Eaton Crouse-Hinds CZP-20-375-PN Insert Kit - 40A
Part Number: CZP-20-375-PN
Quick Summary
CZP-20-375-PN insert kit from Eaton Crouse-Hinds enables rugged Roughneck connections in heavy industrial control panels. In harsh environments, downtime and inconsistent terminations erode maintenance budgets and uptime. This product aligns with UL Canadian certification for the CZ Series and supports area classifications of Ordinary/Non-Hazardous Locations, helping you meet regulatory expectations. By standardizing on the CZ insert kit for 40A circuits and 20-shell configurations, you reduce field variation, simplify spares, and accelerate project timelines. Two to three key benefits include easier diagnostics, improved safety, and predictable crimp integrity.
Product Information
Extended Description
CZP-20-375-PN Eaton Crouse-Hinds: Eaton Crouse-Hinds series Roughneck CZ insert kit, 40A, Male, #10 AWG, Crimp, Pin, 20 shell
Product Name
Eaton Crouse-Hinds series Roughneck CZ insert kit
Catalog Number
CZP-20-375-PN
Product Length/Depth
2.42 in
Product Height
2.5 in
Product Width
2.5 in
Product Weight
0.65 lb
UPC
662275337276
Area classification
Ordinary/Non-Hazardous Locations
Shell size
20
Contact size
#10 AWG
Amperage Rating
40A
Connector gender
Male
Contact type
Pin
Contact termination
Crimp
Roughneck Multi-pin and Single Pole Connectors brochure
Roughneck Heavy Industrial Multi-pin and Single Pole Connectors catalog page
Roughneck Heavy Industrial Multi-pin Connectors Canadian certification (CZ Series)
Roughneck Heavy Industrial Multi-pin Connectors Canadian certification (CZ Series)
IF 1688 - Roughneck Non-hazardous Multi-pin Connector
Eaton Specification Sheet - CZP-20-375-PN
Eaton Specification Sheet - CZP-20-375-PN
Feature: 40A amperage rating and 20-shell size enable heavy-duty power paths, delivering reliable current delivery for motor control and instrumentation in demanding environments. Business Impact: Higher current capability with robust enclosure compatibility reduces overheating risks and minimizes unplanned downtime. Application: Suitable for Roughneck CZ multi-pin connectors in control panels and industrial cabinets. Feature: Male pin with crimp termination simplifies field assembly and improves connection security. Business Impact: Faster installations and fewer mis-terminate events translate to shorter panel builds and maintenance intervals. Application: Ideal for high-vibration settings where consistent crimp quality is critical. Feature: Compact footprint with 2.42 in depth and 2.5 in square footprint supports tight panel layouts. Business Impact: Frees space in crowded control cabinets while maintaining reliable mating interfaces. Application: Suitable for compact, high-density electrical panels. Feature: Ordinary/Non-Hazardous area classification supports standard plant environments. Business Impact: Regulatory alignment reduces design risk and accelerates commissioning. Application: Common in non-hazardous industrial facilities. Feature: Documentation and certification availability including installation instructions and datasheets. Business Impact: Streamlines qualification, procurement, and training, lowering risk and speeding onboarding. Application: Access to IF 1688 instructions and Eaton spec sheets for quick reference.
Get a Quick Quote for a Eaton Crouse-Hinds CZP-20-375-PN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds CZP-20-375-PN?
Enquire Now
FAQs
The CZP-20-375-PN insert kit is designed for Roughneck CZ multi-pin connectors in the 20-shell family. It uses a #10 AWG contact with crimp termination and a male pin configuration, suitable for 40A circuits in heavy industrial panels.
Install using standard crimp tools for #10 AWG conductors and follow the installation guidance in the IF 1688 Roughneck instruction sheet. Ensure proper crimp quality and verify mating alignment with the CZ connector housing to maintain reliable electrical performance.
Yes. The CZP-20-375-PN is specified for Ordinary/Non-Hazardous Locations, aligning with typical non-hazard expansion and control cabinet environments while maintaining rugged, vibration-resistant performance.
CZP-20-375-PN documentation references UL Canadian certification for the CZ Series. There is no explicit CE or IP rating listed in the provided data; consult the certification reports and datasheets for explicit scope and compliance details.
Key specs include a 40A amperage rating, shell size 20, contact size #10 AWG, crimp termination, and male pin contact type. Dimensions are 2.42 in length by 2.5 in height and width, with a weight around 0.65 lb, aiding space planning in panel layouts.
