Eaton DL193 FlexStation DL Plate - Hazardous Locations
Part Number: DL193
Quick Summary
The Eaton Crouse-Hinds DL193 FlexStation legend plate provides local-remote labeling for hazardous-location control stations. This compact component ensures clear, durable identification where safety and reliability matter most. Engineers often contend with illegible markings, mislabeling, and difficult updates in harsh or remote environments; the DL193 addresses these challenges with a robust, NEC/CEC-compliant solution. It supports wide hazardous-location ratings, including Class I Zones 1–2 and Class II/III locations, and pairs with multiple NEMA configurations (12, 7, 9, 3R). Used with single-hole covers, it integrates smoothly with FlexStation components, reducing maintenance time and retrofit costs while improving labeling readability and regulatory compliance for your hazardous-area installations.
Product Information
Extended Description
DL193 Eaton Crouse-Hinds: Eaton Crouse-Hinds series FlexStation DL legend plate, Local-Remote, Used with single-hole covers
Product Name
Eaton Crouse-Hinds series FlexStation DL legend plate
Catalog Number
DL193
Product Length/Depth
2.25 in
Product Height
1.5 in
Product Width
0.01 in
Product Weight
0.01 lb
UPC
662276095267
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class II, Division 2 Class I, Division 2 Class I, Zone 2 Class II, Division 1 Class I, Zone 1 Class I, Division 1 Class III
NEMA Rating
12 7 9 3R
Legend plate inscription
Local-Remote
Type
Used with single-hole covers
FlexStation Explosionproof Control Station Components catalog page
FlexStation Explosionproof Control Station Components UL certification
FlexStation Explosionproof Control Station Components UL certification
FlexStation Explosionproof Control Station Components UL certification
IF 1418 - FlexStation Series Control Stations
IF 1418 - FlexStation Series Control Stations
IF 1418 - FlexStation Series Control Stations
Eaton Specification Sheet - DL193
Feature: Local-Remote inscription for clear operation labeling → Business Impact: Reduces operator error and miswiring in hazardous environments → Application: Ideal for FlexStation control stations where Local-Remote indication matters. Feature: Compact footprint and precise dimensions (2.25 in L × 1.5 in H × 0.01 in W) → Business Impact: Minimal intrusion on panel space and fast retrofit in crowded setups → Application: Replaces bulky plates without sacrificing readability. Feature: NEC/CEC compliance and broad hazardous-location ratings (Class I/II/III; Zones 1–2; Divisions 1–2) → Business Impact: Simplifies compliance planning and audit readiness → Application: Fits chemical, oil, and industrial plants with strict safety requirements. Feature: NEMA ratings 12, 7, 9, 3R → Business Impact: Enhanced environmental resilience and longer service life → Application: Harsh-duty control panels exposed to dust, moisture, and vibration. Feature: Single-hole covers compatibility and documented installation guidance (IF 1418) → Business Impact: Streamlined installation and reduced field errors → Application: Facilitates quick commissioning and maintenance. Feature: Availability of specification sheets and UL certification references → Business Impact: Builds confidence for procurement and risk assessment → Application: Supports formal design reviews and regulatory submissions.
Get a Quick Quote for a Eaton Crouse-Hinds DL193
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds DL193?
Enquire Now
FAQs
The DL193 is designed specifically for FlexStation control stations and is compatible with single-hole covers. To install, align the plate with the mounting holes on the cover, secure with standard hardware, and ensure the Local-Remote inscription is clearly visible. Refer to the IF 1418 FlexStation installation sheets for step-by-step guidance and to the DL193 specification for exact fitment details.
The DL193 supports NEC/CEC-compliant labeling for hazardous locations, including Class I Zones 1 and 2, Class II Divisions 1 and 2, and Class III. It also carries NEMA ratings 12, 7, 9, and 3R, providing broad environmental resilience and suitability for explosion-proof environments in diverse industrial settings.
Yes. The DL193 is a FlexStation legend plate intended for use with explosion-proof control stations in hazardous locations. Its Local-Remote inscription, compatible dimensions, and NEC/CEC compliance support safe operation, clear labeling, and reliable performance in chemical plants, refineries, and other environments with strict safety requirements.
The DL193 meets NEC/CEC standards and is rated for a variety of hazardous locations (Class I, II, III; Zones 1–2; Divisions 1–2). It is associated with UL-certified components and documented certification reports for use in hazardous locations, alongside compatible NEMA ratings and explosion-proof design expectations commonly referenced in Eaton’s FlexStation documentation.
You can access installation documentation and specifications through Eaton’s resources: IF 1418 FlexStation instruction sheets, the FlexStation catalog page, and the DL193 specification sheet. These documents provide mounting guidance, compatibility notes with single-hole covers, and concise technical data to support design reviews, procurement, and maintenance planning.
