Eaton DSD961 J3 ST SP pilot light cover - NEC/CEC
Part Number: DSD961 J3 ST SP
Manufacturer
Eaton Crouse-Hinds
Part number
DSD961 J3 ST SP
Category
Quick Summary
DSD961 J3 ST SP pilot light cover and device sub-assembly delivers reliable status signaling for hazardous-location control panels. Operators often struggle with sealed enclosures that trap heat, promote corrosion, and complicate maintenance across harsh environments. This unit carries NEC/CEC certifications and hazardous-location approvals, plus compatible NEMA ratings to streamline compliance and long-term reliability. By combining a green START/STOP indicator with two pushbuttons in a factory-sealed package, it delivers clear visual feedback and robust control in hazardous areas, reducing downtime and maintenance costs. The solution also aligns with processor-friendly installation and maintenance workflows, enabling safer, faster field service and consistent performance in demanding industrial settings.
Product Information
Extended Description
DSD961 J3 ST SP Eaton Crouse-Hinds: Eaton Crouse-Hinds series DSD pilot light cover and device sub-assembly, Green, START/STOP, Feraloy iron alloy, 2 buttons, Factory sealed, One pilot light and one double pushbutton
Product Name
Eaton Crouse-Hinds series DSD pilot light cover and device sub-assembly
Catalog Number
DSD961 J3 ST SP
Product Weight
3.65 lb
UPC
782274068015
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 2 Class II, Division 2 Class II, Division 1 Class III Class I, Division 1
NEMA Rating
9 7 3
Number of cover buttons
2
Indicating plate markings
START/STOP
Color
Green
Material
Feraloy iron alloy
Special features
Factory sealed
Type
One pilot light and one double pushbutton
DSD and DSDX Cover and Device Sub-assemblies catalog page
DSD Explosionproof Cover and Device Sub-assemblies Canadian certification
DSD Explosionproof Cover and Device Sub-assemblies Canadian certification
IF 1424 - DSD, GFS, CPS and ENR Series Replacement Covers
IF 1424 - DSD, GFS, CPS and ENR Series Replacement Covers
IF 1424 - DSD, GFS, CPS and ENR Series Replacement Covers
Eaton Specification Sheet - DSD961 J3 ST SP
Feature → Business Impact → Application: Two-button START/STOP control and a dedicated pilot light provide immediate, at-a-glance status in control panels, reducing operator errors and response times in high-risk environments. This improves overall equipment effectiveness (OEE) and enhances safety during start-up and shutdown sequences in oil, gas, chemical, and marine facilities. Feature → Feraloy iron alloy construction delivers high strength and durability, improving enclosure integrity in environments with vibration and impactsCommon applications include hazardous-area motor controls and actuator assemblies, where reliability directly ties to uptime and safety. Feature → Factory-sealed design minimizes ingress of dust, moisture, and corrosives, lowering maintenance cycles and extending lifecycle in salty, humid, or chemically aggressive plants. Feature → Green indicating plate and START/STOP markings provide intuitive feedback for operators, improving supervision, training agility, and standardization across multi-site operations. Feature → NEC/CEC compliance and NEMA ratings (9, 7, 3) simplify regulatory approvals, enabling faster project kickoff and reducing the risk of non-compliance penalties. Feature → Compatible with standard DSD cover and device sub-assemblies, allowing quick replacement and streamlined spare-part management, which lowers inventory costs and downtime during maintenance windows.
Get a Quick Quote for a Eaton Crouse-Hinds DSD961 J3 ST SP
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds DSD961 J3 ST SP?
Enquire Now
FAQs
The DSD961 J3 ST SP is designed for plug-in style installation within compatible enclosure cutouts. Begin by verifying NEC/CEC compliance for your area, then mount the unit to the existing cover frame, ensuring a secure seal to preserve the enclosure’s ingress protection. Confirm START/STOP markings align with your control logic and test the pilot light and pushbuttons in a non-live condition before commissioning.
Yes. This pilot light cover and device sub-assembly is specified for hazardous locations under NEC/CEC guidelines and carries NEC hazardous ratings appropriate for Class I, Division 1 and 2, Class II, Division 1 and 2, and Class III. It also supports the unit’s NEMA 9, 7, 3 enclosure compatibility, aiding regulatory approvals for industrial installations.
Applications include motor control stations, pump skids, and safety interlock circuits in chemical plants, refineries, offshore platforms, and machinery rooms. The dual pushbuttons provide dedicated start/stop control, while the pilot light offers real-time status visibility, enabling safer operation, quicker fault diagnosis, and reduced risk of unintended starts in hazardous environments.
It supports NEC/CEC compliance, hazardous-location ratings including Class I/ Division 1 and 2, Class II/ Division 1 and 2, and Class III, along with NEMA 9, 7, 3 ratings. The green indicator and factory-sealed design further ensure suitability for hazardous area equipment, offshore, mining, and chemical processing installations.
The factory-sealed design reduces ingress-related failures, lowering maintenance intervals, while the robust Fer–aloy alloy construction improves durability in vibration-prone or corrosive environments. By standardizing on a compatible DSD cover sub-assembly, you simplify spare parts, accelerate commissioning, and minimize downtime during start-up/shutdown transitions, delivering tangible total cost of ownership improvements.
