Eaton Crouse-Hinds DL191 Legend Plate - Hazardous Locations
Part Number: DL191
Quick Summary
The Eaton Crouse-Hinds DL191 legend plate provides a durable On-Off labeling solution for FlexStation DL control stations in hazardous locations. Installation challenges, such as unreadable or faded markings amid harsh environments, can lead to misoperation and downtime. This DL191 is certified for Hazardous/Classified Locations with NEC/CEC compliance and compatible NEMA ratings, ensuring safety and reliability. By delivering clear, long-lasting inscriptions, it supports faster commissioning and easier maintenance while aligning with installation best practices, single-hole cover compatibility, and industry-standard labeling requirements.
Product Information
Extended Description
DL191 Eaton Crouse-Hinds: Eaton Crouse-Hinds series FlexStation DL legend plate, On-Off, Used with single-hole covers
Product Name
Eaton Crouse-Hinds series FlexStation DL legend plate
Catalog Number
DL191
Product Length/Depth
2.25 in
Product Height
1.5 in
Product Width
0.01 in
Product Weight
0.01 lb
UPC
662276095243
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 2 Class II, Division 2 Class II, Division 1 Class III Class I, Zone 1 Class I, Zone 2 Class I, Division 1
NEMA Rating
12 9 7 3R
Legend plate inscription
On-Off
Type
Used with single-hole covers
FlexStation Explosionproof Control Station Components catalog page
FlexStation Explosionproof Control Station Components UL certification (Components)
FlexStation Explosionproof Control Station Components UL certification (Components)
FlexStation Explosionproof Control Station Components UL certification (Components)
IF 1928 - FlexStation Series Control Stations
IF 1928 - FlexStation Series Control Stations
IF 1928 - FlexStation Series Control Stations
Eaton Specification Sheet - DL191
Feature: On-Off legend plate for FlexStation DL control stations. Business Impact: Clear status indication reduces labeling errors and mis-operation, boosting overall safety and uptime. Application: Ideal for hazard-prone environments where quick visual confirmation is critical. Feature: Hazardous/Classified Locations area classification with NEC/CEC standards. Business Impact: Regulatory alignment minimizes compliance risk and accelerates audit readiness. Application: Suitable for facilities with hazardous locations requiring UL-listed components. Feature: Compact dimensions and light weight (2.25 in length/depth, 1.5 in height, 0.01 in width, 0.01 lb). Business Impact: Simplifies panel space planning and reduces installation time in tight enclosures. Application: Fits FlexStation DL assemblies when space is constrained. Feature: Single-hole cover compatibility. Business Impact: Streamlines retrofits and reduces parts variety, lowering inventory cost. Application: Easy integration into existing FlexStation DL setups. Feature: Certifications and documentation including UL certs and installation sheets IF1928. Business Impact: Provides installers with ready-to-use references, improving project certainty and commissioning speed. Application: Supports compliant installation workflows and faster training for maintenance teams.
Get a Quick Quote for a Eaton Crouse-Hinds DL191
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds DL191?
Enquire Now
FAQs
The DL191 legend plate is designed for use with Eaton Crouse-Hinds FlexStation DL control stations and is specified to work with single-hole covers. It supports straightforward retrofits and new installations alike, helping to maintain a clean panel topology while delivering clear status indication in challenging environments.
The DL191 carries Hazardous/Classified Locations area classification with NEC/CEC standards and UL certifications for US and Canada. It is also compatible with relevant NEMA ratings (12, 9, 7, 3R), ensuring compliance and safety across hazardous-location applications.
Key specifications include a product length/depth of 2.25 inches, product height of 1.5 inches, product width of 0.01 inches, and product weight of 0.01 lb. These compact dimensions support easy integration into tight panel spaces while maintaining legibility.
By providing a durable On-Off inscription with readable markings, the DL191 reduces labeling errors and misoperation, contributing to safer operation and reduced downtime. Its hazardous-location certifications further ensure long-term reliability in demanding environments.
Installation resources include IF 1928 instruction sheets and the FlexStation catalog pages. These documents provide guidance for correct mounting, wiring, and labeling integration, ensuring compliant and efficient commissioning of FlexStation DL systems.
