Eaton Crouse-Hinds DL132 Legend Plate - Hazardous Locations
Part Number: DL132
Quick Summary
The Eaton Crouse-Hinds DL132 legend plate provides Open-Close labeling for FlexStation DL control stations in hazardous locations. In crowded or rugged panels, unclear labeling and damaged legends slow maintenance and raise safety risks; a durable plate reduces downtime. It complies with NEC/CEC standards and supports Hazardous/Classified Locations, with NEMA ratings 9, 12, 3R and 7 for rugged industrial service. Using this plate with single-hole covers streamlines installation, inventory, and compliance reporting while easing future inspections. For engineering teams, the DL132 delivers reliable, standards-aligned branding with minimal footprint, supporting efficient changeouts and operational uptime.
Product Information
Extended Description
DL132 Eaton Crouse-Hinds: Eaton Crouse-Hinds series FlexStation DL legend plate, Open-Close, Used with single-hole covers
Product Name
Eaton Crouse-Hinds series FlexStation DL legend plate
Catalog Number
DL132
Product Length/Depth
2.25 in
Product Height
1.5 in
Product Width
0.01 in
Product Weight
0.01 lb
UPC
662276095052
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 2 Class II, Division 1 Class III Class I, Division 1 Class II, Division 2 Class I, Zone 1 Class I, Zone 2
NEMA Rating
9 12 3R 7
Legend plate inscription
Open-Close
Type
Used with single-hole covers
FlexStation Explosionproof Control Station Components catalog page
FlexStation Explosionproof Control Station Components UL certification
FlexStation Explosionproof Control Station Components UL certification
FlexStation Explosionproof Control Station Components UL certification
IF 1418 - FlexStation Series Control Stations
IF 1418 - FlexStation Series Control Stations
IF 1418 - FlexStation Series Control Stations
Eaton Specification Sheet - DL132
Feature: Compact dimensions and lightweight construction (2.25 in length, 1.5 in height, 0.01 in width, 0.01 lb) enable easy stocking and minimal panel intrusion. Business Impact: Reduces cabinet crowding and maintenance time, improving overall efficiency in refurbishment projects. Application: Ideal for retrofits in space-constrained FlexStation DL installations where quick legend updates are required. Feature: Hazardous location compliance with NEC/CEC and area classifications. Business Impact: Ensures regulatory conformity and safer operation in Class I, Division 1/2; Zone 1/2 environments, reducing compliance risk and audit findings. Application: Suitable for explosion-proof control stations in petrochemical and manufacturing facilities. Feature: NEMA ratings of 9, 12, 3R, and 7 provide robust protection against environmental factors. Business Impact: Extends service life in harsh environments, lowering maintenance costs and downtime. Application: Used in outdoor enclosures or wet, dusty industrial areas attached to FlexStation components. Feature: Legend plate inscription Open-Close and type compatibility with single-hole covers. Business Impact: Improves operator clarity and minimizes labeling errors during open/close operations. Application: Fastens to single-hole cover assemblies for quick state indication in hazardous zones. Feature: Compact, purpose-built for FlexStation DL control stations. Business Impact: Streamlines procurement and installation workflows, reducing lead times and training requirements. Application: Replacement legend plates in OEM and service-provider installations that demand conformity with Eaton Crouse-Hinds labeling standards.
Get a Quick Quote for a Eaton Crouse-Hinds DL132
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds DL132?
Enquire Now
FAQs
DL132 is designed to fit FlexStation DL control stations and uses a Open-Close inscription to clearly indicate status. It is certified for Hazardous/Classified Locations under NEC/CEC and carries relevant NEMA ratings, ensuring dependable performance in Class I/II and Zone locations.
DL132 supports Hazardous/Classified Locations with NEC/CEC standards, NEC hazardous ratings including Class I Divisions 1/2 and Class II/III, and Zone classifications. It also aligns with NEMA ratings 9, 12, 3R, and 7 for rugged protection.
Yes. The DL132 is specifically designed for use with single-hole covers, simplifying installation and ensuring consistent labeling across Eaton Crouse-Hinds FlexStation DL assemblies.
The plate measures 2.25 inches in length, 1.5 inches in height, and 0.01 inches in thickness, with an approximate weight of 0.01 lb, making it ideal for compact control station labeling.
By providing durable, compliant Open-Close labeling in hazardous locations, the DL132 reduces labeling errors, shortens maintenance cycles, and supports inspections, contributing to higher uptime and lower lifecycle costs for explosion-proof control stations.
