Eaton DS512 J3 J3 J1 LED SA - Hazardous Location LED NEC/CEC
Part Number: DS512 J3 J3 J1 LED SA
Manufacturer
Eaton Crouse-Hinds
Part number
DS512 J3 J3 J1 LED SA
Category
Quick Summary
DS512 J3 J3 J1 LED SA is a triple-pilot LED indicator sub-assembly used to signal machine status in hazardous locations. This design helps mitigate miscommunication and unsafe startup by delivering clear, color-coded signals right at the point of operation. It complies with NEC/CEC and area-classification requirements, including Class I Division 1 and 2, Class II and 3, and NEMA ratings 3, 7, 9. The copper-free aluminum housing and factory-sealed construction support long service life, reduced maintenance, and dependable signaling in demanding environments. Built for integration with Eaton Crouse-Hinds DSD covers, it adds value through robust signaling, easy installation, and scalable safety compliance for industrial automation systems.
Product Information
Extended Description
DS512 J3 J3 J1 LED SA Eaton Crouse-Hinds: Eaton Crouse-Hinds series DSD pilot light cover and device sub-assembly, Green/green/red, Copper-free aluminum, LED, factory sealed, Triple pilot light
Product Name
Eaton Crouse-Hinds series DSD pilot light cover and device sub-assembly
Catalog Number
DS512 J3 J3 J1 LED SA
Product Weight
3 lb
UPC
662276700536
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class II, Division 2 Class III Class I, Division 2 Class II, Division 1 Class I, Division 1
NEMA Rating
3 7 9
Color
Green/Green/Red
Material
Copper-free aluminum
Special features
LED, factory sealed
Type
Triple pilot light
DSD and DSDX Cover and Device Sub-assemblies catalog page
DSD Explosionproof Cover and Device Sub-assemblies Canadian certification
DSD Explosionproof Cover and Device Sub-assemblies Canadian certification
IF 1929 - Toggle Operator for EDS, EDSX, EFD, DSD and DSDX Series
IF 1929 - Toggle Operator for EDS, EDSX, EFD, DSD and DSDX Series
IF 1929 - Toggle Operator for EDS, EDSX, EFD, DSD and DSDX Series
Eaton Specification Sheet - DS512 J3 J3 J1 LED SA
Feature to benefit mapping begins with the triple pilot light design, delivering a reliable Green/Green/Red indicator for rapid status recognition. This reduces operator errors and downtime in high-hazard areas, translating to improved production reliability and safety compliance. The copper-free aluminum housing provides corrosion resistance in harsh environments such as chemical plants and offshore facilities, lowering the risk of enclosure degradation and maintenance costs. The factory-sealed configuration minimizes dust, moisture, and explosive atmosphere ingress, supporting long intervals between service and lower total cost of ownership for hazardous-location installations. Compatibility with the DSD cover and device sub-assemblies streamlines installation, reduces field wiring complexities, and ensures consistent signaling across control panels. NEC/CEC certification and NEMA ratings 3, 7, 9 address both regulatory and environmental demands, enabling faster project approvals and audit readiness. Color-coded signaling aligns with industrial standards, improving operator response times in emergencies. The LED technology offers long life and low energy consumption, reducing replacement cycles and maintenance logistics. Industry-focused insight: in refinery, mining, and chemical sectors, this unit supports reliable remote signaling while preserving enclosure integrity and worker safety.
Get a Quick Quote for a Eaton Crouse-Hinds DS512 J3 J3 J1 LED SA
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds DS512 J3 J3 J1 LED SA?
Enquire Now
FAQs
DS512 J3 J3 J1 LED SA installs seamlessly with Eaton Crouse-Hinds DSD covers and device sub-assemblies. Verify compatibility with the DSD enclosure, maintain factory sealing, and use correct grommets or entries to preserve hazardous-location ratings. Follow the IF 1929 installation sheets to ensure proper mounting torque, wiring, and enclosure integrity for Division 1/2 environments.
This unit complies with NEC/CEC standards for Hazardous/Classified Locations, covering Class I Division 1 and 2, Class II Division 1 and 2, and Class III. It carries the associated area-classification approvals and is rated by NEMA for 3, 7, and 9 enclosures. The copper-free aluminum housing and factory sealing support reliable performance in demanding environments.
The triple-LED indicator delivers distinct Green/Green/Red signaling for clear status, enabling quick operator decisions and reducing startup errors. LED life offers low maintenance and energy efficiency, while the copper-free aluminum housing and factory seal provide durable protection against corrosion and ingress in harsh locations such as refineries and chemical plants.
Yes. It is well-suited for oil and gas processing, chemical manufacturing, mining, and other operations requiring reliable hazardous-location signaling. The device sub-assembly integrates with DSD covers, supporting control panels, motor starters, and signaling solutions that must meet NEC/CEC and NEMA 3, 7, 9 requirements while maintaining robust enclosure integrity.
The DS512 J3 J3 J1 LED SA weighs 3 lb and uses a copper-free aluminum housing. Its factory-sealed construction reduces maintenance needs and ingress risk, while its compatibility with DSD covers simplifies mounting. Plan for a lightweight, durable signaling module that integrates with existing hazardous-location control circuits without requiring special enclosure modifications.
