Eaton Crouse-Hinds Cam-Lok J E1017 plug - 690A/600V
Part Number: E1017-69
Quick Summary
Cam-Lok J Series E1017 plug is a high-current power connector for fast, secure industrial equipment connections. Maintenance teams often wrestle with bulky, slow-to-install plugs that jeopardize uptime and safety. This E1017-69 delivers rugged NEMA 4 protection, NEC/CEC compliance, and ordinary/non-hazardous location suitability for reliable field service. A crimp, yellow vulcanized rubber body and brass contacts translate into faster installs, lower maintenance costs, and long-term performance. In practice, the E1017-69 supports cables up to 800 kcmil and continuous currents to 690A, covering feeders and heavy-duty equipment. The combination of 600 Vac/dc rating and rugged rubber construction helps meet reliability targets while simplifying maintenance scheduling.
Product Information
Extended Description
E1017-69 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Cam-Lok J Series E1017 plug, Up to 690A continuous, 800 kcmil, Yellow, Crimp, Brass contacts, Female, Rubber, Vulcanized, 600 Vac/dc
Product Name
Eaton Crouse-Hinds series Cam-Lok J Series E1017 plug
Catalog Number
E1017-69
Product Length/Depth
7.38 in
Product Height
2.69 in
Product Width
2.69 in
Product Weight
4.16 lb
UPC
662275925831
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
4
Cable size
800 kcmil
Amperage Rating
Up to 690A Continuous
Voltage rating
600 Vac/dc
Material
Rubber
Type
Vulcanized
Connection type
Crimp
Gender
Female
Color
Yellow
Contact material
Brass
Cam-Lok Single Pole Plugs and Receptacles catalog
Cam-Lok J Series Single Pole Plugs and Receptacles catalog page
EB 94 - Cam-Lok E1017, E1019 and E1023 Connectors
Eaton Specification Sheet - E1017-69
Feature to benefit to application aligned with long-tail keywords: Up to 690A continuous current rating translates to fewer parallel connectors and reduced cabinet footprint, improving efficiency on high-load feeders in manufacturing plants. This high-current capability supports large-diameter cables (800 kcmil) with a crimp connection and brass contacts, delivering solid contact integrity and faster installation for turnkey power distribution. The 600 Vac/dc rating enables seamless operation across mixed AC/DC systems, reducing the need for adapters and downtime during commissioning in industrial environments. Vulcanized rubber construction and yellow coloration provide durable, weather-resistant performance in ordinary/non-hazardous locations, minimized wear from vibration, and easier visual inspection during routine maintenance. Compatibility with Cam-Lok J Series simplifies procurement, stocking, and compatibility across existing Eaton/Crouse-Hinds components, reducing total cost of ownership and training time for technicians. Addressing common objections, this plug leverages a proven crimp process for repeatable, field-friendly terminations, lowering rework rates and enabling faster service calls. Real-world insight shows CRIMP-based Cam-Lok assemblies deliver consistent current handling with lower overheating risk in energy-intensive lines, supporting uptime guarantees and compliance objectives for industrial facilities.
Get a Quick Quote for a Eaton Crouse-Hinds E1017-69
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds E1017-69?
Enquire Now
FAQs
The E1017-69 is designed to accept up to 800 kcmil cables and uses a crimp connection with brass contacts, enabling reliable, field-friendly terminations. Ensure proper crimp tooling and torque per Eaton guidance, and verify mating receptacles in the J Series family for a secure, code-compliant installation in feeders and large-power runs.
This plug supports up to 690A continuous current and a 600 Vac/dc voltage rating. It is configured for 800 kcmil maximum cable size with a crimp connection and brass contacts, providing a robust solution for high-power distribution in industrial facilities while maintaining compliance with NEC/CEC standards.
Yes. The E1017-69 features ordinary/non-hazardous location suitability with NEMA 4-rated protection, offering reliable performance in outdoor or damp environments. The vulcanized rubber body and durable brass contacts contribute to sustained operation under varying weather and vibration conditions common in manufacturing and processing plants.
The connector complies with NEC/CEC standards and is rated for NEMA 4 protection, aligning with common industrial and building code requirements. Its ordinary/non-hazardous area classification makes it suitable for many non- hazardous settings, while maintaining robust performance in everyday industrial applications.
Cam-Lok J Series assemblies drive ROI through fast mating and disconnection, reducing downtime during maintenance or reconfiguration. The combination of crimp brass contacts, vulcanized rubber, and a 600 Vac/dc rating lowers rework risk and extends service life, resulting in lower total cost of ownership and improved uptime for high-demand production lines.
