Eaton CZP-20-387-PN insert kit - CZ Series UL Certified
Part Number: CZP-20-387-PN
Quick Summary
CZP-20-387-PN insert kit is a Roughneck CZ connector accessory designed to terminate #12 AWG conductors in 30A multi-pin assemblies. Engineering teams often face unreliable crimps and shell mismatches that complicate installation, increase downtime, and raise safety risk in the field. UL certification for the CZ Series in the US and Canada, along with Ordinary/Non-Hazardous area classification, supports regulatory compliance and safe operation. Designed to fit the 20-shell, 2.42 in length, and 2.5x2.5 in envelope of Roughneck housings, this kit enables repeatable, high-integrity connections. Using the CZP-20-387-PN across projects streamlines procurement and reduces training time, delivering measurable efficiency gains.
Product Information
Extended Description
CZP-20-387-PN Eaton Crouse-Hinds: Eaton Crouse-Hinds series Roughneck CZ insert kit, 30A, Male, #12 AWG, Crimp, Pin, 20 shell, 20 contacts
Product Name
Eaton Crouse-Hinds series Roughneck CZ insert kit
Catalog Number
CZP-20-387-PN
Product Length/Depth
2.42 in
Product Height
2.5 in
Product Width
2.5 in
Product Weight
0.65 lb
UPC
662276429215
Area classification
Ordinary/Non-Hazardous Locations
Shell size
20
Contact size
#12 AWG
Amperage Rating
30A
Connector gender
Male
Contact type
Pin
Contact termination
Crimp
Roughneck Multi-pin and Single Pole Connectors brochure
Roughneck Heavy Industrial Multi-pin and Single Pole Connectors catalog page
Roughneck Heavy Industrial Multi-pin Connectors UL certification (CZ Series)
Roughneck Heavy Industrial Multi-pin Connectors UL certification (CZ Series)
IF 1688 - Roughneck Non-hazardous Multi-pin Connector
Multi-pin Connectors
Multi-pin Connectors
Feature: 30A amperage rating with #12 AWG contact size and a male pin in a 20-shell insert. Business Impact: Delivers a robust power path with reduced risk of overheating and improved electrical integrity in heavy industrial environments. Application: Ideal for Roughneck CZ multi-pin connectors in control panels and outdoor installations where space is constrained and reliability is critical. Feature: Crimp termination capability with compatible tooling. Business Impact: Enables fast, repeatable, field-ready terminations, reducing rework and commissioning time. Application: On-site harness assembly for large-scale electrical installations where uptime matters. Feature: Compact dimensions (2.42 in length, 2.5 in width and height) and a pin contact configuration. Business Impact: Simplifies enclosure planning and enables dense connector arrays without compromising performance. Application: Space-constrained control cabinets and equipment racks in automation facilities. Feature: UL CZ Series certification and Ordinary/Non-Hazardous area classification. Business Impact: Provides regulatory assurance and safer operation in general industry environments, minimizing compliance risks. Application: Industrial plants with non-hazardous locations requiring certified mating components. Feature: Comprehensive installation guidance and access to standard literature. Business Impact: Accelerates onboarding, improves first-time right installations, and supports warranty compliance. Application: Maintenance teams and OEMs integrating Roughneck CZ insert kits into existing systems.Feature: Compatibility with Roughneck heavy-industrial connectors and extensive OEM literature. Business Impact: Streamlines procurement, ensures consistent performance across projects, and supports scalable deployment. Application: Large facility rollouts and multi-site automation programs where standardization matters.
