Eaton E1017-80 Cam-Lok Plug - 545 A, 500 kcmil, 600 Vac/DC
Part Number: E1017-80
Quick Summary
Eaton E1017-80 Cam-Lok plug delivers high-current power connections for industrial equipment. Engineers rely on robust, fast-connect solutions that survive harsh environments and minimize downtime. This J Series connector aligns with NEC/CEC standards and carries a NEMA 4 rating for rugged indoor and outdoor use, with ordinary/non-hazardous area classification as standard. Built for 500 kcmil cables and up to 545 A continuous, the E1017-80 uses a durable vulcanized rubber body and brass contacts with a crimp termination to ensure a secure current path. The brown, vulcanized rubber housing resists moisture, oils, and abrasion, while the compact 7.38 in length fits constrained enclosures. In automation projects or heavy power distribution, this plug delivers reliable performance with repeatable results and faster installation.
Product Information
Extended Description
E1017-80 Eaton Crouse-Hinds: Eaton Crouse-Hinds series Cam-Lok J Series E1017 plug, Up to 545A continuous, 500 kcmil, Brown, Crimp, Brass contacts, Female, Rubber, Vulcanized, 600 Vac/dc
Product Name
Eaton Crouse-Hinds series Cam-Lok J Series E1017 plug
Catalog Number
E1017-80
Product Length/Depth
7.38 in
Product Height
2.69 in
Product Width
2.69 in
Product Weight
4.16 lb
UPC
662275909190
Area classification
Ordinary/Non-Hazardous Locations
Standards type
NEC/CEC
NEMA Rating
4
Cable size
500 kcmil
Amperage Rating
Up to 545A Continuous
Voltage rating
600 Vac/dc
Material
Rubber
Type
Vulcanized
Connection type
Crimp
Gender
Female
Color
Brown
Contact material
Brass
Cam-Lok Single Pole Plugs and Receptacles catalog
Cam-Lok J Series Single Pole Plugs and Receptacles catalog page
EB 94 - Cam-Lok E1017, E1019 and E1023 Connectors
Eaton Specification Sheet - E1017-80
Feature: High-current capability up to 545 A continuous. Business Impact: Supports large motor loads and minimizes the number of connections in power distribution schemes. Application: Heavy machinery, mining, and cement plant drives. The robust rating translates to fewer components and reduced maintenance windows, improving overall equipment effectiveness. Feature: Cable size compatibility up to 500 kcmil with brass contacts. Business Impact: Enables direct full-size conductor termination, lowering resistance paths and heat generation. Application: Upstream power distribution and feeder runs in hazardous-free locations. Feature: Crimp connection and vulcanized rubber construction. Business Impact: Ensures a secure, durable electrical path with rapid field termination, reducing field splices and install time. Application: Wet or oily shop floors and outdoor installations where reliability matters. Feature: 600 Vac/dc voltage rating and NEMA 4 enclosure compatibility. Business Impact: Safer operation in dual-voltage systems and environments requiring washdown readiness. Application: Automation panels and outdoor equipment. Feature: J Series female plug design with brown color and 7.38 in length. Business Impact: Compact footprint enables easier routing in tight panels and visibility for maintenance personnel. Application: Replacements and retrofits in aging installations where form factor matters. Feature: NEC/CEC compliance and ordinary/non-hazardous area classification. Business Impact: Regulatory alignment simplifies procurement and reduces risk during audits. Application: Industrial facilities seeking standard-compliant power connectors with predictable performance. Insight: This combination of material selection, current rating, and easy crimp installation reflects Eaton’s focus on reliability and lifecycle cost reduction in demanding environments.
Get a Quick Quote for a Eaton Crouse-Hinds E1017-80
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds E1017-80?
Enquire Now
FAQs
Yes. The E1017-80 is designed for Cam-Lok J Series systems and supports up to 500 kcmil conductors with a crimp termination. This combination ensures a robust current path and reliable, repeatable connections in heavy-duty power layouts. For proper installation, use the recommended crimp tooling and follow the catalog instructions to maintain NEMA 4 performance and NEC/CEC compliance.
The plug is rated up to 545 A continuous and supports 600 Vac/dc. This makes it suitable for large motor feeders and high-current applications in automation, mining, and material handling. Planning should account for startup surges and conductor sizing up to 500 kcmil to maintain safe, efficient operation and compliance with electrical codes.
Yes. It carries a NEMA 4 rating and an ordinary/non-hazardous area classification, making it appropriate for wet, dusty, and washdown-prone locations. The vulcanized rubber body and brass contacts provide durability against moisture, oils, and abrasion, ensuring long service life in demanding industrial settings.
Crimp termination provides a solid, low-resistance connection with no solder joint, reducing the risk of joint degradation over time. It enables faster installation and easier field servicing with proper tooling, lowering maintenance costs and downtime while improving current-carrying capability and fidelity of the power path in demanding environments.
A full set of Eaton resources supports installation and specification clarity, including the Cam-Lok catalog pages, EB 94 instruction sheet for E1017, and the E1017-80 specification sheet. Access to brochures and catalog pages helps verify compatibility, proper crimping procedures, and compliance with NEC/CEC standards for safe, compliant installations.
