Eaton Crouse-Hinds E1016-8387 Cam-Lok J Plug - 3R 600V/400A
Part Number: E1016-8387
Quick Summary
Eaton Crouse-Hinds Cam-Lok J Series E1016 plug provides rugged, high-current power connections for industrial wiring. Engineers often face downtime during connector changes, and mismatched fittings or loose contacts can cause costly repairs and unplanned shutdowns. This plug meets NEC/CEC standards and carries a NEMA 3R enclosure rating for reliable use in ordinary/non-hazardous locations, including some outdoor or damp environments. It supports 2/0–4/0 AWG conductors and delivers up to 400 A continuous with a 600 V AC/DC rating, making it suitable for heavy machinery, power distribution, and mobile equipment. The brass contacts and thermoplastic elastomer housing enhance conductivity and durability, delivering long service life and predictable performance in harsh conditions.
Product Information
Extended Description
E1016-8387 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Cam-Lok J Series E1016 plug, Up to 400A continuous, 2/0-4/0 AWG, Black, Double set screw, Brass contacts, Female, Thermoplastic elastomer (TPE), Non-vulcanized, 600 Vac/dc
Product Name
Eaton Crouse-Hinds series Cam-Lok J Series E1016 plug
Catalog Number
E1016-8387
Product Length/Depth
7.18 in
Product Height
1.5 in
Product Width
1.5 in
Product Weight
0.6 lb
UPC
662275131874
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
3R
Cable size
2/0-4/0 AWG
Amperage Rating
Up to 400A Continuous
Voltage rating
600 Vac/dc
Material
Thermoplastic elastomer (TPE)
Type
Non-vulcanized
Connection type
Double set screw
Gender
Female
Color
Black
Contact material
Brass
Cam-Lok Single Pole Plugs and Receptacles catalog
Cam-Lok J Series Single Pole Plugs and Receptacles catalog page
IM 1004 - Cam-Lok E1016 and E1018 Double Set Screw
IM 1004 - Cam-Lok E1016 and E1018 Double Set Screw
IM 1004 - Cam-Lok E1016 and E1018 Double Set Screw
Eaton Specification Sheet - E1016-8387
High-current capability up to 400A continuous supports heavier loads with fewer components, reducing wiring complexity and potential fault points. It accepts 2/0–4/0 AWG conductors, enabling longer runs with consistent performance in mining, large conveyors, and heavy machinery. Feature: Double set screw connection. Business impact: Secure grip on conductors, resisting loosening under vibration and shocks. Application: outdoor equipment, conveyors, and mobile machinery in manufacturing environments. Feature: Brass contact material. Impact: Low contact resistance improves efficiency and reduces heat during high-current operation, contributing to longer service life of power feeds and panels. Application: power distribution and motor feeder connections in demanding facilities. Feature: Thermoplastic elastomer housing (TPE). Impact: Durable, chemical-resistant enclosure that withstands oils, dust, and solvents common on factory floors. Application: harsh environments where long-term integrity matters. Feature: Cable size compatibility 2/0-4/0 AWG and compact form factor. Impact: Reduces need for adapters and simplifies sourcing across projects. Application: integration with existing Cam-Lok reels, receptacles, and distributed power systems. Feature: Certifications and compliance. Impact: NEC/CEC alignment and a NEMA 3R rating support safer, regulatorily compliant installations. Application: facilities with strict standards and outdoor or protected-enclosure needs.
Get a Quick Quote for a Eaton Crouse-Hinds E1016-8387
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds E1016-8387?
Enquire Now
FAQs
The E1016-8387 supports 2/0–4/0 AWG conductors and can carry up to 400 A continuous. It is rated for 600 V AC/DC and uses brass contacts with a double set screw in a thermoplastic elastomer housing, ensuring a secure, reliable connection in industrial power feeds.
Wire the conductors into the double set screws per the 2/0–4/0 AWG range, tighten to the appropriate torque, and ensure correct polarity. Use the black female plug with brass contacts in a clean, dry environment. Verify mating receptacle alignment and reseat after a short cycle test to confirm a vibration-resistant connection.
Yes. The E1016-8387 is designed for ordinary/non-hazardous locations and carries a NEMA 3R rating, making it suitable for some outdoor or damp environments when used with appropriate enclosures and installation practices.
The plug complies with NEC/CEC standards and features a NEMA 3R enclosure rating. It is intended for ordinary/non-hazardous locations, providing regulatory alignment and safety assurances for industrial power connections.
The high-current capability and secure double-set-screw connection reduce downtime from failed or loose connectors, lowering maintenance costs. Durable brass contacts and a rugged TPE housing resist wear, enabling longer service intervals, fewer spare parts, and improved overall equipment availability.
