Eaton DL49 Legend Plate - Hazardous/Classified Locations
Part Number: DL49
Quick Summary
Eaton DL49 legend plate provides clear labeling for FlexStation DL control stations used in hazardous locations. Accurate labeling reduces maintenance downtime and prevents mis-wiring during routine servicing. It carries NEC/CEC compliance with hazardous location ratings (Class I, Division 1/2; Zone 1/2) and compatible NEMA configurations, empowering safer, faster wiring and audits. By standardizing inscriptions such as Auto-Off-Hand, it supports compliance documentation and operator training across teams. Compatible with 2- or 3-hole covers, this plate delivers reliable labeling where space is tight, helping facilities meet regulatory requirements while keeping downtime to a minimum.
Product Information
Extended Description
DL49 Eaton Crouse-Hinds: Eaton Crouse-Hinds series FlexStation DL legend plate, Auto-Off-Hand, Used with 2- or 3-hole covers
Product Name
Eaton Crouse-Hinds series FlexStation DL legend plate
Catalog Number
DL49
Product Length/Depth
2.25 in
Product Height
1.5 in
Product Width
0.01 in
Product Weight
0.15 lb
UPC
662276038158
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 2 Class I, Zone 2 Class II, Division 2 Class I, Division 1 Class I, Zone 1 Class II, Division 1 Class III
NEMA Rating
9 12 3R 7
Legend plate inscription
Auto-Off-Hand
Type
Used with 2- or 3-hole covers
FlexStation Explosionproof Control Station Components catalog page
FlexStation Explosionproof Control Station Components UL certification
FlexStation Explosionproof Control Station Components UL certification
FlexStation Explosionproof Control Station Components UL certification
IF 1418 - FlexStation Series Control Stations
IF 1418 - FlexStation Series Control Stations
IF 1418 - FlexStation Series Control Stations
Eaton Specification Sheet - DL49
Feature: Clear legend plate inscription Auto-Off-Hand. Business Impact: Improves operator awareness and safety by clearly indicating switch state. Application: Used on FlexStation DL control stations in hazardous locations to prevent misinterpretation during maintenance. Feature: Compact 2.25 in length and 1.5 in height with a slim 0.01 in width and 0.15 lb weight. Business Impact: Enables labeling without crowding the panel, reducing installation time and panel density concerns. Application: Suitable for tight electrical enclosures and 2- or 3-hole covers. Feature: NEC/CEC compliance and Hazardous/Classified Locations area classification. Business Impact: Aligns with regulatory requirements, lowering audit risk and improving safety standings. Application: Ideal for Class I/Division 1 and Zone 1 environments with diverse NEMA enclosures (9, 12, 3R, 7). Feature: Compatibility with UL certification references and FlexStation series control stations. Business Impact: Simplifies procurement and reduces engineering changes during panel upgrades. Application: Seamless integration with existing explosionproof control station components and installation sheets. Feature: Auto-Off-Hand inscription and 2- or 3-hole cover compatibility. Business Impact: Standardized labeling accelerates training and maintenance routines, reducing human error. Application: Used across hazardous-area installations to support consistent operation and compliance practices.
