Eaton E1017-57 Cam-Lok J Series Plug - NEMA 4
Part Number: E1017-57
Quick Summary
The Eaton E1017-57 Cam-Lok J Series plug delivers robust high-current power connections for industrial panels and mobile equipment. Engineers often struggle with reliable crimp connections under heavy vibration and in non-hazardous locations where downtime hits the bottom line. This connector is rated to 600 Vac/dc, supports up to 545A continuous, and uses 500 kcmil conductors with brass, vulcanized rubber contacts for durability in harsh environments. Compliant with NEC/CEC standards and featuring a NEMA 4 rating, it ensures protection against dust and water exposure in ordinary locations. For buyers, this means faster installation, reduced maintenance, and dependable compatibility with Cam-Lok accessories and high-capacity cables, delivering tangible uptime gains and cost savings.
Product Information
Extended Description
E1017-57 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Cam-Lok J Series E1017 plug, Up to 545A continuous, 500 kcmil, Yellow, Crimp, Brass contacts, Female, Rubber, Vulcanized, 600 Vac/dc
Product Name
Eaton Crouse-Hinds series Cam-Lok J Series E1017 plug
Catalog Number
E1017-57
Product Length/Depth
7.38 in
Product Height
2.69 in
Product Width
2.69 in
Product Weight
4.16 lb
UPC
662275876973
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
4
Cable size
500 kcmil
Amperage Rating
Up to 545A Continuous
Voltage rating
600 Vac/dc
Material
Rubber
Type
Vulcanized
Connection type
Crimp
Gender
Female
Color
Yellow
Contact material
Brass
Cam-Lok Single Pole Plugs and Receptacles catalog
Cam-Lok J Series Single Pole Plugs and Receptacles catalog page
EB 94 - Cam-Lok E1017, E1019 and E1023 Connectors
Eaton Specification Sheet - E1017-57
Crimp connection with brass contacts ensures a secure, low-resistance path for high-current power. This reduces heat buildup and promotes electrical reliability in sudden-load applications. The E1017-57 is engineered for 500 kcmil conductors and continuous operation up to 545A, making it a strong fit for feeder connections in manufacturing lines and distribution panels. Rubber vulcanized body offers moisture resistance and rugged mechanical protection, extending service life in vibration-prone environments. The J Series Cam-Lok design enables fast mating and unmating, accelerating panel upgrades and field wiring without sacrificing safety. The bright yellow color aids visibility, helping technicians confirm correct orientation during messy installations. Compliance with NEC/CEC standards and a NEMA 4 rating translates into reliable performance in Ordinary/Non-Hazardous Locations, with proven protection against dust and splashing water. The 600 Vac/dc voltage rating and 500 kcmil cable size supports a wide range of industrial loads, from stationary equipment to mobile power carts. This alignment with codes minimizes risk during audits, while maintaining versatile, long-life connectivity. Compatibility with cam-lok accessories and standard crimp tooling simplifies procurement and spares planning across facilities. The female contact design ensures secure mating with corresponding male plugs, reducing mis-wiring and contact misalignment in tight spaces. Field serviceability is enhanced by readily available crimps and ferrules, lowering maintenance costs and downtime. From a business perspective, high amperage capability and rugged rubber body deliver measurable uptime gains, lower replacement costs, and predictable performance in demanding environments. With a 600 Vac/dc rating, 545A continuous capability, and 500 kcmil conductor support, this connector supports scalable distribution for power-intensive equipment. In short, the E1017-57 is a durable, code-compliant interconnect that keeps critical lines energized.
Get a Quick Quote for a Eaton Crouse-Hinds E1017-57
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds E1017-57?
Enquire Now
FAQs
To install the E1017-57 with 500 kcmil cable, verify that the mating half is present and compatible. Prepare the conductors, select the correct crimp tool, and terminate the conductors into the brass female contacts per the installation sheet. Ensure the housing is clean, insert the connector, and perform a secure crimp to achieve a solid, low-resistance connection. Inspect for proper alignment and test continuity after mating.
The E1017-57 handles up to 545A continuous and is rated for 600 Vac/dc. It accepts 500 kcmil conductors with brass contacts in a vulcanized rubber housing, providing a reliable high-current interconnect for demanding industrial loads and long cable runs in non-hazardous locations.
Yes. The connector is designed for Ordinary/Non-Hazardous Locations and carries a NEMA 4 rating, offering dust and water ingress protection. Its 600 Vac/dc rating and 545A continuous capability make it suitable for a wide range of industrial power distribution tasks, from motors to conveyors, in controlled environments.
The E1017-57 complies with NEC/CEC standards and features a NEMA 4 rating. These certifications ensure safe operation in typical industrial settings, ease regulatory audits, and compatibility with standard electrical codes for non-hazardous locations.
Cam-Lok connectors like the E1017-57 reduce downtime through quick mating and secure crimps. Durability is enhanced by vulcanized rubber bodies and brass contacts, lowering replacement frequency. The parts are compatible with common crimp tooling and Cam-Lok accessories, supporting scalable deployments and predictable maintenance costs across facilities.
