Eaton DL101 EM SP Legend Plate - NEMA 9 3R 7 12
Part Number: DL101 EM SP
Quick Summary
Eaton Crouse-Hinds FlexStation DL legend plate clearly labels emergency stop points for hazardous-location control panels. In harsh environments, inconsistent labeling and non-compliant components slow maintenance and increase misoperation risk. This part is NEC/CEC compliant for hazardous locations and carries NEC hazard ratings along with NEMA 9, 3R, 7 and 12 protection, ensuring robust performance in demanding settings. Designed for quick integration with FlexStation control-station components, it speeds commissioning and reduces wiring errors, boosting uptime and plant productivity. By using this legend plate, engineering teams ensure consistent labeling standards across panels, simplifying audits and maintenance planning.
Product Information
Extended Description
DL101 EM SP Eaton Crouse-Hinds: Eaton Crouse-Hinds series FlexStation DL legend plate, Emer Stop, Used with single-hole covers
Product Name
Eaton Crouse-Hinds series FlexStation DL legend plate
Catalog Number
DL101 EM SP
Product Length/Depth
2.25 in
Product Height
1.5 in
Product Width
0.01 in
Product Weight
0.19 lb
UPC
662276453883
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Zone 1 Class III Class I, Division 2 Class II, Division 1 Class I, Zone 2 Class II, Division 2
NEMA Rating
9 3R 7 12
Legend plate inscription
Emer Stop
Type
Used with single-hole covers
FlexStation Explosionproof Control Station Components catalog page
FlexStation Explosionproof Control Station Components UL certification (Components)
FlexStation Explosionproof Control Station Components UL certification (Components)
FlexStation Explosionproof Control Station Components UL certification (Components)
IF 1418 - FlexStation Series Control Stations
IF 1418 - FlexStation Series Control Stations
IF 1418 - FlexStation Series Control Stations
Eaton Specification Sheet - DL101 EM SP
Feature → Business Impact → Application: The DL101 EM SP provides a dedicated Emer Stop legend inscription, improving operator clarity and reducing misaction in critical stop circuits. This translates to lower incident rates and faster incident response during commissioning and routine operation in hazardous locations. Application: ideal for emergency stop circuits within FlexStation DL control stations at chemical, oil & gas, and metal-processing facilities. Feature → Business Impact → Application: Compact dimensions (2.25 in length, 1.5 in height) and light 0.19 lb weight enable tight panel packing and easier retrofits. Impact: frees valuable space on crowded control enclosures and simplifies panel reorganizations without sacrificing legibility. Application: supports dense automation panels and retrofit projects where space is at a premium. Feature → Business Impact → Application: NEC/CEC compliance with Class I, Division 1 and Division 2 ratings, plus NEMA 9, 3R, 7 and 12 protection, provides regulatory assurance and UL compatibility. Impact: reduces engineering risk, eases third-party approvals, and simplifies audits. Application: hazardous-location installations across industries such as refining, chemical processing, and mining. Feature → Business Impact → Application: Compatibility with single-hole covers and FlexStation explosionproof components streamlines procurement and installation. Impact: lowers total cost of ownership by standardizing parts and reducing SKU proliferation. Application: new builds and retrofit projects in explosion-protected enclosures. Feature → Business Impact → Application: Accessible installation instructions and installation sheets (IF 1418 references) shorten commissioning time. Impact: minimizes field errors, accelerates project timelines, and supports on-time handover. Application: field deployment in regulated facilities and multi-panel installations. Industry Insight: The DL101 EM SP is designed for reliability in harsh industrial environments, where legible labeling and certified enclosure compatibility translate to measurable maintenance savings and safer, compliant operations.
