Eaton Cam-Lok E1012-61 Plug - 120V, 315A Continuous
Part Number: E1012-61
Quick Summary
The Eaton Cam-Lok E1012-61 plug provides a robust power interconnect for heavy industrial equipment in harsh environments. Engineers rely on durable connectors to minimize downtime in motors, conveyors, and process lines. The E1012-61 resists vibration and field wear while delivering reliable current transfer at 120 VAC. It meets NEC/CEC standards and carries a NEMA 1 rating for ordinary/non-hazardous locations, ensuring safe installation across factory floors and control rooms. With reinforced thermoplastic housing and brass contacts, it combines durability with dependable conductivity. Cam-Lok F Series compatibility and a set-screw connection support quick field maintenance and broader cable-size range (#2-1/0 AWG).
Product Information
Extended Description
E1012-61 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Cam-Lok F Series E1012 plug, Up to 315A continuous, 550A intermittent, #2-1/0 AWG, Red, Set screw, Brass contacts, Male, Reinforced thermoplastic, 120 Vac
Product Name
Eaton Crouse-Hinds series Cam-Lok F Series E1012 plug
Catalog Number
E1012-61
Product Length/Depth
3.86 in
Product Height
1.19 in
Product Width
1.19 in
Product Weight
1 lb
UPC
662275126214
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
1
Cable size
#2-1/0 AWG
Amperage Rating
Up to 315A Continuous, 550A Intermittent
Voltage rating
120 Vac
Material
Reinforced thermoplastic
Connection type
Set screw
Color
Red
Gender
Male
Contact material
Brass
Cam-Lok Single Pole Plugs and Receptacles catalog
Cam-Lok F Series Single Pole Plugs and Receptacles catalog page
EB 8 - Cam-Lok E1012 Connectors
Eaton Specification Sheet - E1012-61
Feature → Business Impact → Application: The E1012-61 uses a reinforced thermoplastic housing and brass contacts to deliver high-current performance with vibration resistance. This translates to fewer field failures and lower maintenance costs in continuous-run equipment. In applications like CNC machines, conveyors, and pumps, the connector remains reliable under harsh conditions, reducing unplanned downtime. The compatibility with #2-1/0 AWG cables enables broad cable routing options, while the set screw connection ensures secure, time-saving installation. Cable and current specs provide up to 315A continuous and 550A intermittent at 120 VAC, delivering headroom for peak loads without overheating. This helps streamline panel design and reduce total installed cost by avoiding unnecessary splices or parallel connections. Durability and safety features include a robust reinforced thermoplastic housing for impact resistance, a vivid red color for visibility in busy facilities, and a NEMA 1 enclosure rating aligned with NEC/CEC compliance for ordinary/non-hazardous locations.
Get a Quick Quote for a Eaton Crouse-Hinds E1012-61
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds E1012-61?
Enquire Now
FAQs
To install, power down the circuit, prepare #2-1/0 AWG conductors, and route them into the set-screw terminals on the E1012-61 plug. Tighten to the recommended torque, ensure the brass contacts are clean, and mate with a compatible Cam-Lok F Series receptacle. Use the reinforced thermoplastic housing for protection and ensure proper cable routing to maintain strain relief.
The E1012-61 is rated for 120 VAC with a continuous current rating up to 315A and an intermittent rating of 550A. It accepts #2-1/0 AWG cables and uses brass contacts with a set-screw termination to maintain low contact resistance during high-load operation.
Yes. The plug is specified for Ordinary/Non-Hazardous Locations with a NEMA 1 enclosure rating and NEC/CEC compliance, making it appropriate for factory floors, control rooms, and typical automation environments where standard power distribution is required.
The E1012-61 complies with NEC/CEC standards and carries a NEMA 1 rating. It is designed for ordinary/non-hazardous locations, with CAM-Lok F Series compatibility that ensures consistent performance across a wide range of industrial power connections.
The set-screw termination and brass contacts deliver durable, low-resistance connections that are easier to service in the field. The reinforced thermoplastic housing withstands industrial wear, and its compatibility with Cam-Lok accessories supports quick replacements and scalable power distribution, reducing downtime and long-term maintenance costs.
