Eaton DL101 RN FlexStation DL - Hazardous Locations
Part Number: DL101 RN
Quick Summary
The Eaton DL101 RN FlexStation DL legend plate provides clear labeling for hazardous-location control stations in compact panels. Engineering teams struggle with space constraints, single-hole cover compatibility, and meeting hazardous-location labeling standards. It aligns with NEC/CEC standards and broad hazardous ratings, including Class I, Division 1 and 2, Zone 1 and 2, plus NEMA 3R. Designed for FlexStation installations in hazardous locations, it simplifies maintenance workflows and reduces panel downtime while supporting efficient labeling workflows. Its rugged construction and clear inscription options help technicians quickly identify circuits, improving safety audits and downtime planning. Ordering with DL101 RN ensures spare-part readiness and consistent documentation across projects.
Product Information
Extended Description
DL101 RN Eaton Crouse-Hinds: Eaton Crouse-Hinds series FlexStation DL legend plate, Run, Used with single-hole covers
Product Name
Eaton Crouse-Hinds series FlexStation DL legend plate
Catalog Number
DL101 RN
Product Length/Depth
2.25 in
Product Height
1.5 in
Product Width
0.01 in
Product Weight
0.19 lb
UPC
662279104614
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 2 Class II, Division 2 Class I, Division 1 Class III Class I, Zone 2 Class I, Zone 1 Class II, Division 1
NEMA Rating
3R 9 12 7
Legend plate inscription
Run
Type
Used with single-hole covers
FlexStation Explosionproof Control Station Components catalog page
FlexStation Explosionproof Control Station Components UL certification
FlexStation Explosionproof Control Station Components UL certification
FlexStation Explosionproof Control Station Components UL certification
IF 1358 - Replacing Plastic Buttons on EDS Series
IF 1358 - Replacing Plastic Buttons on EDS Series
IF 1358 - Replacing Plastic Buttons on EDS Series
Eaton Specification Sheet - DL101 RN
Feature: Run legend inscription ensures quick circuit identification → Business Impact: Accelerates diagnosis and reduces mislabeling → Application: Used with single-hole covers in FlexStation hazardous-location panels. Feature: NEC/CEC compliance with Class I, Division 1 & 2 and Zone 1 & 2 ratings → Business Impact: Regulatory conformity and safer operations → Application: Suitable for explosionproof control stations in harsh environments. Feature: NEMA ratings including 3R, 9, 12, 7 → Business Impact: Expanded enclosure compatibility and durability → Application: Outdoor and heavy-industrial installations. Feature: Explicit compatibility with single-hole covers → Business Impact: Faster field retrofits and lower installation time → Application: Retrofit projects and new builds requiring standardized labeling. Feature: Comprehensive documentation and UL-related resources in downloads → Business Impact: Reduced procurement risk and faster approval processes → Application: Compliance-driven projects and audits. Feature: Legend plate inscription 'Run' and precise dimensions (2.25 in L, 1.5 in H, 0.01 in W) → Business Impact: Predictable fit and consistent labeling across panels → Application: Dense-panel environments with space constraints in hazardous locations.
Get a Quick Quote for a Eaton Crouse-Hinds DL101 RN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds DL101 RN?
Enquire Now
FAQs
Plan for compatibility with single-hole covers and the two-and-a-quarter inch length by one-and-a-half inch height of the plate. Use standard mounting hardware and verify that the enclosure rating remains intact after installation. The plate is designed for Run inscription labeling and integrates with FlexStation DL series components to maintain hazardous-location integrity.
The DL101 RN supports NEC/CEC standards and a broad set of hazardous-location ratings, including Class I, Division 1 and 2, and Zone 1 and 2, along with a NEMA 3R compatibility. This alignment helps engineers meet regulatory labeling requirements without modifying the enclosure or control panel.
Yes. Its dimensions and single-hole cover compatibility make it ideal for retrofits and ongoing maintenance. By using the DL101 RN, technicians can replace or upgrade legend labeling quickly while preserving existing explosionproof configurations and compliance across the FlexStation system.
It aligns with NEC/CEC standards and carries hazardous-location ratings such as Class I, Division 1 & 2, Zone 1 & 2, plus a NEMA 3R rating. UL certifications are documented in the downloadable resources, providing verification for safety approvals and regulatory audits.
Using the DL101 RN reduces labeling errors, speeds maintenance and audits, and improves overall panel uptime. The consistent Run inscription and precise dimensions simplify installation, improve safety training, and support faster project approvals, delivering measurable ROI in hazardous-location control panels.
