Eaton EDS2140 Snap Switch Control Station - NEC/CEC

Part Number: EDS2140
EDS2140
Manufacturer
Eaton Crouse-Hinds
Part number
EDS2140
Category

Quick Summary

EDS2140 is a snap switch control station used in hazardous locations for industrial control panels. Operators and maintenance teams need reliable, factory-sealed enclosures to protect against dust, moisture, and explosive atmospheres. This unit adheres to NEC/CEC standards and carries hazardous-location ratings (Class I, Division 1 and 2; Class II, Division 1 and 2; Class III), along with a NEMA 3, 7, 9 enclosure profile. With 120-277V operation and a 20A rating, it supports scalable automation in plant environments, delivering safety, compliance, and long-term cost efficiency. In the broader context of industrial automation and electrical protection, the EDS2140 offers a robust solution for panel-mounted control needs in challenging environments.

Product Information

Extended Description

EDS2140 Eaton Crouse-Hinds: Eaton Crouse-Hinds series EDS snap switch control station, 20A, With switch, With one 3/4" hub, Feraloy iron alloy, 1, Single-gang, Four-pole, 120-277V, Factory sealed, Dead end, 4-way, 3/4", 120-277 Vac
Product Name
Eaton Crouse-Hinds series EDS snap switch control station
Catalog Number
EDS2140
Product Length/Depth
5.06 in
Product Height
5.875 in
Product Width
3.5 in
Product Weight
7.89 lb
UPC
782274763774
Area classification
Hazardous/Classified Locations
Standards type
NEC/CEC
NEC hazardous rating
Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
NEMA Rating
3 7 9
Enclosure type
With switch
Trade size
3/4"
Number Of Poles
Four-pole
Switch function
4-way
Number of gangs
Single-gang
Style
Dead end
Voltage rating
120-277 Vac
Amperage Rating
20A
Hub style
With one 3/4" hub
Number of devices
1
Primary voltage range
120-277V
Material
Feraloy iron alloy
Special features
Factory sealed
EDS and EDSX Fully Assembled Snap Switches catalog page EDS and EFD Explosionproof Snap Switches UL certification - snap switches EDS and EFD Explosionproof Snap Switches UL certification - snap switches EDS and EFD Explosionproof Snap Switches UL certification - snap switches EDS and EFD Explosionproof Snap Switches UL certification - snap switches IF 328 - EDS, EFS, EDSC and EFSC Single- and Two-gang Device Bodies IF 328 - EDS, EFS, EDSC and EFSC Single- and Two-gang Device Bodies Eaton Specification Sheet - EDS2140
Feature: Feraloy iron alloy construction and factory sealed enclosure deliver rugged protection against dust, moisture, and corrosive atmospheres. Business Impact: Reduces unscheduled downtime and maintenance costs while extending service life in demanding environments. Application: Suitable for hazardous-location panels in oil, gas, mining, and chemical processing facilities. Feature: Four-pole, four-way switch with a 3/4" hub and 120-277V rating. Business Impact: Enables flexible control wiring, reliable power handling up to 20A, and simplified field installation. Application: Ideal for multi-point switching in control stations within complex automation panels. Feature: Single-gang, dead-end enclosure design. Business Impact: Compact footprint minimizes panel space requirements and installation time, lowering overall project costs. Application: Common in space-constrained industrial control panels across various industries. Feature: Factory-sealed construction for hazardous/classified locations. Business Impact: Improves safety compliance, reduces ingress-related failures, and supports regulatory approvals. Application: Chemical plants, refineries, and offshore platforms where environmental protection is critical. Feature: NEC/CEC alignment with NEMA ratings 3, 7, 9. Business Impact: Streamlines procurement, reduces compliance risk, and accelerates commissioning. Application: General-purpose hazardous-location control in oil, gas, mining, and manufacturing sectors.

Get a Quick Quote for a Eaton Crouse-Hinds EDS2140

Chat with us on WhatsApp - fast responses guaranteed

Need to speak with someone? We'll call you back within 2 hours during business hours

Interested in Eaton Crouse-Hinds EDS2140? Enquire Now

FAQs

The EDS2140 is a single-gang, dead-end enclosure with a 3/4" hub, designed to fit standard control panel spaces while accommodating four-pole, four-way switching. Its compact footprint and factory-sealed construction simplify wiring and reduce installation time in hazardous-location environments.
The device is rated for 20A at 120-277V, with four-pole, four-way switch functionality. It supports a 3/4" hub and accommodates a single device per enclosure, enabling reliable control across multiple circuits within a single mounting location.
Yes. The EDS2140 carries NEC/CEC standards with hazardous-location ratings including Class I, Division 1 and 2, Class II, Division 1 and 2, and Class III, and it has a NEMA rating of 3, 7, 9. This combination provides robust protection for control stations in challenging environments.
The EDS2140 complies with NEC/CEC standards for hazardous locations and area classifications. It is rated for Class I/II/III locations, supports Division 1 and 2, and carries NEMA 3, 7, 9 enclosure protections, aligning with industry requirements for safe electrical installations.
The 3/4" hub, single-gang footprint, and factory-sealed design reduce wiring time and maintenance needs, lowering installation costs and downtime. Feraloy iron alloy construction enhances durability, extending service life in harsh environments and delivering lower total cost of ownership over the life of the control panel.
