Eaton Cam-Lok E1017-52 Plug - 600 Vac/dc, J Series
Part Number: E1017-52
Quick Summary
Cam-Lok J Series E1017 plug provides rugged, rapid power connection for industrial equipment. Engineers often battle unreliable connections, downtime, and safety concerns in harsh environments. With an IEC/NEC framework and NEMA 4 protection, this plug is designed for ordinary/non-hazardous locations while meeting NEC/CEC standards. Up to 445 A continuous at 600 V supports scalable installations, reducing the need for multiple terminations and costly rework. By delivering robust connectivity and quick engagement, it enables safer field wiring, easier maintenance, and longer service life, ultimately lowering total cost of ownership in demanding manufacturing and processing environments.
Product Information
Extended Description
E1017-52 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Cam-Lok J Series E1017 plug, Up to 445A continuous, 350 kcmil, Red, Crimp, Brass contacts, Female, Rubber, Vulcanized, 600 Vac/dc
Product Name
Eaton Crouse-Hinds series Cam-Lok J Series E1017 plug
Catalog Number
E1017-52
Product Length/Depth
7.38 in
Product Height
2.69 in
Product Width
2.69 in
Product Weight
4.16 lb
UPC
662275133151
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
4
Cable size
350 kcmil
Amperage Rating
Up to 445A Continuous
Voltage rating
600 Vac/dc
Material
Rubber
Type
Vulcanized
Connection type
Crimp
Gender
Female
Color
Red
Contact material
Brass
Cam-Lok Single Pole Plugs and Receptacles catalog
Cam-Lok J Series Single Pole Plugs and Receptacles catalog page
EB 94 - Cam-Lok E1017, E1019 and E1023 Connectors
Eaton Specification Sheet - E1017-52
Feature: Amperage rating Up to 445 A continuous with 350 kcmil cable. Business Impact: Enables direct, high-current feeds to large motors and feeders, cutting wiring complexity and avoiding parallel connections. Application: Power distribution for heavy machinery in manufacturing floors. Feature: Crimp connection with brass contacts. Business Impact: Delivers a reliable, vibration-resistant contact that minimizes hot spots and oxidation. Application: Field installs where equipment experiences constant motion or vibration. Feature: 350 kcmil cable size compatibility. Business Impact: Allows large-diameter conductors to be terminated directly, reducing junctions and potential losses. Application: High-current feeders in industrial plants. Feature: 600 Vac/dc voltage rating. Business Impact: Supports mixed AC/DC systems with consistent performance and safety. Application: Control panels and power distribution networks. Feature: Rubber vulcanized, red enclosure. Business Impact: Provides resistance to environmental factors and wear, extending service life. Application: Outdoor and rugged indoor settings such as construction sites and warehouse yards. Feature: NEMA 4 rating and NEC/CEC compliance. Business Impact: Ensures code-compliant, weather-resistant operation, minimizing compliance risk. Application: Outdoor installations in ordinary locations where ingress protection matters. Feature: Female gender and Cam-Lok J Series mating design. Business Impact: Facilitates quick, secure mating with minimal misalignment. Application: Receptacle and plug pairing in modular power systems.
Get a Quick Quote for a Eaton Crouse-Hinds E1017-52
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds E1017-52?
Enquire Now
FAQs
The E1017-52 Cam-Lok J Series plug supports up to 350 kcmil cable, enabling direct high-current connections without intermediate terminations. This simplifies field wiring, reduces resistance losses, and improves overall reliability in heavy-load applications such as motor feeders and main power feeds.
Yes. The connector is rated for Ordinary/Non-Hazardous Locations and carries a NEMA 4 enclosure rating, making it suitable for outdoor or semi-exposed industrial installations. NEC/CEC compliance further ensures it meets relevant electrical codes for such environments.
This is a female plug designed for Cam-Lok J Series mating with corresponding receptacles. The crimp brass contacts and vulcanized rubber housing provide reliable contact and environmental protection. Ensure compatible J Series receptacles are used to achieve proper engagement and seal integrity.
Plan for proper crimp terminations with approved tooling and conductors up to 350 kcmil. Verify fitment with NEC/CEC guidelines and inspect the vulcanized rubber housing for signs of wear or cracking after heavy use. Regular inspection during routine maintenance minimizes risk of arcing and ensures continued compliance.
By supporting up to 445 A continuous at 600 V, reducing junctions with direct high-current feeds, and providing durable, weather-resistant construction, the E1017-52 lowers replacement frequency, minimizes downtime, and improves system reliability. This translates to lower maintenance costs and safer operation in demanding industrial settings.
