rugged connections.
Yes. The product is classified for Ordinary/Non-Hazardous Locations and is UL-certified for CZ Series assemblies, providing regulatory assurance for non-hazardous environments. This makes it appropriate for standard industrial facilities without hazardous-area requirements.
The CZP-20-350-SN is associated with UL certifications for the CZ Series and area classifications for Ordinary/Non-Hazardous Locations. Supporting literature includes brochures, catalog pages, and installation instructions (IF 1688) available through Eaton’s Roughneck documentation and UL certification pages.
The kit consolidates a 30A, #12 AWG, crimped, multi-pin connection in a compact Roughneck form factor, reducing assembly time, field errors, and downtime. With UL compliance and standardized part numbers, maintenance and spares management become leaner, delivering lower total cost of ownership over equipment life cycles.
